Slide for midsleeper - White
Assembly Instructions
8507086
- Please keep for future reference
Dimensions
Length - 150cm
Depth - 124cm
Height - 112cm
Weight - 9,5kg
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@fl exa.dk
Issue 1 - 27/06/18
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Home 8507086
Summary of Contents for Home 8507086
- Page 1 Slide for midsleeper - White Assembly Instructions 8507086 - Please keep for future reference Dimensions Length - 150cm Depth - 124cm Height - 112cm Weight - 9,5kg Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 or e-mail: order@fl...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Assemble on a soft level • Be aware of the danger of • Remove all fi ttings from the surface to avoid damaging the young children (under 6) falling plastic bags and separate them unit or your fl...
-
Page 3: Components - Parts
If you have damaged or missing components, Components - Parts call the Customer Helpline: 0045 7668 8055 Please check you have all the parts listed below Slide side x2 Short post x1 (150.8x9.0x2.0cm) (36.8x8.9x2.0cm) No. 12-02015081-20 No. 12-02003681-20 Safety rail 1/2 x2 (112.7x6.5x2.0cm) No. - Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. No. 3901-30020 No. 3901-40035 No.
- Page 5 Assembly Instructions Step 1 Remove the support list (1.) by removing the (b.) fi ttings (a.). (a.) Remove the safety rails (2.) by removing the (b.) fi ttings (b.). (1.) (a.) (2.) (2.) (b.) Step 2 Attach the safety rails (b.) to the ladder side (3.) with fi...
- Page 6 Assembly Instructions Step 3 Attach the short post to the safety rails with assembly screws and confi rmat screw Attach the short post to the bed side (4.) with chipboard screws and cover with cover cap (4.) Step 4 Attach brackets to the slide base with coach...
- Page 7 Assembly Instructions Step 5 Attach the slide with the brackets to the bed side (4.) with chipboard screws Attach support list (1.) to the safety rails bed side (4.) with the fi ttings (a.). (a.) (1.) (4.) Step 6 Attach slide side the short post with chipboard screws...
