Graphical Command Center
3.8

Multi-Module System Load Screen

The Multi-Module System Load screen is accessed from the system mimic diagram. The screen displays infor-
mation on kW, %kW and %kVA of all the UPS's configured, and the overall system measurements. See Figure 3-8.
Figure 3-8: M-M System Load Screen.
14:47:58
Setu p
Trend
ALARMS
System
Load
Protected
UPS 1
Load
Protected
UPS 2
Load
Protected
UPS 3
UPS
Offline
page 3 —10
UPS 1 load
KW 200
% KW Load 50
% KVA Load 50
UPS 2 load
KW 200
% KW Load 50
% KVA Load 50
UPS 3 load
KW ???.?
% KW Load ???.?
% KVA Load ???.?
GCC Screens
System load
Voltage
A-B 480 V
B-C 480 V
A-C 480 V
Current
A 600 A
B 600 A
C 600 A
Frequency 60.0 Hz
KW 400
KVA 500
pf 0.8
% KW Load 100
% KVA Load 100
