- Page 1 Owners Manual HV-3C HV-3D High Voltage Microphone Preamplifiers Millennia Music & Media Systems...
- Page 2 HIGH RESOLUTION GAIN CONTRO 6 PHANTOM POWER SELECT SWITCH6 HIGH VOLTAGE SELECT SWITCH ... 6 SIGNAL INDICATORS ....6 POWER SWITCH ......6 HV-3 SERIES PREAMP GENERAL SPECIFICATIONS WORLD WIDE WARRANTY ..8 Millennia Media HV-3C and HV-3D 041722js page 2 of 8...
- Page 3 See “Rear Panel” instructions for proper fuse requirements. Note that since 2017, HV-3C and HV-3D preamplifiers have been shipping with switch-mode power supplies. These SMPS's detect mains voltages (90VAC to 243VAC) and adapt automatically -- no need to manually change the fuse block voltage setting.
- Page 4 The HV-3 series preamp enclosure measures 19" wide x 1.75 (HV-3C) or 3.5” (HV-3D) high x 13" deep and is designed for mounting into a standard 19" equipment rack. If the HV-3 series preamp is mounted in a road case or other rack which is prone to strong vibration or shock, it is recommended that the rear of the HV-3 series preamp be supported or otherwise reinforced to withstand such conditions.
- Page 5 Provides +48V Note that since 2017, HV-3C and HV-3D Phantom powering. Standard input impedance is preamplifiers have been shipping with switch-mode approximately 6,200 ohms. Pin 1 is ground. Pin 2 is power supplies.
- Page 6 AC line power on and off. When LED is insert or extract mic cables from the HV-3 illuminated, shows that the HV-3 series preamp unit series preamp when phantom power is is powered up and active. active. Millennia Media HV-3C and HV-3D 041722js page 6 of 8...
- Page 7 Selectable: 90-243 V ac, 50/60 Hz Dimensions/Shipping Weight HV-3C 19” W x 1.75” H x 13” D, 15 lbs. HV-3D 19” W x 3.5” H x 13” D, 23 lbs. Millennia Media, SPC reserves the right to change specifications, delivery and pricing without notice...
- Page 8 Vacuum tube and bulb failures are not covered under warranty. Shipping Millennia Media HV-3C and HV-3D 041722js page 8 of 8...
