radiance TACM-24 Owner & Operator Instruction Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

OWNER & OPERATOR
INSTRUCTION MANUAL
TACM-24
Model No.
TACM-36
TACM-48
THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL GAS EQUIPMENT WHO SHOULD
PERFORM THE INITIAL FIELD START-UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.
POST IN A PROMINENT LOCATION: THE INSTRUCTIONS ARE TO BE FOLLOWED IN THE EVENT WHEN SMELL
OF GAS IS DETECTED. THIS INFORMATION CAN BE OBTAINED FROM THE LOCAL GAS SUPPLIER.
IMPORTANT
In the event a gas odor is detected, shut down units at main shutoff valve and contact the local gas company or gas supplier for service.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or other appliance.
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury, or death. Read the installation,
operating and maintenance instructions thoroughly before installing or servicing this equipment.
TASM-24
TASM-36
IMPORTANT SAFETY NOTICE
www.turboairinc.com
For service contact:
German Knife Inc.
1-800-500-3519
www.turboairinc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TACM-24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for radiance TACM-24

Summary of Contents for radiance TACM-24

  • Page 1 For service contact: German Knife Inc. 1-800-500-3519 www.turboairinc.com OWNER & OPERATOR INSTRUCTION MANUAL TACM-24 TASM-24 Model No. TACM-36 TASM-36 TACM-48 IMPORTANT SAFETY NOTICE THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL GAS EQUIPMENT WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.
  • Page 2 TABLE OF CONTENTS PAGE INSTALLATION OPERATING INSTRUCTIONS MAINTENANCE WARRANTY German Knife, Inc. 4184 E. Conant St., Long Beach, CA 90808 Phone: 800-500-3519 Fax: 310-900-1066 www.turboairinc.com SHIPPING DAMAGE CLAIM PROCEDURE The equipment is inspected & crated carefully by skilled personnel before leaving factory. The transportation company assumes full responsibility for safe delivery upon acceptance of this equipment if shipment arrives damaged;...
  • Page 3 INSTALLATION UNPACKING: 1. Remove appliance from container. 2. Remove all protective packaging material. 3. Retain container and packaging material until the appliance is operated and found in good condition. 4. Check appliance for any shipping damage. If appliance shows any external or internal damages, promptly inform dealer/distributor where you bought your appliance.
  • Page 4 INSTALLATION The installation must conform with codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA54, or the Natural Gas and propane Installation Code, CSA B149.1, as applicable, including: 1. The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 PSI.
  • Page 5 OPERATING INSTRUCTIONS PRIOR TO LIGHTING, CHECK ALL GAS CONNECTIONS FOR LEAKS!!!!!! LIGHTING INSTRUCTIONS: Turn all burner valves to “OFF” position (bottom). Turn on the main gas supply to the unit. Pilots are located on the top of the salamander and cheesemelters. Turn pilot valve(s) adjusting screw counterclockwise, then light standing pilot and adjust the pilot flame to approximately ¼”...
  • Page 6 The gas supply (service) line must be the same size or greater than the inlet line of the appliance. Radiance equipment’s use a ¾” NPT inlet. Sealant on all pipe joint must be resistive to LP gas. MANUAL SHUT-OFF VALVE:...
  • Page 7 MAINTENANCE CAUTION All cleaning and maintenance should be done when the unit is cool and the gas supply turned off by turning off the manual shutoff valve. At least on weekly basis, the following items must be inspected: ● Clean area surrounding the unit of all combustible material, gasoline and other flammable vapors and liquids.
  • Page 8 3 days from receiving. Any part covered under this warranty that is found by German Knife / Radiance to have been defective within the above time period is limited to the repair or replacement, including labor charges, of defective parts or assemblies.
