WAPB1xx WiFi access point Operation manual Version 1.04 wapb1xx_g_en_104...
Page 2
WAPB1 AMiT, spol. s r. o. does not provide any warranty concerning the contents of this publication and reserves the right to change the documentation without obligation to inform any body or authority about it. This document can be copied and redistributed under following conditions: 1.
WAPB1 1. Introduction WAPB1xx is a family of WiFi access points for rolling stock, used for providing connection between WiFi devices and local Ethernet network of the train. Hereinafter in the text it will be referred to as access point.
WAPB1 2. Technical parameters Processor core Intel Atom E3815 1.46 GHz, 2 GB DDR3L, 4 GB eMMC FLASH 1 × to 2 × Ethernet Number of connectors 1 × to 2 × Number of interfaces 1 × LAN Interface configuration 0 × to 1 × switch Galvanic isolation Yes, 1000 V AC / 1 minute Data transmission rate...
Page 8
WAPB1 1 × Service USB Quantity USB version USB 2.0 Operation indication Galvanic isolation Data transmission rate 12 Mbps / 480 Mbps Recommended cabling Shielded USB cable Maximum cable length Connection point USB connector type B, socket 1 × Service HDMI Quantity Operation indication Galvanic isolation...
Page 9
WAPB1 Dangerous Unit overall mass of plastics Max. 181.3 g materials Included mass of self-extinguishing Max. 181.3 g plastics Device does not contain PUR, PVC, Asbestos Device conforms 2011/65/EU (ROHS) 1907/2006EU (REACH) -40 °C to 70 °C Temperatures Operating temperature range -40 °C to 70 °C Storage temperature range Others...
WAPB1 2.1. Possible variants Access point WAPB1xx can be supplied in the following variants that differ in power supply voltage and number of peripherals. Name Ethernet WiFi WiFi a/b/g/n a/b/g/n/ac 1 × 2 × 0 × WAPB1C101 2 × 2 ×...
WAPB1 2.3. Recommended drawing symbol Following drawing symbol is recommended for access point. Variants of drawing symbol for different variants are available on AMiT website. WAPB1C201 X1 - PWR R-SMA WiFi1 ANT1 R-SMA WiFi1 ANT2 DIO0 DIO1 M12 8-pin, X-coded...
WAPB1 2.4. Block diagram Figure shows drawing symbol for WAPB1xx family. This drawing symbol is particularly for WAPB1C201. Power WiFi WiFi WAP82574I + 3V3 + 3V3 + 3V3 WiFi 1 WiFi 2 PCIe Power input HDMI Main CPU Temperature RS232...
WAPB1 3. Product marking WRTB1xx is fitted with producer type label. Location of labels, see Fig. 4 - Location of label on device cover. Fig. 4 - Location of label on device cover Legend Number Description Type label wapb1xx_g_en_104 14/36...
WAPB1xx TYPE: xxxxxxx MAC X2 xx-xx-xx-xx-xx-xx MAC X3 xx-xx-xx-xx-xx-xx POWER 24 V DC / 0.5 A WEIGHT 1.5 kg TEST OK-JE HiPot HiPot - OK DATE 21.12.2015 Fig. 5 - Example of AMiT type label 15/36 wapb1xx_g_en_104...
WAPB1 4. Conformity assessment Providing, that access point is correctly used, it complies with the requirements of Czech governmental decree NV616/2006. The conformity assessment has been carried out in accordance with harmonized standard EN 50121-3-2:2006. Tested in accordance Type of test Classification with standard EN 55011:2009...
WAPB1 4.1. Other tests Access point has been assessed and approved for use in railway applications according to standards: Tested in accordance Type of test Result with standard Railway applications – Electronic EN 50155:2007 Complies equipment used on rolling stock Railway applications –...
WAPB1 5. Processor modules 5.1. Master processor module For master CPU, access point uses a processor module with CPU Intel Atom. The core contains processor Intel® Atom™ E3815 2 GB DDR3L, 4 GB eMMC. Core For more details see the MSC Q7 module datasheet on manufacturer's website (see Related documentation).
WAPB1 6. Power supply Access point power supply connector contains power supply inputs and two digital inputs / outputs. Voltage level of power supply and digital inputs / outputs corresponds with power supply voltage 24 V DC. Fig. 6 - Power supply and digital inputs / outputs connector Wiring Connector type: WAGO 769-666 of power...
WAPB1 6.1. Computer start up and shut down Access point is turned on after connection of power supply to Vcc and GND terminals and activation by SB signal. 6.1.1 SB input is active Power ON In terms of data consistence, the unit's start-up is not critical and can be realized either by coincident connecting of power supply voltage to Vcc and SB terminals, or by connecting the voltage first to Vcc terminal and then to SB, or vice versa.
WAPB1 Incorrect shut down process is when the application doesn’t turn off during toff2. toff2 Fig. 8 - Computer start up and shut down 6.1.2 SB input is not used Power ON In terms of data consistence, the unit's start-up is not critical and can be realized either by coincident connecting of power supply voltage to Vcc and SB terminals, or by connecting the voltage first to Vcc terminal and then to SB, or vice versa.
WAPB1 7. Digital inputs / outputs Access point is equipped with two input / output pins, located on power supply connector. Both are galvanically separated from the access point electronics. Pins can be used as an inputs or outputs with backward reading, bun never as input and output simultaneously.
WAPB1 8. Communication lines and peripherals Access point contains following communication interfaces and peripherals: ▪ Ethernet ▪ WiFi ▪ USB ETHERNET ETH LED WIFI LED WIFI SYS LED POWER Fig. 10 - Location of peripherals on the front panel 8.1. Ethernet Access point is equipped with one or two (depending on variant) independent Ethernet interfaces, each with its own MAC address.
WAPB1 8.1.3 Ethernet line state indication Indication of Ethernet line state is provided by LEDs, located on the right from M12 connector. Fig. 14 - Location of Ethernet LED indicators Meaning Status Meaning of LED Ethernet is inactive Ethernet connected Blink Running communication No communication...
WAPB1 Configuration Theoretical Real transmission speed transmission speed SISO 1 Mbps to 54 Mbps 0.3 Mbps to 18 Mbps MIMO 300 Mbps 100 Mbps Transmission can be secured by WEP, WPA, WPA2 or 802.1x technologies. 8.2.2 Connection of antennas For good quality of signal transmitted between access point and counterpart device it is necessary to maintain certain rules, also it greatly depends on type of used antenna.
WAPB1 9. Service peripherals Access point contains following service interfaces and peripherals: ▪ USB ▪ HDMI ▪ RS232 Service peripherals are used for device diagnostics and service interventions. Access point is equipped with USB, RS232 and HDMI service peripherals used by operator or by maintenance company for setup and configuration.
WAPB1 9.1.3 RS232 Access point contains one RS232 interface. The line is not galvanically separated, i.e. it is galvanically connected with chassis. Line is used as service interface. Fig. 18 - RS232 connector Connector Connector type: D-sub DE-9, plug wiring Signal Signal type on connector –...
WAPB1 10. Indication elements 10.1. System LEDs State indication is provided by LED SYS located on front panel. Fig. 19 - System indication Meaning of Status Meaning Power is OFF, or system is not functional System is launched – Reserved for future use 29/36 wapb1xx_g_en_104...
The wrapped AP is stored in a paper box. Package dimensions are listed in chapter Technical parameters. Label Sticker on the box contains following information: Item Description TYPE WAPB1xx NETTO 1.5 kg BRUTTO 1.62 kg 1 pc Serial number –...
WAPB1 12. Storing To prevent damage of the device, follow these rules. Product Product in original packaging must be stored under the conditions specified in in a package chapter Technical parameters. Product must not come into contact with water, oil or any other liquids that can damage the packaging. Box with the device can be stored in any position.
WAPB1 13. Mounting 13.1. Mounting instructions Access point can be mounted in any position. To ensure proper cooling and access to the access point we recommend to keep a free space of minimum 70 mm sidewise and 100 mm from the upper surface of the radiator. Alternatively, cooling can be arranged by additional means (fans, another measures).
WAPB1 13.3. Mounting apertures Access point is intended for mounting on the baseplate by means of four M5 bolts with low profile bolt heads. Four holes located in corners with diameter of 5.5 mm are used for mounting. 107,8 Fig. 21 - Mounting apertures All dimensions are stated in mm.
WAPB1 15. Maintenance Cleaning Time after time, with regard to way of using it is necessary to remove dust from device. The equipment can be cleaned by dry soft brush or vacuum cleaner, only when turned-off and disassembled. 35/36 wapb1xx_g_en_104...
WAPB1 16. Waste disposal Electronics The disposal of electronic equipment is subject to the regulations on handling disposal electrical waste. The device must not be disposed together with common public waste. It must be delivered to places specified for that purpose and recycled. wapb1xx_g_en_104 36/36...
