Scandinavia - Chest of drawers

Assembly Instructions

Retain these instructions for future reference

Dimensions

Width - 78cm

Depth - 40cm

Height - 71cm

Important

– Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline:

487/7174

476/8654

Sainsbury's Argos

489-499 Avebury Boulevard

Saxon Gate West

Central Milton Keynes

MK9 2NW

03456 400800

Issue 3 - 23/11/2016

Need help?

Do you have a question about the Scandinavia - Chest of drawers and is the answer not in the manual?

Questions and answers

Summary of Contents for Home Scandinavia - Chest of drawers

Page 1 Scandinavia - Chest of drawers Assembly Instructions 487/7174 Retain these instructions for future reference 476/8654 Dimensions Sainsbury’s Argos 489-499 Avebury Boulevard Width - 78cm Saxon Gate West Depth - 40cm Central Milton Keynes Height - 71cm MK9 2NW Important – Please read these instructions fully before starting assembly...
Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Assemble the item as close • Assembly to be carried out by components and tools listed on to its final position (in the same a competent adult only pages 2 and 3.
Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the panels listed below Top (78 x 40cm) Back right leg Small drawer front x 2 (67 x 3.2cm) (32.4 x 14cm) Large drawer front x 3 (66.6 x 14cm)
Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Cam 12 mm x 30 Locking pin 24 mm x 30 Dowel 30 mm x 4 Cam 15 mm x 8...
Page 5 Components - Key Diagram Left side Right side Function of Cam and Locking Pin...
Page 6 Assembly Instructions Step 1 Inserting the dowels and mounting the locking pins to the legs. Insert the dowels into the holes indicated on the legs Screw the locking pins into the holes indicated on the legs Note: Insert locking pins E as far as shown.
Page 7 Assembly Instructions Step 3 Inserting the dowels and mounting the locking pins to the assembled side. Insert the dowels into the holes indicated Screw the locking pins into the holes indicated on the legs Note: Insert locking pins as far as shown. Do not over tighten.
Page 8 Assembly Instructions Step 6 Adding the plinths to the left side. Fit the left side onto the plinths Note: See page 5 Left side “Function of cam and locking pin“. Rebate=Back Place the cams into the holes indicated on the plinths To tighten cams: Turn to the right using a...
Page 9 Assembly Instructions Step 8 Attaching drawer runners to the divider. Fix the drawer runner to the divider left side and the drawer runner the divider right side with screws into the holes indicated on the divider Front edge Step 9 Mounting the locking pins to the top.
Page 10 Assembly Instructions Step 11 Rebate=Back Assembling the top to the sides. Attach the top onto the sides Note: See page 5 “Function of cam and locking pin“. Place the cams into the holes indicated on the sides To tighten cams: Turn to the right using a screwdriver.
Page 11 Assembly Instructions Step 12 Rebate=Back Adding the back to the carcass. Carefully turn the assembled piece of furniture, with the back to the top. Place the back into the Right side rebate of the top the side Ensure thet there is no gap between the side back, not between the top and the back.
Page 12 Assembly Instructions Step 13 Large drawer assembly. a: Fix the drawer sides to the drawer back using screws b: Slide the drawer bottom into the grooves of the drawer back c: Screw the locking pins into the holes indicated on the drawer front Note: Insert locking pins as far as shown.
Page 13 Assembly Instructions e: Fix the knobs to the drawer front using screws f: Fix the drawer runners to the drawer sides using screws through the holes indicated. Repeate with remaining drawer.
Page 14 Assembly Instructions Step 14 Small drawer assembly. a: Fix the drawer sides to the drawer back using screws b: Slide the drawer bottom into the grooves of the drawer back c: Screw the locking pins into the holes indicated on the drawer front Note: Insert locking pins as far as shown.
Page 15 Assembly Instructions e: Fix the knob to the drawer front using screw f: Fix the drawer runners to the drawer sides using screws through the holes indicated. Repeate with remaining drawer. ф Step 14 Adding the drawers to the carcass. Slide the drawers onto the drawer runners.
Page 16 Reposition drawer chest and fix wall strap using screw Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Domestic address or Home Retail Group Plc address.
Page 17 Care & Fitting: From time to time check Safety: Always check the fitting the fitting to ensure the wall plugs and location to ensure your safety Maintenance in and around the home. or screws do not become loose.
Page 18 Dear Customer Please note that the product you have purchased is a natural living timber. Just like nature itself, wood varies in shape and colour. Knots, vein patterns, resin pockets and colour differences contribute to giving the piece of furniture its beauty and form - a natural part of solid wood.
