Instructions for Use
RPI
MRN-184-EN Version 6 (05-01-2022)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RPI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RR Mechatronics RPI

Summary of Contents for RR Mechatronics RPI

  • Page 1 Instructions for Use MRN-184-EN Version 6 (05-01-2022)
  • Page 3 RPI.........

  • Page 4: Table Of Contents

    11.1 - - Maintenance items & Maintenance schedule RPI......11.2 - - Removing and replacing cover panels.
  • Page 5 Contents 12 - Error list............. . . 13 - System temporarily out of use.
  • Page 6 1620 AE Hoorn The Netherlands De Corantijn 13 Office address: 1689 AN Zwaag The Netherlands © Copyright RR Mechatronics Manufacturing B.V. All rights reserved. Subject to changes without prior notice. Issued by the Support Department of RR Mechatronics MRN-184-EN Version 6 (05-01-2022)
  • Page 7 Metrology traceability addition Decommissioning Decommissioning only by FSE remark nov. 2021 General update including software version 2.14 and changes due to wording intended use of RPI-Check jun. 2021 General update and changed chapter sequence according FDA regulations jan. 2021 General update oct.
  • Page 8 AFS-24 (WPU). It may be necessary to reference these documents for maintenance or other procedures with the RPI. It is recommended to store these documents in such way that they can be quickly located and where they will not be damaged.
  • Page 9 Introduction These symbols are used to indicate that proper safety equipment has to be used. Protective glasses and gloves must be worn This UV RADIATION sticker is used to refer to a position on or inside the water system cabinet where exposure to UV light is possible This ELECTRICAL GROUND sticker is used to refer to a position on the water system Cabinet or inside where an electrical ground connection is made.
  • Page 10 ▪ Poor quality of feed water The RPI (including WPU) is designed to stay connected to the main power supply and water supply at all times. The quality of RPI’s production has to be checked daily for use on the connected analyzers according local quality specifications.
  • Page 11 Intended use RPI Intended use RPI The RPI is a general purpose instrument intended to dilute a concentrated reagent to a usable fluid for in vitro laboratory testing. MRN-184-EN Version 6 (05-01-2022)
  • Page 12 Installation procedures and requirements are described in the Installation manual. 3.1 - Feed water requirements The provided feed water quality will affect the performance of the RPI and is required to be within the specifications mentioned below. RR Mechatronics recommends that a Merck Millipore representative performs a water analysis prior to the installation of the RPI to ensure your water supply meets the requirements.
  • Page 13 Principles of operation Principles of operation The RPI (Reagent Production Instrument) is an automated reagent preparation instrument. It produces a ready-to-use reagent out of a concentrated reagent and lab water to a predetermined target conductivity. The instrument is a single unit, housing all necessary parts inside a closed frame. The frame is covered with easily removable, coated, sheet metal panels.
  • Page 14 Performance characteristics and specifications Performance characteristics and specifications MRN-184-EN Version 6 (05-01-2022)
  • Page 15 Number of concentrate 2 x 10L, hot swappable cubitainers RPI-Check Result monitoring method The RPI is a general purpose instrument intended to dilute a Intended use concentrated reagent to a usable fluid for in vitro laboratory testing. Traceability Concentrated reagent...
  • Page 16 Rear Location RFID at cubitainer To be determined with customer Concentrate pick-up tube Monitoring process: Control cycle using RPI-Check Monitoring method Acclimated to environment temperature (>24 hours) RPI-Check temperature ≥1x per 24 hrs Frequency Manual start and time scheduled...
  • Page 17 Performance characteristics and specifications Reagent delivery port details: Number of output ports John Guest PM Acetal 6 mm (OD) Output port outer diameter 0.22 µm End point filtration ~ 33 kPa (250 mmHg) by analyzer Expected priming vacuum User interface Full color touch screen Human machine interface 154x90mm (7"), 1024x600 resolution, 85˚...
  • Page 18 Consumables replacement RPI: Every 3 months, WPU: Every 3 months frequency RPI-Check / Progard / Q-gard / end point filters / peristaltic Consumables pump tubing and pickup tubes Electrical requirements 120 or 230V (± 10%), 50-60 Hz (± 3%) Mains voltage 2x 3.15A T (Slow blow) Hollyland 31-50T-032H or equivalent...
  • Page 19 Performance characteristics and specifications Environment Less than 62 dBA Sound level 5-40 °C Environment temperature 15.5 – 32 °C Operating temperature 35-75% non-condensing Relative humidity 0 – 2000 m AMSL Operational altitude Indoor use Indoor/outdoor use Total dimensions L 775 x W 620 x H 750 mm Instrument size 107 kg, including WPU Empty weight...
  • Page 20 Performance characteristics and specifications 5.2 - User level description The software has four access levels from basic functionality for the operator up to full access for the Field Service Engineer. The four levels are: Operator: ▪ Basic functionality Supervisor: ▪ Basic functionality ▪...
  • Page 21 Performance characteristics and specifications 5.3 - Application The instrument is used as part of an automated laboratory logistical system and can be connected to a maximum of 4 analyzers or similar reagent consuming instruments. These combined instruments are expected to have a continuous consumption of <17 L/hr / ~20 L/hr peak (for 3 hours). The instrument will be standing on the laboratory floor.
  • Page 22 Performance characteristics and specifications 5.6 - Identification and Labelling Example of type plate This label indicates the voltage configuration / used fuses in which the instrument is delivered. The voltage cannot be changed. MRN-184-EN Version 6 (05-01-2022)
  • Page 23 Standard operation procedures Standard operation procedures 6.1 - Check before starting up after inactive period Normally, the RPI is running continuously but in case of starting up the instrument again: ▪ check status of the concentrated reagents and RPI-Check ▪...
  • Page 24 Standard operation procedures Production". The instrument start producing ready-to-use The operator can start production by pressing "Start reagent. The main screen shows the consumption of the reagents. MRN-184-EN Version 6 (05-01-2022)
  • Page 25 Standard operation procedures 6.3 - Cubitainer Status It is advised to replace the empty Cubitainer prior to the active Cubitainer reaching 50% of the fill level to ensure continuous production of ready-for-use reagent. The color changes when a cubitainer has <20% concentrate reagent remaining. The color changes to red when a cubitainer is empty (<5%), production switches to other cubitainer and an audible and visual warning is given.
  • Page 26 When both cubitainers are empty, an audible and visual warning is given and production stops until new cubitainers are placed. 6.4 - Replacement of the cubitainers and RPI-Check bottle Wear protective clothing, gloves and safety glasses during replacement. Clean immediately in case of spilling or splashing.
  • Page 27 The lower position is indicated as the "Bottom" concentrate cubitainer (2). The RPI-Check bottle can be found inside the door at the right side of the instrument (3). During normal operation it is possible to produce reagent until both cubitainers are empty.
  • Page 28 Standard operation procedures 6.4.1 - Placement of a new cubitainer Always use concentrated reagent cubitainers that has been acclimatized for at least 24 hours to environment temperature. 1. Prior to use, inspect the cubitainer for any damage. in’ and enter credentials. 2.
  • Page 29 Standard operation procedures cubitainer’. The following message appears: 4. Select ‘Replace 5. Prepare a new cubitainer, remove the cardboard cover to expose neck and cap. Do not extend the neck. 6. For replacement of top cubitainer: Open door, lift drip tray sensor and pull out the drip tray. Replacement of top cubitainer MRN-184-EN Version 6 (05-01-2022)
  • Page 30 Standard operation procedures Open drawer Place new cubitainer nearby and disconnect peristaltic pick-up tube cubitainer from old cubitainer. Remove old cubitainer, remove cap from new container, Place new cubitainer. Ensure the pick-up tube is clean transfer pick-up tube from old to new container. and undamaged.
  • Page 31 Standard operation procedures Ensure the cubitainer is placed correctly. Place cap on the old cubitainer. Discard the old Place pickup tube on the new the container and connect cubitainer according to local regulations. peristaltic pump tube. Wipe drip tray in case of leaking fluids. Push drawer and drip tray in (mind the drip tray sensor).
  • Page 32 Standard operation procedures Open drawer. Place new cubitainer nearby. Exchange cap and pickup tube from both cubitainers. Place new cubitainer in the drawer. Ensure the pick-up tube is clean and undamaged. Remove spilled liquid immediately. MRN-184-EN Version 6 (05-01-2022)
  • Page 33 Standard operation procedures Ensure the cubitainer is placed and connected correctly. Discard the old cubitainer according to local regulations. Push drawer in will indicate if the NFC tag was read correctly. If the NFC tag is not orientated in the correct way or not readable, the reagent information has to be entered manually, see Manual insert cubitainer ID MRN-184-EN Version 6 (05-01-2022)
  • Page 34 Enter new or existing user information and press Submit. Note: After a lot switch, production can be low and F67 occurs. This will be automatically solved by the instrument (RPI). 6.4.2 - Concentrated reagent lot switch When both concentrated reagent cubitainers have the same lot number, reagent production continues without interruption.
  • Page 35 Progress of the Prime storage step is shown on the screen: 6.4.3 - Placement of a new RPI-Check bottle It is shown on the screen if the RPI-Check bottle fluid has to be replaced: Replace RPI-Check: Log in and select the 'Manual"...
  • Page 36 2. Remove empty bottle from the instrument and replace with a new one. Always use a bottle that has been acclimatized to room temperature for at least 24 hours. 3. Place the bottle with the NFC-tag facing the NFC-reader to enable the RPI to read the NFC properly. 4. Close the door.
  • Page 37 Green: instrument in operation mode Orange: warning, instrument needs attention Red: error, instrument needs attention immediately The quality of RPI’s production has to be checked daily for use on the connected analyzers according local quality specifications. MRN-184-EN Version 6 (05-01-2022)
  • Page 38 The RPI measures the conductivity of the RPI-Check and compares it to limits based on the conductivity value stored in the NFC-tag on the RPI-Check bottle. If the measured conductivity is within the limits, the control cycle is passed and the control cycle is finished. If the measured conductivity fails, the GUI will display an error.
  • Page 39 Calibration procedures MRN-184-EN Version 6 (05-01-2022)
  • Page 40 User interface and software menu User interface and software menu The Graphical User Interface or GUI is featured on a touch operated screen located on the front of the instrument. The following program description is valid for software from version 2.15 and up. The user interface has four levels of access: Operator: with basic user functionality ▪...

  • Page 41: User Menu

    User interface and software menu 8.1 - User Menu The following tabs are available: Home Maintenance Manual Settings Information Depending on the access level one or more functions are available. On each screen is shown: active tab (1), menu level (2) and the active access level (3). Available functions are indicated in dark blue (4).

  • Page 42: Access Levels

    The following functions are available for the user: Operator Supervisor Technician Function Home View status Concentrate/RPI-Check levels Manual Start/Stop Production Replace cubitainer/RPI-Check bottle Start Manual Control cycle Manual ID entry Info Performance data Instrument state Instrument information Maintenance WPU maintenance items RPI Maintenance items...

  • Page 43: Operator Level

    User interface and software menu 8.3 - Operator level The lab operator has to login to be able to operate the touch screen. 1. Select Log In 2. Enter the Lab employee credentials on the-screen keypad, to operate the graphical user interface: 3.
  • Page 44 This screen shows if one the cubitainers is empty (<5%) and has to be replaced. If one cubitainer is empty and the other is <10% filled, a warning is given to replace the empty cubitainer. For the RPI-Check bottle the first warning (almost empty) is given if the level is <40% and an urgent replace warning if the level is <20%.

  • Page 45: Supervisor Level

    User interface and software menu 8.4 - Supervisor level 1. Select Log In 2. Enter the Supervisor credentials on the-screen keypad, to operate the graphical user interface: 3. The menu for the Supervisor is visible: More screens are activated at Information tab MRN-184-EN Version 6 (05-01-2022)
  • Page 46 User interface and software menu ▪ Performance data ▪ Instrument state ▪ Instrument information It is not possible to use items on the Maintenance tab On tab Settings the following functions are activated: MRN-184-EN Version 6 (05-01-2022)
  • Page 47 User interface and software menu ▪ General settings ▪ Audio settings ▪ Lab settings MRN-184-EN Version 6 (05-01-2022)

  • Page 48: Technician Level

    8.6 - Home screen The Home screen provides relevant information for available cubitainers and indication of the status of the concentrated reagent cubitainers and RPI-Check. The status can be indicated in three colors: blue=no action needed, orange=action needed, red=immediate action needed.
  • Page 49 The status of the concentrated reagent not currently in use. The status of the RPI-Check. Concentrated reagent or RPI-Check has to be replaced. Concentrated reagent level is almost empty (indicated if concentrate level is <10%). Production is switched to other cubitainer or control cycle cannot be performed.
  • Page 50 User interface and software menu Concentrated reagent or RPI-Check has to be replaced immediately. Concentrated reagent level is empty. (indicated if concentrate level is <5%). By pressing on one of the circles more information is visible with specific data: Warnings are indicated with an orange frame, errors are indicated with a red frame on the screen, including a message.

  • Page 51: Manual Screen

    On this tab reagent production can be started or stopped or to start a Control cycle The other options are: Replace cubitainer (and adding users Replace RPI-Check Manual ID entry production" is grey, it has been more than 24h since a control cycle has been performed. If the button "Start...

  • Page 52: Manual Control Cycle

    User interface and software menu 8.7.1 - Manual Control cycle his option can be used if an additional control cycle has to be performed. A control cycle will take maximum 20 minutes. For this step the door has to be closed. in’...
  • Page 53 User interface and software menu Press Yes, the following screen appears, enter new or existing user information. Click on "new entry" to add a new user. The following screen appears: The next time, this user can be selected from the list. MRN-184-EN Version 6 (05-01-2022)

  • Page 54: Manual Insert Cubitainer Id

    User interface and software menu Submit Press and it will be confirmed that all the concentrate information has been stored correctly: 8.7.3 - Manual insert cubitainer ID Disclaimer This is not the recommended process. “By manually entering the cubitainer ID the instrument is unable to determine and track the consumption from that cubitainer.
  • Page 55 User interface and software menu ‘Manual ID entry’. 4. Select 5. Select applicable "top" or "bottom" concentrated reagent. 6. Enter applicable data, exactly as printed on the cubitainer label and press Next. MRN-184-EN Version 6 (05-01-2022)

  • Page 56: Manual Insert Rpi-Check Id

    Enter batch number and expiry date and an ID is generated. This ID can be entered in the software as manual inserted ID for RPI-Check In case the entered RPI-Check ID is not accepted by the instrument, repeat the process. MRN-184-EN Version 6 (05-01-2022)
  • Page 57 User interface and software menu 6. Log out or otherwise log-out will occur automatically after 5 minutes of inactivity. Disclaimer “By manually entering the cubitainer ID the instrument is unable to determine and track the consumption from that cubitainer. The user accepts all performance and potential legal consequences that this action may have”...

  • Page 58: Information Screen

    8.8 - Information screen Select Information Three options are available: Performance data To retrieve data from a specific batch of concentrate, RPI-Check and traceabilty. Instrument state To see the status of the instrument. Instrument information For general information about the instrument configuration.

  • Page 59: Retrieve Performance Data

    User interface and software menu 8.8.1 - Retrieve performance data Use an empty, virus-free, USB stick, formatted with FAT32. 1. Select ‘Login’ 2. Enter access level credentials 3. Select "Information"tab Data'. 4. Select 'Performance 5. Data can be shown on screen with Search, data can be exported with Export. Search option: On screen can be seen: End time, Result, Conductivity, Temperature, Pulse count and Duration.
  • Page 60 User interface and software menu After using the table button: The available data is shown as a graph. Export option: Data”. 1. Select "Performance 2. Insert an empty USB stick in the slot located at the front of the instrument, near the GUI screen. 3.

  • Page 61: Instrument State

    User interface and software menu 8.8.2 - Instrument state This screen only indicates in which lines is an active water flow (in blue). The lines in black are not containing water at that moment. The overflow lines are only indicated in red, meaning an inactive water flow. 8.8.3 - Instrument information On this screen general information, several software status and serial numbers are displayed.

  • Page 62: Maintenance Screen

    In the Maintenance screen, two options are available on Technician access level: , with maintenance functions for the WPU (filter replacement and cleaning). , with maintenance functions for the RPI (cleaning, replacement of standard parts and shut down). 8.9.1 - WPU maintenance The filter packs in the WPU requires replacing or cleaning (Cl or pH).

  • Page 63: Rpi Maintenance

    User interface and software menu Confirm finishing the WPU Maintenance actions after they are performed. The RPI will go back to online. 8.9.2 - RPI maintenance On the level Technician are options available for regular replacement items: Replace Vent filter ▪...

  • Page 64: Settings

    Set the time zone, date and time with the next options. To apply Time and timezone settings a restart is required. Note: Daylight saving time has to be set manually, the RPI is not connected with an external network. MRN-184-EN Version 6 (05-01-2022)
  • Page 65 User interface and software menu Audio settings: After enabling the the silent mode, the timer can be refreshed for one hour. With adjusting the sound volume., the normal sound level can be set. Only error messages signals will stay at the same level. Lab settings: Set control cycle time: For setting the time for the automatic control cycle.

  • Page 66: Operational Precautions, Limitations And Hazards

    Engineer. ▪ If the RPI has to be shut off for a long period of time, at first the shut down cycle has to be performed by a trained Field Service Engineer. Contact your Service Representative. MRN-184-EN Version 6 (05-01-2022)

  • Page 67: Avoidance Of Infection

    The internal fluid containers may never be opened by the user, but only by trained service personnel. During prolonged use of the RPI, harmful bacteria (f.e. legionella) may grow inside the containers. Before the containers are opened, the disinfection procedure must be performed (see section Maintenance-Cleaning for details).

  • Page 68: Troubleshooting

    Troubleshooting Troubleshooting In case of errors, the system will generate an error message on the GUI. Also, the (optional) status light will be changed from green to orange in the case of warning, or to red in the case of a production error. Warnings and errors of the WPU are displayed on the AFS-display (visible from the outside) Occurring errors are indicated on the screens with red outlines and error codes with descriptions.

  • Page 69: No Water

    Troubleshooting If more errors are active, it will be indicated: 10.1 - No water -Possible stop of water supply, check water connection/supply. -WPU-error, check display of the WPU-unit, in case of no water, check tubing and water supply. 10.2 - Concentrated reagent information is not recognized If after placing a new concentrated reagent cubitainer the data is not recognized (error F55), the instrument will not start production.

  • Page 70: Reagent Errors

    Troubleshooting 10.3 - Reagent errors Check the cubitainer connection or replace the cubitainer if this error persists. Press confirm to continue: Press confirm and solve other errors if needed: MRN-184-EN Version 6 (05-01-2022)

  • Page 71: Control Cycle Does Not Start Or Fails

    10.4 - Control cycle does not start or fails If the automatic control and manual control does not start: ▪ Check if the door is closed. ▪ DI-vessel is not filled (enough), check water supply and WPU-unit. ▪ Check/replace RPI-Check Peristaltic pump tube T30 MRN-184-EN Version 6 (05-01-2022)

  • Page 72: Maintenance

    Maintenance Maintenance Required maintenance items will be indicated by messages, which only can be removed after correct replacement and confirmation by a trained Lab Technician (quarterly maintenance) or Field Service Engineer (quarterly maintenance/yearly maintenance. Inform the Lab Technician or your Field Service for performing maintenance as soon as possible. We recommend performing the maintenance in time to be sure the instrument will produce reagent as required.

  • Page 73: Maintenance Items & Maintenance Schedule Rpi

    If empty Operator specific RPI-Check A0020487 (12 If empty Operator pcs) Quarterly maintenance RPI (with parts from Quarterly Maintenance Kit A0020395): Replacement endpoint filters & QLV0400013 3 months Lab technician tubing (4 pcs) Replacement RPI-Check tubing A0020834 3 months...

  • Page 74: Removing And Replacing Cover Panels

    2. Lift the rear of the top cover approximately 5 cm. 3. Pull top cover to the rear. Now you can fully remove the top panel from RPI. 4. Place the top panel in a suitable location until it is placed back.

  • Page 75: Replacing The Vent Filter

    Maintenance Remove side panels 1. Undo the latches from a side panel on the inside of the RPI. 2. Now gently push the side panel outwards. 3. Lift the side cover up out of the lower supports with use of the grip.
  • Page 76 Maintenance 1. Enter software and log in with the applicable credentials. Maintenance 'RPI" 2. Go to and select Replace vent filter, the following message is given: 3. Press 4. Press to confirm and start actual replacement. 5. Press after the message "Instrument will be offline."...

  • Page 77: Replacing Peristaltic Pump Tubes

    Maintenance 8. Confirm that replacement is correctly performed. Production is started again. 9. Log out or otherwise log-out will occur automatically after 5 minutes of inactivity. 10. Dispose of removed parts according to local regulations. 11.4 - Replacing peristaltic pump tubes Only to be performed by a trained Lab Technician or FSE.
  • Page 78 1. Remove the top panel by loosening the three M4 bolts(with Torx T10) at the back, lifting up and fully removing from the instrument. 2. Undo the latches from the side panel on the inside of the RPI (1) and remove side panel (2) with use of the handle inside the panel, remove side panel completely (3).
  • Page 79 Maintenance 8. Remove the strain relief from the frame. 9. Disconnect the pump tubes from the cubitainers. 10. Disconnect the pump tubes from the mix vessel. Use the John Guest connection tool to remove the tube coupling. MRN-184-EN Version 6 (05-01-2022)
  • Page 80 Maintenance 11. Remove the old tubes from the pumps. Lift the lever to open the clamp system, remove old tube 12. Guide the new pump tubes to the holes, push the strain relief in the hole. MRN-184-EN Version 6 (05-01-2022)
  • Page 81 Maintenance 13. Connect the pump tubes with the "quick connect" to the cubitainers and close the drawers. 14. Mount new tube in the pumps, close the clamp system again. 15. Connect the new pump tubes to the mix vessel. C1 for top cubitainer (T28), C2 for bottom container (T29).

  • Page 82: Replacing Pickup Tubes/End Point Filters

    Only to be performed by a trained Lab Technician or FSE. Be aware of liquid spilling, use a cloth to prevent liquid dripping in the instrument. Replacing Pickup tubes: 1. Enter software and log in with the applicable credentials. Maintenance "RPI". 2. Go to and select Replace Pickup tubes/End filter, the following message is given.
  • Page 83 Maintenance 6. Replace T30 from RPI-Check bottle to V6 connection. Replacing endpoint Replacing endpoint Replacing Endpoint filters and tubing (4xA0017999): The end point filter module is positioned at the left upper side. MRN-184-EN Version 6 (05-01-2022)
  • Page 84 Maintenance 1. Ensure connected analyzers are placed in an operational mode where reagent consumption will not occur. If not done yet: R emove the top panel by loosening the three M4 bolts(with Torx T10) at the back, lifting up and fully removing from the instrument. 3.

  • Page 85: Maintenance Wpu

    Maintenance 7. Confirm that replacement is correctly performed. Production will resume. 8. Log out or otherwise log-out will occur automatically after 5 minutes of inactivity. 9. Dispose of removed parts according to local regulations. Note: Optional can the complete end filter assembly be demounted after removing the old tubing by loosening the knurled knobs.

  • Page 86: Cleaning

    Maintenance For maintenance of the WPU: See AFS24 User manual (Merck). Remove top and right side panel first. 11.7 - Cleaning The concentrate and reagent tubing are automatically rinsed before each control cycle. As needed a manual rinse cycle can be performed by the Field Service Engineer. Annually, Service will perform additional internal cleaning during the PM visit.

  • Page 87: Replacing Main Fuses

    Maintenance The outer casing of the instrument and the inside of the drawers can be cleaned with any standard (non- abrasive) cleaning agent or soap solution and a microfiber cloth. The LCD screen and the light box can be cleaned with a clean soft cloth, slightly damped. Do not use organic solvents.
  • Page 88 Maintenance Replace both fuses with the appropriate type, as indicated on the type label and in the Technical specifications Push the fuse holder back into the power entrance module. MRN-184-EN Version 6 (05-01-2022)

  • Page 89: Error List

    F05 Internal test ECT unit timeout Issue with the ECT module Call for service F06 Air bubbles detected in control process Bubbles being pumped RPI- Replace RPI-Check bottle Check bottle is (almost) empty Check pick up tube RPI-Check tubing/pickup is...
  • Page 90 Not correctly connected F18 Leak detection triggered Leak Check vessels and tubes and replace leaking pick-up tubes. Accidental spilling of e.g. RPI- Check fluid F19 Waste pump not active and overflow Float switch(es) broken Call for service upper float triggered...
  • Page 91 External temperature too high Automatic Drain storage and wait for storage vessel out of range or too low restart production F51 NFC tag for RPI-Check not successfully No RPI-Check bottle installed Place new bottle or move control read and door is closed bottle...
  • Page 92 Error list F59 RPI-Check bottle open life expired Open life expiration is detected Replace RPI-Check bottle F60 When starting control, open life expired After start of control step shelf Replace RPI-Check bottle life expiration is detected F61 Shelf life one concentrate cubitainer...
  • Page 93 Error list F72 Error: Expiration date of manual Placed concentrate is out of Replace cubitainer with correct barcode has already passed date expiration date F73 An unexpected error has occurred in the NFC reader failure Call for service tagreader F74 Tag is write protected and cannot be Unusable tag on place Replace cubitainer with a writable tag used...

  • Page 94: System Temporarily Out Of Use

    Als het instrument niet gebruikt wordt (inclusief 's nachts) dient de watertoevoer afgesloten te worden om incidenten met waterverspilling te voorkomen. Activeer de "LAb gesloten"modus van de WPU-eenheid. If the RPI is shut off for a long period of time: Call for service, this can only be performed by a Field Service Engineer.

  • Page 95: Decommissioning And Disposal

    Decommissioning and disposal Decommissioning and disposal Only to be performed by a trained FSE. In case of permanent removal of the instrument 1. Remove all data from the memory. 2. Perform a complete shut of procedure to remove all fluids from the instrument. 3.

  • Page 96: Glossary Of Terms

    Sheet. In this type of MSDS all kind of important data can be found on reagents. Progard: Pre filter pack positioned on the side of the Water Purification Unit RPI: Reagent Preparation Instrument WPU: Water Purification Unit (AFS-24 Merck) MRN-184-EN Version 6 (05-01-2022)
