User Manual for LCO-i100 Console
www.levitronix.com
®
PuraLev
Console
LCO-i100
®
®
PuraLev
i30SU/MU, PuraLev
i100SU/MU
®
PuraLev
i600SU
USER MANUAL
®
This manual contains information necessary for the safe and proper use of the PuraLev
LCO-i100
Console. Included are specifications for the standard configurations and instructions regarding its use,
installation, operation, adjustment, inspection and maintenance. For detailed description of the menu
structure and the configuration possibilities with the touch screen user interface the console software
manual PL-4067-00 can be consulted. For all in this manual revision described configurations and features
the console software V1.04 R16 or higher is needed. For special configurations of the system refer to
accompanying information. Please familiarize yourself with the contents of the manual to ensure the safe
and effective use of this product. After reading this manual, please store the manual where the personnel
responsible for operating the pump system can readily refer to it at any time.
First Release: 09-Feb-2017
PL-4066-00, Rev03, DCO# 21-230
Last Update: 07-Oct-2021
Advertisement
Table of Contents
Related Manuals for Levitronix PuraLev LCO-i100
Summary of Contents for Levitronix PuraLev LCO-i100
- Page 1 User Manual for LCO-i100 Console www.levitronix.com ® PuraLev Console LCO-i100 ® ® PuraLev i30SU/MU, PuraLev i100SU/MU ® PuraLev i600SU USER MANUAL ® This manual contains information necessary for the safe and proper use of the PuraLev LCO-i100 Console. Included are specifications for the standard configurations and instructions regarding its use, installation, operation, adjustment, inspection and maintenance.
-
Page 2: Table Of Contents
User Manual for LCO-i100 Console www.levitronix.com Table of Contents SAFETY PRECAUTIONS..................................3 SPECIFICATIONS ....................................4 Specification of Console Components ............................4 System Overview and General Specification ..........................7 2.2.1 Basic Stand-Alone System Configuration................................7 2.2.2 Extended System Configuration ..................................8 General Environmental Conditions..............................9 Basic Dimensions of Console ................................9 ENGINEERING INFORMATION ................................10... -
Page 3: Safety Precautions
Concerning safety precautions for motor, pump and sensors refer to the corresponding manuals. CAUTION ® Do not under any circumstances open the console enclosure. Levitronix does not assume responsibility for any damage, which occurs under such circumstances. -
Page 4: Specifications
Table 2: Specification of standard pump motors and single-use pump heads compatible with LCO-i100 console. ® ® Note 1: Gamma irradiation option available. Note 2: See Levitronix technical brochures of PuraLev i30SU/i30MU/100SU/i100MU/600SU for detailed specifications. Note 3: Sterile fitting options available. - Page 5 LFS-03SU-Z (0.8 lpm) 100-30375 Triclamp 3/8” LFS-03SU-Z-SC1 (0.8 lpm) 100-30418 Triclamp 3/8” LFS-06SU-Z (8 lpm) 100-30377 ® See Levitronix technical brochure Triclamp 3/8” LFS-06SU-Z-SC1 (8 lpm) 100-30394 Polypropylene (FDA, USP Class of LFS-SU single-use sensor series ® Triclamp 1/2” LEVIFLOW...
- Page 6 User Manual for LCO-i100 Console www.levitronix.com Pos. Component Article Name Part # Characteristics Special Feature / Description ® LEVIFLOW Cable Jacket Material LFI-C.1-30 (3m) 190-10308 Main Purpose Connection between LFSC-D and LFS-SU flow sensors and console. Interconnect Cable IP Cable Signal Cable Jacket Material ICS-3.1-30 (3m)
-
Page 7: System Overview And General Specification
User Manual for LCO-i100 Console www.levitronix.com 2.2 System Overview and General Specification 2.2.1 Basic Stand-Alone System Configuration Figure 4 ® With the stand-alone pump system configuration, as illustrated in for the PuraLev i30 and i100 and for the ® ®... -
Page 8: Extended System Configuration
User Manual for LCO-i100 Console www.levitronix.com 2.2.2 Extended System Configuration Figure 6 illustrates the extended capabilities of the console for advanced fluid handling applications. The connection of up to 3 single-use pressure sensors enables pressure monitoring. A standard interface for a temperature sensor facilitates temperature monitoring. -
Page 9: General Environmental Conditions
User Manual for LCO-i100 Console www.levitronix.com 2.3 General Environmental Conditions Usage Indoor (Laboratory, Industrial environments) Altitude Up to 2000 m Operating ambient temperature 10 to 40 °C Storage ambient temperature (Extremes for Transportation) -20 to 70 °C 15 – 95% (non-condensing) Operating humidity range (relative humidity) 15 –... -
Page 10: Engineering Information
User Manual for LCO-i100 Console www.levitronix.com 3 Engineering Information 3.1 IP Rating The console is tested to meet IP65. Note: Units older than 2018/19 have IP40. These older units can be identified by having only 2 pressure inputs (instead of 3 pressure inputs) on the connector back plane. -
Page 11: Electrical Installation
RS485 bus with 24 VDC supply. LFSC-iX. ® LAN Interface TCP/IP Modbus For connection to OPC devices or Levitronix Service Software. USB Interface Connection for a USB stick. USB access for data debugging and software update through a USB stick. -
Page 12: Plc Interface
1: Wires of compatible cables: ICS-2.1-xx 2: Designations are for standard firmware. Note 3: Not available on units older than 2018/19. Example of User Interface Levitronix Console PLC Inter face Circuit 24 VDC 11: Analog Out High Pin 4..20 mA 12: Analog Out Low Pin 33-750 Ω... -
Page 13: Analog Input With 24Vdc Supply
1: Depends on used cable. 2: Designations for standard firmware. 3: Models older than 2018/19 it is 350 mA. 4: Not available on models older than 2018/19. Levitronix Console Typical Sensor Analog In / 24 VDC (4-20mA Signal Output Interface and 24 VDC Supply) max. -
Page 14: General Installation Instructions
User Manual for LCO-i100 Console www.levitronix.com 4.2.4 General Installation Instructions WARNING Hazardous voltage may be present. Always isolate the console from the mains power supply before performing any changes to the connections, the positioning and before doing other maintenance activities. -
Page 15: Operation
User Manual for LCO-i100 Console www.levitronix.com 5 Operation The console contains a self-explaining touch screen user interface with various menus to operate, configure and troubleshoot the system. In this section only the basic functions for a safe usage are explained. For more details consult the LCO Console Software Manual PL-4067-00. -
Page 16: Auto-Resume Feature
The LCO-i100 console software offers the possibility to update itself as well as the underlying components © firmware versions. A new software/firmware package will be provided by Levitronix as a single file with the file ending *.levi. Follow the procedure below for an update: 1. -
Page 17: Maintenance
If problems or failures can’t be solved with the help of the notification on the console screen, it is recommended to capture a data log during operation, as described in LCO Console Software Manual PL-4067-00, until the ® failure appears and then send the data log file to the Levitronix Technical Service Department or the appropriate key account manager. -
Page 18: Appendix
Electrical equipment for measurement, control and laboratory use – EMC requirements IEC 61326-1 9.1.2 IECEE CB Safety Certification ® The Levitronix LCO-i100 Console is 3 party tested and certified by Electrosuisse following the IECEE CB Scheme according to the following safety standards: IEC61010-1 Safety requirements for electrical equipment for measurement, control and laboratory use. -
Page 19: Symbols And Signal Words
User Manual for LCO-i100 Console www.levitronix.com 9.2 Symbols and Signal Words Symbol / Description Type Source Signal Word Indication of an imminently hazardous situation that, if not DANGER avoided, will result in death or severe injury. Limited to the Signal word...
