USER MANUAL

Salt VS

ASIN AQUA

2021

ELECTROLY SER FOR DISINFECTION

OF THE SW IMMING POOL WATER

Electrode TE–25

INTEGRATED

VS PUMP

CONTROL

w w w.asekopool.com

Need help?

Do you have a question about the ASIN AQUA Salt VS and is the answer not in the manual?

Questions and answers

Summary of Contents for Aseko ASIN AQUA Salt VS

Page 1 USER MANUAL Salt VS ASIN AQUA ® 2021 ELECTROLY SER FOR DISINFECTION OF THE SW IMMING POOL WATER Electrode TE–25 INTEGRATED VS PUMP CONTROL w w w.asekopool.com...
Page 2 General safety information This user manual contain basic information that should be observed during assembly, start-up, operation, and maintenance. Therefore, this user manual must be read by installers and operators prior to assembly and start/up, and must be accessible to every user of this unit. Additionally, all further safety information in this document absolutely must be observed.
Page 3 The chemicals used with the ASIN Aqua must be handled in a safe manner to prevent damage or personal harm. Aseko recommends you always use personal protective safety equipment when handling the pH and chlorine agents. Refer to the Materials Safety Data Sheet (MSDS).
Page 4 What do you receive in your box Water thermometer with housing #13192 Device ASIN AQUA Salt Probe housing 2 pcs Probe housing 2 pcs #12013 Peristaltic pumps #12093 Peristaltic pumps #12093 Electrode TE–25 Flowmeter with ﬁ lter Flowmeter with ﬁ lter #12106 CLF* probe #12052 CLF* probe #12052...
Page 5 #13209-25 Inserting plug DN50 pH 7.00 Bu er #12065 Air thermometer 1/4“threaded #12134 Redox Bu er #12063 #13192 Original Aseko Chemicals 20 l for pools Salt #12110 pH MINUS #12130 pH MINUS #12130 ALGICID #12156 ALGICID #12156 5 l for whirlpools...
Page 6 (3-4kg salt per 1m3), precise measuring, by FREE Chlorine Membrane Probe, with digital intelligence and connection to ASEKO Web Services makes from ASIN AQUA Salt the best solution for Your pool.
Page 7 Pool management functions Filtration Time Control Daily, automatic start of the ﬁ ltering for individually preset periods. Water Level - Reﬁ lling Water level can be monitored by optional level sensor #12086. System can be level sensor #12086. System can be level sensor individually programmed to control up to four di erent water levels at your pool and switch the water reﬁ...
Page 8 ASIN AQUA Salt Installation WARNING: The location temperature should permanently be in the range from +5 °C to +40 °C. 40 °C ASIN AQUA Salt ALGICID 5 °C 40cm ASIN AQUA Salt ALGICID 40cm 40cm 40cm 150cm Wall bracket 18,5 cm 18,5 cm ASIN AQUA Salt ALGICID...
Page 9 Installing the Probes Carefully insert the pH, CLF or REDOX probe into the housing. After probes have been inserted, slightly tightened and connectors have been connected, ASIN AQUA Salt is ready for connection to the water system of your pool. WARNING: Only hand tighten the probes or use the attached plastic wrench for probes.
Page 10 Connection of electrode TE-25 Insert the electrode to the branch line of the ﬁ ltration system according to the Electrode TE–25 following diagram. Build the branch using plastic pipes with closing valves to enable future closing for necessary electrode maintenance or replacement. In between the branch inlet and outlet insert another valve to open or close direct ﬂ...
Page 11 Chlorine pH – mg/l Salz Algizid Temperature Water level kg/m 29,0 Leistung g/std. ml/m °C TIMER FILTRATION Electronic ﬂ owmeter with ﬁ lter and salinity sensor 184 mm 13 mm 20 Nm 50 mm Ø 50 mm Thermometer Water sam- pling point pling point Gluing...
Page 12 Speedﬁ t connection G1/4” thread 6.2x4 hose Aseko provides the unique Speedﬁ t connecting ﬁ tting for measured water LOCKING connection. To connect the interconnecting tube, push it into the Speedﬁ t connector and then lock it by pulling back. To disconnect the interconnecting tube, push and hold a circular collet and pull the interconnecting tube out.
Page 13 Water-cooled POOL Electronic WATER INLET WATER INLET ﬂ owmeter with ﬁ lter and salinity sensor Max. pool water Water sam- pressure pling point pling point 1,5 Bar THE WATER OUTLET Besgo FROM POOL FROM POOL FROM POOL TO POOL Heating...
Page 14 Pool Chemicals Connection In this step, it is necessary to connect the injecting valves of individual chemicals to the dosing pumps and dosed agents. Place the injecting valve in the T-joint, blinded with the DN50 1/4” threaded plug #12134. WARNING: Only hand tighten. Do not use tongs or any other tools. Injecting valve T-joint with inserting DN50 plug G1/4”...
Page 15 Chlorine pH – mg/l Salz Algizid Temperature Water level kg/m 29,0 Leistung g/std. ml/m °C FILTRATION TIMER Max 8 m Max 8 m Besgo FROM POOL FROM POOL FROM POOL TO POOL Heating...
Page 16 POWER SUPPLY Accessories Connection ZDROJ NAPÁJENÍ 230 V ~ 50 Hz 230 V ~ 50 Hz RELAY 230 V, MAX 1 A 230 V relé Solenoid valve Solenoid ﬁ lling dopuštění max 1A Besgo valve 5W Besgo 5 W Filter backwash Praní...
Page 17 VS Pump module connection SPECK TYP A Speed 3 HIGH Speed 2 MEDIUM Speed 1 STOP Speed 0 STOP PENTAIR TYP B OVERDRIVE Speed 3 HIGH Speed 2 MEDIUM Speed 1 Speed 0 STOP HAYWARD (older type) TYP C Speed 3 HIGH Speed 2 MEDIUM...
Page 18 Power Supply Connection to the mains: Leave the mains switch in the o position. Connect the ﬁ ltering device to the ASIN AQUA Salt switched socket outlet Installation must be (ﬁ ltration power supply - max. 1.4 kW / 230 VAC). protected by a residual Connect the 230 V / 50 Hz mains cable to ASIN AQUA Salt (on the right side).
Page 19 Installation Test WARNING: Any obstacles, bubbles or leaks in the connecting tube will prevent ASIN AQUA Salt from correct operating. The clear plastic tube allows you to monitor ﬂ ow of liquid to the injecting valves. Before commencing the operation, test ASIN AQUA Salt installation. Most problems result from incorrectly performed installation.
Page 20 Control Basic Screen The basic screen display measured, required values and status information. E.g. click on the Chlorine tab to enter the setting of the required chlorine value in pool water. Value Required. Value Measured. The chlorine pump status – ON. ON/OFF indicates the current status ON/OFF indicates the current status ON/OFF...
Page 21 Settings Back to the main screen. Displays help/manual for Back to the previous the particular screen. screen. Movement through Menu Movement in menu to the previous page. ON - function is switched on Indicator of the current page and the total number of pages.
Page 22 Conﬁ guration Date and Time To ensure the correct function of timers, set the current date and time. Pool Volume To ensure the correct function of ASIN AQUA Salt, enter the correct volume of your. Calculate your pool volume in m Length (L) times width (W) times depth (D) is volume (V) - (L ×...
Page 23 Heating Control Water Temperature Measurement and Heating Control The high-accuracy electronic thermometer is used to measure water temperature. This should be installed to the inlet pipe coming from the pool. Never mount it downstream of the heat exchanger. Signiﬁ cant distortion of temperature occurs.
Page 24 ASIN AQUA Salt does not take any action and it waits for stabilization of a signal from probes. Concentration pH – If you use the original ASEKO Pool & SPA chemicals keep the pre-adjusted values. In case of use other non-original chemicals adjust concentration according to data on the label of a chemical used.
Page 25 Choosing the disinfection probe CLF free chlorine probe Free chlorine measurement Redox probe of the RX potential Measurement of redox potential...
Page 26 System start-up MAX POOL VOLUME Salting the pool water Chlorine generating depends on the salt concentration and water temperature. Uncovered As lower the temperature as lower the chlorine production. You can boost the electrolyzer by increasing the salt concentration. 1 kg of salt per cubic meter 60 m of water can increase the electrolyzis power for about 20%.
Page 27 Salt to be used SALT Do not use rock salt. All additives may cause electrode lifetime shortening. ASIN AQUA Salt is designed to electrolyze water with 4 kg/m salt BIOCID CERTIFIED concentration. Electrode may get damaged at lower salt concentrations than 1,5 kg/m .
Page 28 First start procedure The water in the pool must be clean without any additives. Ideally ﬁ ll the pool with fresh water from the water main. 1. Ensure the ﬁ ltration system runs NONSTOP for 24 hours • Set the required values via the main screen by pressing the appropriate tab (see the chapter Control): •...
Page 29 pH Setting Considering that the ASIN AQUA Salt water treatment system is e cient in the broad pH range, it is useful to enter the required pH value equal to pH value of water you reﬁ ll or slightly lower. Required pH value = reﬁ...
Page 30 If you use the CLF probe For the correct functionality of the CLF probe you must observe the following conditions: pH of the pool water The ideal pH value should be between 7.3 and 7.6. The pH of the pool water must be stabilized. If the pH value ﬂ...
Page 31 If you use the Redox probe For the correct functionality of the REDOX probe, you must observe the following conditions: pH of the pool water The ideal pH value should be between 7.3 and 7.6. The pH of the pool water must be stabilized. If the pH value ﬂ...
Page 32 Safety Functions Maximum Number of pH Doses - without Probe Response If the measured pH value does not change even after preset quantity of doses (according to the settings), ASIN AQUA Salt stops pH dosing and an error message appears on the display. The other ASIN AQUA Salt functions are not limited.
Page 33 In Operation Measurement and Calibration pH Probe Calibration When pH is being measured in operation, there may be a di erence between the ASIN AQUA Salt value and the current pH value measured directly in water. Calibration can be done in two ways: With a buffer •...
Page 34 In Operation Measurement and Calibration CLF Probe Calibration Calibration rules: Calibration is performed only for reﬁ ning the value measured by the colorimeter or Pool Tester and the measured value displayed on the ASIN AQUA Salt (if the di erence is up to 0.2, calibration is not necessary). The probe can be calibrated when the chlorine content in pool water corresponds to the required value or it is higher (measured with a colorimeter or Pool Tester).
Page 35 There is no manufacturer of pH and REDOX probes that cover its products with warranty. ASEKO has decided to cover supplied probes to its clients by two year warranty period that cover free repair of supplied probe that will have higher tolerance than above described.
Page 36 The LAN connector is to be connected to the domestic router. Data are sent in the intervals of 10 seconds to the address pool.aseko.com, the route must not be blocked by the ﬁ rewall. Connection of ASIN AQUA Salt to your LAN is not complicated. You just need some basic IT skills.
Page 37 INTERNET Home network INTERNET 3G / LTE WIFI EXTENDER Wiﬁ extender INTERNET Powerline via 230 V 230 V socket outlet INTERNET...
Page 38 Application is available for iOS and Android operation systems. Main screen after opening will ask for typing your ASIN AQUA Salt serial number. If you have more pools equipped by the ASEKO NET adapter you can load all of them to one application. Pool LIVE...
Page 39 The web application for detailed monitoring of the pool water quality by means of well-arranged graphs. It shows all the measured parameters as well as ASIN AQUA Salt actions up to 30 days back. This application is giving you the detailed information of the pool status and detailed review of all events, taken actions and act levels of monitored items up to 30 days back.
Page 40 Maintenance #12073 Replacement hose for the pump PP 60 To ensure the optimum e ciency, perform visual checks and maintenance of ASIN AQUA Salt on a regular basis. Pump Hose Replacement To prevent the pump from failing, it is recommended to replace the hose #12073 every 24 months.
Page 41 Durability of the electrolytic cell Electrode TE – 25 Lifetime of the electrolytic cell is 8000 running hours. The electrodes in the electrolytic cell are made of titanium with a ruthenium and iridium layer. During electrolysis this layer gets consumed. Durability of the electrodes is reduced by the following parameters: •...
Page 42 Error messages Agent Run Out • Check liquid levels on a regular basis, reﬁ ll in time. Dosing Pump does not Dose • Leakage in connection of PE tubes or they are damaged. • Failure of dosing pump. Check whether pump is running. If so, check the hose inside the pump for damage or breakage and replace it, if required.
Page 43 Too Rapid pH Change Too rapid change of pH is usually caused by reﬁ lling water directly to the skimmer. If such rapid change of pH occur, ASIN AQUA Salt stops controlling pH for two hours. This limitation can be manually disabled. After pH has been stabilized or two hours have elapsed, ASIN AQUA Salt changes over to the normal mode.
Page 44 Connection ASIN AQUA Salt to ASIN Salt The ASIN Salt expansion module must be connected to the ASIN AQUA Salt control unit with a cable. To activate the external control, select the EXT mode on the display. up to 10 up to 10 modules modules...
Page 45 Select the EXT mode up to 10 modules Connection cable to ASIN Salt TE 25 – ASIN AQUA Salt TE 25 – ASIN AQUA Salt TE 25 – ASIN Salt TE 25 – ASIN Salt HEATING TO POOL FROM POOL FROM POOL...
Page 48 USER MANUAL ASIN AQUA Salt VS w w w.asekopool.com...
