Sandstrom SSBKIT20 Instruction Manual

Soundbar Mount
Starter Kit
Instruction Manual
SSBKIT20
Thank you
for purchasing your new product.
Please follow this quick start guide for a successful rst time set up.
Read all the safety instructions carefully before use and keep the quick start guide
for future reference.
Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories.
With over 1 million spares and accessories available we can deliver direct to your door
the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers
only) Calls charged at National Rate.
This Mount comes with a 3-year guarantee. If the product fails whilst in use for its
intended purpose, please return it, along with your receipt, for a full refund or
replacement. Please follow the instruction manual carefully when installing this device.
Currys Group Limited (co. no. 504877)
Omni Park SC, Santry, Dublin 9, Republic of Ireland
1 Portal Way, London, W3 6RS, UK
EU Representative
Currys Ireland Limited (259460)
3rd Floor O ce Suite
SAFETY
KG
Max loading capacity
6.8 kg
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• Assembly is required. Installation must be carried out by quali ed personnel only. Incorrect assembly can result in
severe personal injury and property damage. This Soundbar Mount is only designed to mount soundbars below the
television.
• If the TV bracket does not include TV interface spacers, do not use the TV interface spacers included with this
Soundbar Mount. If the TV bracket has built-in or integrated spacers, do not use this product.
• It is the installers' responsibility to verify that the wall will safely support the total load of the TV, TV bracket, soundbar
and the Soundbar Mount.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation. Make sure your TV
and any accessories you plan to use do not exceed the maximum load limit of your TV Mount.
• This Soundbar Mount should only be installed into TV interface bracket slots or holes that are less than 11 mm wide;
do not over-tighten washer.
• Keep this instruction manual for future reference.
• For indoor household application only.
UNPACKING
IB-SSBKIT20-211026V3
x 2 x 2 x 2 x 2
A1 A2 A3 A4
Screws for TVs with a Flat/Unobstructed Back
x 4 x 4 x 4
B1 B2 B3 B4
M4 × 16mm M5 × 16mm M6 × 16mm M6 × 25mm
Screws for TVs with Irregular/Obstructed Backs
x 4 x 4 x 4
B6 B7 B8
M4 × 40mm M5 × 40mm M6 × 40mm M6 × 50mm
TV Screw Washers
x 4
B12
Ø4, Ø5/Ø6, Ø8
x 4 x 4
B5
M8 × 20mm
x 4 x 4 x 4
B9 B10 B11
M8 × 40mm
