Page 1: Table Of Contents
SIGMA-X Series USER MANUAL SIGMA-X8 SIGMA-X10 SIGMA-X12 SIGMA-X15 SIGMA-X18B SIGMA-XV5 & XV5T SIGMA-XV9 & XV9T www.wharfedalepro.com... - Page 2 UNPACKING All Wharfedale Pro products are fully checked before leaving our factory. After unpacking please inspect the cabinets for any physical damage Please retain the shipping carton if possible and internal packing material incase the unit ever needs to be returned. Please check as soon as possible that the unit is functioning.
- Page 3 Improved mounting and rigging options make SIGMA-X simple to install into almost any location. The improved audio definition is also welcomed as SIGMA-X has been completely re-evaluated by the Wharfedale Pro International R&D team.
- Page 4 0° 45° SIGMA-X series can use M8 forged shoulder eye bolt ONLY. Be aware that lifting eye bolts at an angle reduces the safe load. Always ensure the rigging hardware conforms to the safety standards and regulations in your area.
- Page 5 SIGMA-X Series Installation Hardware Both models are supplied with U-bracket hardware SIGMA-XV5 / XV5T SIGMA-XV9 / XV9T The optional WPB-SV bracket allows for angles of up to 15° to be created SIGMA-XV5 / XV5T SIGMA-XV9 / XV9T...
-
Page 6: Sigma-X8
Dimensional Drawings SIGMA-X8 127.0 282.7 284.0 SIGMA-X10 127.0 338.3 338.0... -
Page 7: Sigma-X12
Dimensional Drawings SIGMA-X12 127.0 354.0 358.8 SIGMA-X15 127.0 435.0... -
Page 8: Sigma-Xv9 & Xv9T
Dimensional Drawings SIGMA-X18B 385.8 360.0 502.0 779.8 126.0 SIGMA-XV9 & XV9T 145.0 126.0 SIGMA-XV5 & XV5T 126.0 126.0 145.0... - Page 9 Response Graphs SIGMA-X8 Note : Specification and graphs are created with the dedicated DSP presets.
- Page 10 Response Graphs SIGMA-X10 Note : Specification and graphs are created with the dedicated DSP presets.
- Page 11 Response Graphs SIGMA-X12 Note : Specification and graphs are created with the dedicated DSP presets.
- Page 12 Response Graphs SIGMA-X15 Note : Specification and graphs are created with the dedicated DSP presets.
- Page 13 Response Graphs SIGMA-X18B Note : Specification and graphs are created with the dedicated DSP presets.
- Page 14 Specifications Model Name SIGMA-X8 SIGMA-X10 SIGMA-X12 System Type Passive Passive Passive Configuration Two-Way Two-Way Two-Way Frequency Response (+/-3 dB) 70 Hz - 18 KHz 65 Hz - 18 KHz 60 Hz - 18 KHz Frequency Range (-10 dB) 65 Hz - 20 KHz 60 Hz - 20 KHz 55 Hz - 20 KHz Sensitivity 2.83 V / 1 m...
- Page 15 Specifications Model Name SIGMA-X15 SIGMA-X18B System Type Passive Passive Configuration Two-Way Subwoofer Frequency Response (+/-3 dB) 50 Hz - 18 KHz 35 Hz - 250 Hz Frequency Range (-10 dB) 45 Hz - 20 KHz 30 Hz - 250 Hz Sensitivity 2.83 V / 1 m 98 dB 100 dB...
- Page 16 Specifications Model Name SIGMA-XV5 SIGMA-XV9 SIGMA-XV5T SIGMA-XV9T System Type Passive Passive Passive Passive Configuration Two-Way Two-Way Two-Way Two-Way Frequency Response (+/-3 dB) 160 Hz - 18 KHz 130 Hz - 18 KHz 160 Hz - 18 KHz 130 Hz - 18 KHz Frequency Range (-10 dB) 150 Hz - 20 KHz 120 Hz - 20 KHz...
- Page 17 Wharfedale Pro products are warranted of manufacturing or material defects for a period of three years from the original date of purchase. In the event of malfunction, contact your authorised Wharfedale Pro dealer or distributor for information. Please be aware that the warranty details may differ from country to country. Contact your dealer or distributor for information (available at www.wharfedalepro.com).
