MECHANICAL SPECIFICATION
Enclosure Construction Material
White or Red ABS
Flame Retardant rating 94V0
Weight
Module - 30g
Boxed - 125g
Including packaging - 160g
TECHNICAL SPECIFICATIONS
SUPPLY VOLTAGE
LOOP CURRENT
EXTERNAL SUPPLY - CURRENT
POWER OUTPUT MAX.
MAX. CABLE SIZE
MAX. HUMIDITY
OPERATING TEMPERATURE
ENCLOSURE - MATERIAL
PROTECTION CATEGORY
DIMENSIONS
WEIGHT
ORDER CODE
GFE-PA-VOX-A
GLOBAL FIRE EQUIPMENT S.A.
MARF - Armazéns F3 e F4, Sítio do Guelhim, Estoi, 8009-021 FARO, PORTUGAL
Sales: sales@globalfire.pt • Technical Support: techs@globalfire.pt • www.globalfire.pt
100
NOTE: All dimensions in mm
Loop: 17-30 V DC - External Supply: 20-30 V DC
0.5 mA (Quiescent) - 0.5 mA (Sounder Active)
2.0 mA (Quiescent) - 1.0 A (Sounder Active)
24 Watts rms
2
2.5 mm
85% RH Non-Condensing
-5ºC to 40ºC
White or Red ABS
IP44
100 (D) x 48 (H) mm
125 g - 160 g including packaging
DESCRIPTION
Addressable Voice Controller/Amplifier
• Tel: +351 289 896 560
GFE-PA-VOX-A
Addressable Voice
Controller/Amplifier
The GFE-PA-VOX A is an addressable PA
Speaker Amplifier/Controller which is
available in either Red or White
housings. The GFE-PA-VOX A is able to
provide a maximum of 24 W of sound
output to a single PA Speaker. Up to 32
individually addressed controllers can
be installed per loop occupying an
address in the range 94 to 125. The
address is set using switches 1 to 5 of the
8 way DIL switch.
With message selection directly
programmable via the standard sounder
programming of the Junior and Juno-
Net panels, the GFE-PA-VOX-A,
can
broadcast up to 5 differentiated pre-
loaded messages. The desired messages
can be downloaded from our own
proprietary recording PC application, via
a standard USB interface. This product is
loop controlled and externally powered.
INSTRUCTION MANUAL V.07/2013
FEATURES
Message Programming
via USB interface
Multi-Message (5)
Multi-Language
120 dB maximum sounder output at 1 m
Synchronization for fast activation
Compatible with all GFE
addressable panels
Made in Portugal-EU
