INSTRUCTION MANUAL
S a f e t y P r ec a u ti o n s ・ ・ ・・・ ・・・・ ・ 1
1 ． Overview ・・・・・・・・・・・・・・・ 2
2 ． Specifications ・・・・・・・・・・・・ 2
3 ． Part Names and Functions ・・・・・・・ 3
4 ． Installation ・・・・・・・・・・・・・・ 4
6 ． Wiring ・・・・・・・・・・・・・・・・ 7
7 ． Operation ・・・・・・・・・・・・・・ 8
8 ． Sensitivity adjustment ・・・・・・・・ 12
9 ． Maintenance ・・・・・・・・・・・・ 12
10 ． Troubleshooting ・・・・・・・・・・・・ 13
※ An operator should read carefully this instruction manual and conduct
correct handing.
1-8-18 Norimatsu-Higashi,Yahatanishi-ku,Kitakyushu 807-0837 Japan
Phone No.(8193)691-3731 Fax No.(8193)691-3735
http://www.matsushima-m-tech.com
E-mail sales@matsushima-m-tech.com
FOR
FLOW MONITOR
TYPE
MWFM-AN-01
Contents
TMWFM-001E
Rev2:Nov.26,2016
Advertisement
Table of Contents
Related Manuals for Matsushima MWFM-AN-01
Summary of Contents for Matsushima MWFM-AN-01
-
Page 1: Table Of Contents
TMWFM-001E Rev2:Nov.26,2016 INSTRUCTION MANUAL FLOW MONITOR TYPE MWFM-AN-01 Contents S a f e t y P r ec a u ti o n s ・ ・ ・・・ ・・・・ ・ 1 1 ． Overview ・・・・・・・・・・・・・・・ 2 2 ． Specifications ・・・・・・・・・・・・ 2 3 ．... -
Page 2: Safety Precautions
Cause for any peripheral equipment or device. Accident beyond control and force majeure (fire, earthquake, flood, riots, etc.). Lack of instructions to MATSUSHIMA for information or safety requirements that can be predicted only by customers’ side. This warranty conditions do not limit customers’ legal right. -
Page 3: Overview
This device outputs an electrical signal of the flow rate measured relative to the given measuring span, which can be freely set. 2. Specifications 2-1. Model MWFM-AN-01 2-2. Supply voltage 80 VAC to 240 VAC at 50/60 Hz 2-3. Frequency 24.15 GHz... -
Page 4: Part Names And Functions
3. Part Names and Functions Fig. 1 shows the panel surface as it looks when the housing cover is removed. Lead Outlet Side Fig. 1 Panel Surface Name Function Display the measurement results (as a percentage of the set 7 segment LEDs value). -
Page 5: Installation
4. Installation The mounting part of the Flow Monitor is a G1 screw. Install the Flow Monitor either horizontally or vertically with the use of the G1 locknut and packing provided with the device. If there is any concern about the screw loosening, apply liquid gasket. If the Flow Monitor is to be used outdoors, attach a rain cover or similar protective cover to minimize the entry of rain water. -
Page 6: Flow Monitor Installation Conditions
<How to install so that adhesion and accumulation of transported materials is minimized> Install as shown in Fig. 4, so that the transmitting and receiving surface is flush with the container wall (tube, pipeline, etc.). If installation shown above is not possible, install a shield made of a material such as low-permittivity Teflon or ceramics to allow microwave transmission. - Page 7 5-2. Pneumatic transportation Applications Flow Monitor Length: At least 10 times Length: At least 5 times the pipe diameter the pipe diameter Air flow Metal piping Important:Metal pipes must be used for the equipment piping. ！ Be sure to secure the required heights for installation. Fig.6 Installation on Pneumatic Transportation Equipment 5-3.
-
Page 8: Wiring
6. Wiring • Use a cable of 1.25 mm to 2 mm diameter, and suitable for the environmental conditions in which it is to be used. • Connect wires only to the AC (power supply) and to 4 mA to 20 mA (current output) terminals. Caution: Do not connect unused terminals, as this may result in a Flow Monitor failure. -
Page 9: Operation
7. Operation The display window on the Flow Monitor panel functions as a measurement display window (for checking measured values) and a setting window (for entry of parameters), and must be operated in accordance with each situation. The window operation procedures and indications on display are described below. <Measurement Display Window>... - Page 10 7-1. Setting Zero and Span There are two methods, automatic and manual, to enter and set the zero and span values: Use either method according to the situation. 7-1-1. Manual Entry and Setting Method (a) Setting Zero Check and record the value of the arithmetic processing result indicated under no-load conditions (nothing is flowing inside).
- Page 11 7-1-2. Automatic Entry and Setting Method With the automatic entry and setting method, data measured within the sampling time (which has been set to any desirable value within the setting range) is calculated. The zero and span settings are automatically entered and stored to reflect the calculation results. Note: The default setting for the sampling time is one minute.
- Page 12 7-2. Setting the Moving Average (Number of Times the Moving Average is Taken) Displays measurement results. (Flow rate in % is shown.) Press [MOD] With the moving average setting on display, enter a value to be set. three times. The numeric character which is flickering can be changed. Use [ ] to change the flickering position, [ ] to change the numeric character, and [STO] to store the entered value.
-
Page 13: Sensitivity Adjustment
8. Sensitivity adjustment Flow Monitor has a sensitivity selector function. When the signal does not change in proportion to the increase/decrease of flow amount in the initial setting, change the selector switch as shown below and make a measurement again. Caution: ！... -
Page 14: Troubleshooting
10 or less. Power is not being supplied. Supply power. Cable disconnection Repair disconnected sensor does section. operate. Device failure Contact Matsushima. Proper adjustment been zero span completed. parameters. Sensor malfunction Material is adhering to the transmitting Clean the transmitting surface.
