- Page 1 S E R I E S L O U D S P E A K E R S I N S T R U C T I O N M A N U A L WHARFEDALE SYSTEMS DIVISION...
- Page 2 Operating/Use 1. The SI Series accept cables with Speakon™ and bare wire and feature two Speakon™ type connectors and a barrier strip situated at the rear of each cabinet. These are connected in parallel.
- Page 3 ● Dual Speakon™ type and Barrier strip connectors ● Available in black or white SI SERIES OVERVIEW: The SI Series comprises of the SI-10, SI-12, SI-15 and SI 28 full range systems plus two subwoofers - the SI15B and the SI-18B. SI-10, SI-12, SI-15 and SI 28: All the full range models are two way systems with an internal passive crossover providing high level , high definition performance in a compact enclosure.
-
Page 4: Specifications
S I - 1 0 SPECIFICATIONS: SYSTEM: Power handling: 120watts RMS,240watts program, 480watts peak Nominal Impedance: 8 Ω Frequency response (+/-3dB): 65-20kHz Sensitivity: 96 dB/1watt/1meter Coverage: 70 x 70º Maximum SPL (dB) ref Peak Power: 123dB LF Driver: 10” HF Section: Coil Size: 44mm/1.7 inches Exit Size: 25.4mm/1 inch Diaphragm Material: Metal... - Page 5 SPECIFICATIONS: SYSTEM: SI-12 Power handling: 250watts RMS,500watts program, 1000watts peak Nominal Impedance: 8 Ω Frequency response (+/-3dB): 55-20kHz Sensitivity: 97 dB/1watt/1meter Coverage: 70 x 70º Maximum SPL (dB) ref Peak Power: 127dB LF Driver: 12” HF Section: Coil Size: 44mm/1.7 inches Exit Size: 25.4mm/1 inch Diaphragm Material: Metal Crossover Point: 2.3k...
- Page 6 S I - 1 5 SPECIFICATIONS: SYSTEM: Power handling: 300watts RMS, 600watts program, 1200watts peak Nominal Impedance: 8 Ω Frequency response (+/-3dB): 45-20kHz Sensitivity: 98 dB/1watt/1meter Coverage: 70 x 70º Maximum SPL (dB) ref Peak Power: 129dB LF Driver: 15” HF Section: Coil Size: 44mm/1.7 inches Exit Size: 25.4mm/1 inch...
- Page 7 S I - 2 8 SPECIFICATIONS: SYSTEM: Power handling: 200watts RMS,400watts program, 800watts peak Nominal Impedance: 8 Ω Frequency response (+/-3dB): 70-20kHz Sensitivity: 97 dB/1watt/1meter Coverage: 70 x 70º Maximum SPL (dB) ref Peak Power: 126dB LF Driver: 2 x8” HF Section: Coil Size: 44mm/1.7 inches Exit Size: 25.4mm/1 inch...
- Page 8 S I - 1 5 B SPECIFICATIONS: SYSTEM: Power handling:300watts RMS,600watts program, 1200watts peak Nominal Impedance: 8 or 4Ω Frequency response (+/-3dB): 45-1kHz Sensitivity: 98 dB/1watt/1meter Maximum SPL (dB) ref Peak Power: 129dB. System Frequency: 40Hz Enclosure Type: Trapezoidal Finish colour: black or white tough acrylic paint Rigging : M8 x 12 Back Panel Connectors: Speakon™type x 2 and barrier strip Dimensions mm HxWxD: 640 x 452 x 396...
- Page 9 S I - 1 8 B SPECIFICATIONS: SYSTEM: Power handling: 400watts RMS,800watts program, 1600watts peak Nominal Impedance: 8 or 4Ω Frequency response (+/-3dB): 35-2kHz Sensitivity: 99 dB/1watt/1meter Maximum SPL (dB) ref Peak Power: 131dB. System Frequency: 35Hz Enclosure Type: Rectangular Finish colour: black or white tough acrylic paint Rigging : M8 x 12 Back Panel Connectors: Speakon™type x 2 and barrier strip...
- Page 10 23.48 32.3 36.6 52.8 2 way 2 way 2 way WHARFEDALE SYSTEMS DIVISION www.wharfedalepro.com All rights reserved © 2004 Wharfedale Pro. Wharfedale is a member of the International Audio Group (IAG). SI-15B SI-18B 45-1kHz 35-2kHz 98dB 99dB 1200 1600 129dB...
