Mirage Omnican OC-55 Specifications

O mnic an OC - 55
• Exclusive OMNIGUIDE technology for immersive
360-degree sound dispersion
• Perfect for in-ceiling complete home theater
application
• Indoor or outdoor installation; weather resistant
construction
• Rotatable OMNIGUIDE allows fine-tuning of
sound in the listening area
• Low profile design
• Woofers feature Ribbed Elliptical Surround™
for increased output and lower distortion
• Easy installation, setup
• Removable back boxes for ease of installation
in tight spaces
• Paintable grille and bezel
Specifications
DESIGN:
SYSTEM TYPE:
RECOMMENDED
AMPLIFIER POWER:
NOMINAL IMPEDANCE:
MINIMUM IMPEDANCE:
FREQUENCY RESPONSE
(+/- 3DB):
SENSITIvITY (1W/1M):
CROSSOvER POINT:
TWEETER:
WOOFER:
HEIGHT:
WIDTH:
RECOMMENDED HOLE
CUT-OUT:
REQUIRED
INSTALLATION DEPTH:
CONNECTORS:
PACkAGING QUANTITY:
COLORS:
OTHER UNIQUE FEATURS:
OPTIONAL INSTALLATION
BRACkET:
All specifications are subject to change without notice. ©2008
Weather resistant Omnipolar
in-ceiling speaker
2-Way
10 to 125 Watts
8 Ohms
4 Ohms
80 Hz - 20 kHz
89 dB
2.5 kHz
1" PTH™ Pure Titanium Hybrid
tweeter
5.5" Titanium Deposit
Polypropylene woofer with
patented Ribbed Elliptical
Surround
7.28" / 18.48 cm (1.6" / 4cm visible
height when installed)
W - 8.03" / 20.4 cm (back box)
W- 9.43" / 23.96 cm (outside baffle)
Ø 8.15 / 20.7 cm
5.43" / 13.8 cm (with back-box
installed)
2.87" / 7.3 cm (without back-box)
High quality spring loaded
1 per box
White
Weather resistant design with UV
rated enclosure. Rotatable
OMNIGUIDE module. Removable
back-box for installations with
limited mounting depth
ICB-55
www.miragespeakers.com
