- Page 1 TTE-7 DTMF Dialing Encoder Manual Revision: 2010-04-16 Covers Hardware Revision: TTE-7: 7163A & Higher...
- Page 2 GENERAL INFORMATION The TTE-7 is a 12-digit DTMF dial encoder with snap-dome keypad in a mountable bezel frame. The TTE-7 will automatically assert the PTT output when a button is pressed and hold the PTT output for 2 seconds for subsequent digits to follow.
- Page 3 HARDWARE INSTALLATION Be certain to follow standard anti-static procedures when handling any of Midian’s products. Connector P1 P2-A (Pin 1) – Green – HI Z – Connect to a high impedance audio point in the transmitter modulator. P2-B (Pin 2) – Red – VIN +6-24 VDC – Connect to switched battery point in the radio. P2-C (Pin 3) –...
- Page 4 Talk circuit consists of D1, C15, C16, R10, and Q3. The time constant of C15, C16 and R10 produces a PTT output for approximately 2 seconds. The TTE-7 input voltage is regulated at +5 volts by VR1. VR1 will work from a low of 6.5 volts to 24 volts. TECHNICAL NOTES Radio Compatibility: Midian has taken the utmost care to ensure the option board integrates into the radio with minimal impact to the features of the radio.
- Page 5 .47u .47u 2.2M +6.5V to 24V +6.5V to 24V VOUT 78L05 .47u 100p 560p GND GND GND GND GND GND PROJECT NAME Midian Electronics, Inc. TTE-7 PRJ_7163_TTE7 APPR DATE: 2008/10/09 DWN.BY SCHEMATIC SHEET DOCUMENT NUMBER 7163-A-1 DESIGN REV. 2008/10/09 COPYRIGHT 2008...
- Page 6 This page intentionally left blank...
