NIVELCO NITIME JEL-111 User Manual

Thank you for choosing a NIVELCO instrument.
We are sure that you will be satisfied throughout its use.
1. APPLICATION
NITIME time relays are microprocessor controlled units suitable for highly diverse timing tasks. The multiple
functions, the universal power supply and (1-module width) the rail mountable construction ensure universal
usage (automation, lighting, heating, motor and ventilation control).
2. TECHNNICAL DATA
2.1 G
ENERAL DATA
TYPE
Number of functions
Adjustable time ranges
Time setting controls
Reset time
Time deviation
Repeat accuracy
Temperature coefficient
Power supply
Power consumption
Relay
Rated current
Inrush current
Output indication
Output Switching voltage
Switching power
Min. switching power
Electrical lifespan (AC1)
Mechanical lifespan
Electrical connection
Electrical protection
Mechanical connection
Ingress protection
Ambient temperature
Mass
2.4 D
IMENSIONS
64
35
3,4
16
JEL-111
10
0.1 sec ... 10 days
rotary switch, potentiometer
max. 150 msec
5% - mechanical setting
0.2% - set value stability
0.01% /°C at 20 °C
12-240V AC/DC
0.7-3 VA AC, 0.5-1.7 W DC
1xSPDT
16 A AC1
30 A (<3 sec)
multifunctional LED
250 V AC1 / 24 V DC
4000 VA AC1, 384 W DC
500 mW DC
5
0.7x10 switchings
7
3x10 switchings
2
terminal for 2.5 mm wire cross-section
Class II. reinforced insulation
DIN EN60715 rail
IP 20
-20°C ... +55°C
90 g
17,6
14,8
JEL-121
2
0.1 sec ... 100 days
70 g
3. INSTALLATION
NITIME time relays can be mounted on DIN EN 60715 rails.
The device should not be installed in highly electromagnetic
environment. Operating temperature should not exceed the limit of the
specified operation temperature even in conditions such as increased
ambient temperature or continuous operation. The device is
completely electronic. Consider this during the installation.
NITIME
Manufacturer:
NIVELCO Process Control Co.
H-1043 Budapest, Dugonics u. 11.
Tel.: (36-1) 889-0100, Fax: (36-1) 889-0200
E-mail: sales@nivelco.com
www.nivelco.com
2.2 A
CCESSORIES
–
User's manual
–
Warranty Card
–
Declaration of Conformity
2.3 O
RDER CODE
NITIME J E L – 1 1
Type Code
Multifunction 1
Pulse cycler 2
