Summary of Contents for Marmitek 300

  • Page 1 20129_20060817_UG_scart300 SCART INVISIBLE SCART 300 20129 / 20060817 - INVISIBLE SCART 300™ ALL RIGHTS RESERVED MARMITEK © 2006 26-09-2006 11:02 Pagina 1 USER MANUAL GEBRAUCHSANLEITUNG 11 GUIDE UTILISATEUR MODO DE EMPLEO MANUALE D’ISTRUZIONI 35 GEBRUIKSAANWIJZING ™...
  • Page 2: Table Of Contents

    Because of its compact design, the Invisible Scart 300™ looks smart in combination with a flat screen (LCD, plasma TV), but it can be used with any TV with a scart connection.
  • Page 3: Set Contents

    Connect the RCA/RCA cable to the yellow, red and white connections on the scart/scart RCA adapter. See image 1 for more details. Switch the channel selector [A] (A-B-C-D) to A. 26-09-2006 11:02 Pagina 4 GIGAVIDEO TRANSMITTER SCART/SCART RCA ADAPTER ORIGINAL SCART CABLE Image 1 TO A/V DEVICE TO TV MARMITEK...
  • Page 4: Installing The Receiver

    [K] at the receiver. Extend the stick antenna [J] on the side. Connecting the Invisible Scart 300™ transmitter to multiple devices: If you have multiple A/V devices, these are proba- bly all connected to your TV in series. To be able to transmit the signals of e.g.
  • Page 5: Installing The Ir Extender

    IR LEDs, don’t remove them! 7. INSTALLING THE INVISIBLE SCART 300™ TO YOUR PC. The Invisible Scart 300™ should be connec- ted to the ‘TV-out’ or ‘Video-out’ of your PC. This connection can usually be found on the graphics card. The signal you should offer is a so-called ‘composite video signal’,...
  • Page 6: Using The Invisible Scart 300

    Switch the TV connected to the receiver to the correct scart IN. Usually this means pres- sing the 0 or A/V button. You should immediately get an image. The TV should not have to search for channels with the Invisible Scart 300™. Because of the high frequency, the signal is slightly direction sensitive. The transmitter’s antenna has been designed in such a way that it can be turned into different directions.
  • Page 7 Does the Invisible Scart 300™ cause a conflict with my wireless network (WLAN)? Both systems use the same frequency band (2.4GHz). Some interference may occur. The Invisible Scart 300™ can use different channels within the frequency band (A, B, C, D). Choose the channel that produces the least interference.
  • Page 8: Technical Data

    Marmitek Flat TV Link 4 The Flat TV Link 4 gives you the opportunity to connect all types of A/V equipment to your Scart 300™ transmitter or your TV screen, retaining signal quality. For more information go to: www.marmitek.com. Marmitek EasyControl 8™ or Marmitek EasyTouch35™...
  • Page 9 For more detailed information about the disposal of your old equipment, please contact your local authorities, waste disposal service, or the shop where you purchased the product. 26-09-2006 11:02 Pagina 10 MARMITEK...
  • Page 10: Einführung

    11. Zusätzlich erhältlich. _____________________________________________________________________________________17 1. EINFÜHRUNG. Herzlichen Glückwunsch zum Erwerb des Marmitek Invisible Scart 300™. Mit diesem Gerät können Sie Ihren Fernseher drahtlos an Ihr A/V Gerät anschließen, wie z.B. Ihren Videorekorder, DVD-Player, DVD- Rekorder, Satellitenempfänger, Set Top Box, PC usw. Hiermit haben Sie eine ideale Lösung, wenn sie Ihr...
  • Page 11: Verpackungsinhalt

    Anschlussbuchse des Scart/Scart RCA Kabel (Chinch) Adapters an. Sehen Sie Abbildung 1 für weitere Details. Stellen Sie den Kanalschalter [A] (A-B-C-D) auf A. 26-09-2006 11:02 Pagina 12 GIGAVIDEO SENDER SCART/SCART RCA KABEL (CHINCH) ADAPTER URSPRÜNGLICHES SCART-KABEL Abbildung 1 ZUM A/V GERÄT ZUM TV MARMITEK...
  • Page 12: Anschließen Des Empfängers (Receiver)

    Empfänger. Klappen Sie die sich an der Seite befindende Stabantenne [J] hoch. Anschließen des Invisible Scart 300™ Senders an mehrere Geräte: Wenn Sie mehrere A/V Geräte haben, so sind diese wahrscheinlich bereits mit Ihrem Fernseher vernetzt. Um beispielsweise das Signal von sowohl dem Videorekorder wie auch dem Satellitenempfänger versenden zu können, schließen Sie den Sender zwischen dem...
  • Page 13: Anschließen Des Ir-Verlängerungskabels

    Entfernen Sie die IR LEDs niemals, auch dann nicht, wenn Sie diese nicht verwenden. 7. ANSCHLIEßEN DES INVISIBLE SCART 300™ AN DEN PC. Der Invisible Scart 300™ muss an den ‘TV-Out’ oder ‘Video-Out’ Ihres PC angeschlossen wer- den. Meistens befindet sich dieser Anschluss auf der Grafikkarte.
  • Page 14: Gebrauchsanleitung

    20129_20060817_UG_scart300 mengesetztes Videosignal um. Dieses Übergangskabel wird nahezu immer mitgeliefert wenn Sie eine Grafikkarte (oder einen PC) mit ‘TV-Out’ kaufen und ist auch über Ihren Marmitek Händler erhältlich (Art.-Nr. 09388). An manche PC Arten passen die Standardkabel nicht. In diesem Falle empfehlen wir Ihnen, Kontakt mit der Liefererfirma der Grafikkarte aufzunehmen.
  • Page 15 Einfluss sein. Ich empfange zwar Bild, aber keinen Ton. Der Invisible Scart 300™ kann analoge Stereosignale versenden, wie z.B. Dolby Surround. Digitale Systeme wie beispielsweise Dolby 5.1 oder Dolby Digital können nicht versendet werden. Verursacht der Invisible Scart 300™ einen Konflikt mit meinem drahtlosen Netzwerk (WLAN)? Beide Systeme arbeiten auf demselben Frequenzband (2,4GHz).
  • Page 16: Technische Daten

    Marmitek Flat TV Link 4 Mit dem Flat TV Link 4 können Sie Ihre gesamten A/V Geräte ohne jeglichen Qualitätsverlust an Ihren Invisible Scart 300™ Sender oder an den Fernseher anschließen. Weitere Informationen finden Sie unter www.marmitek.com. Marmitek EasyControl 8™ oder Marmitek EasyTouch35™...
  • Page 17 Folgen für Umwelt und die menschliche Gesundheit zu vermeiden. Wenn Sie weitere Informationen zur Entsorgung Ihrer Altgeräte benötigen, wenden Sie sich bitte an die örtlichen Behörden oder städtischen Entsorgungsdienste oder an den Händler, bei dem Sie das Produkt erworben haben. 26-09-2006 11:02 Pagina 18 MARMITEK...
  • Page 18: Introduction

    à l’autre bout de la pièce ou même dans une autre pièce ! De forme compacte, l’Invisible Scart 300™ se combine parfaitement avec un écran plat (TV LCD ou Plasma) mais convient bien entendu à tous les types de téléviseur avec connexion scart.
  • Page 19: Contenu De L'emballage

    Branchez maintenant le câble RCA/RCA sur le bus de connexion jaune, rouge et blanc de l'adaptateur scart/scart RCA. Voir illustration 1 pour plus de détails. Mettez le commutateur de canal [A] (A-B-C-D) sur A. 26-09-2006 11:02 Pagina 20 GIGAVIDEO ÉMETTEUR ADAPTATEUR SCART/SCART RCA CÂBLE SCART D'ORIGINE Illustration 1 VERS APPAREIL A/V VERS TÉLÉVISEUR MARMITEK...
  • Page 20: Installation Du Récepteur (Receiver)

    Orientez l'antenne para- bolique [K] avec le côté plat vers le récepteur. Relevez l'antenne tige [J] sur le côté. Brancher l'Émetteur Invisible Scart 300™ sur plusieurs appareils : Si vous possédez plusieurs appareils A/V, ceux-ci sont probablement raccordés en série à votre télé- viseur.
  • Page 21: Installation Du Câble D'extension Ir

    A/V. Si vous n'utilisez pas ces LED IR, ne les retirez jamais ! 7. INSTALLATION DE L'INVISIBLE SCART 300™ SUR UN PC. L'Invisible Scart 300™ doit être branché sur la sortie ‘TV-out’ ou ‘Video-out’ de votre PC. Cette connexion se trouve généralement sur la carte graphique.
  • Page 22: Utilisation

    Commutez le téléviseur sur lequel vous avez branché le récepteur sur la bonne entrée scart. Pour la plupart des téléviseurs, cela se fait en appuyant sur la touche 0 ou A/V. Vous avez maintenant une image. Pour la connexion de l'Invisible Scart 300™, le télévi- seur n'a jamais besoin de chercher les canaux.
  • Page 23 (WLAN) ? Les deux systèmes fonctionnent sur la même bande de fréquence (2,4GHz). Une interférence est donc possible. L'Invisible Scart 300™ dispose de plusieurs canaux (A, B, C, D) dans la bande de fréquence. Sélectionnez le canal avec le moins d'interférence.
  • Page 24: Caractéristiques Techniques

    11. DISPONIBLE EN OPTION. . Marmitek Flat TV Link 4 Le Flat TV Link 4 vous permet de raccorder tous vos appareils A/V à votre émetteur Invisible Scart 300™ ou votre écran TV, sans perte de qualité. Pour plus d’information, voir www.marmitek.com.
  • Page 25 Pour plus d’informations sur le mode d’élimination de votre ancien équipement, veuillez prendre contact avec les pouvoirs publics locaux, le service de traitement des déchets, ou l’endroit où vous avez acheté le produit. 26-09-2006 11:02 Pagina 26 MARMITEK...
  • Page 26: Introducción

    11. También a la venta. __________________________________________________________________________33 1. INTRODUCCIÓN. Felicidades por la compra del Marmitek Invisible Scart 300™. Con este aparato puede conec- tar su pantalla de TV inalámbricamente al enchufe scart de su equipo A/V (como por ejemplo videograbadora, lector de DVD, receptor de satélite, set-top box, ordenador, etc.). Una solu- ción perfecta si no puede o no quiere colocar sus aparatos A/V cerca del televisor.
  • Page 27: Contenido Del Embalaje

    Enchufe el adaptador de suministro incluido (230V-50Hz) y conecte la clavija de sumini- stro a la entrada DC [E] en la parte trasera del transmisor. ¡Utilize exclusivamente el adap- tador incluido! 26-09-2006 11:02 Pagina 28 GIGAVIDEO TRANSMISOR ADAPTADOR SCART/SCART TULP CABLE SCART ORIGINAL Ilustración 1 AL APARATO A/V AL TV MARMITEK...
  • Page 28: Instalación Del Receptor (Receiver)

    Dirija la antena de barra [J] al costado hacia arriba. Conectar el transmisor del Invisible Scart 300™ con varios aparatos: Si tiene varios aparatos A/V, pueden estar conecta- dos en serie con su televisor. Para poder transmitir p.e. tanto la señal del videograbador, como la señal del receptor de satélite, hay que conectar el trans-...
  • Page 29: Instalación Del Cable De Extensión Infrarrojo

    LED IR aunque no los utilice! 7. INSTALACIÓN DEL INVISIBLE SCART 300™ AL ORDENADOR. Hay que conectar el Invisible Scart 300™ con la salida de TV o de video del ordenador. La mayoría de las veces, esta conexión se encuentra en la tarjeta gráfica.
  • Page 30: Modo De Empleo

    Compruebe que los dos estén en posición ‘ON’ (ilustraciones 1 y 2) [B]. • Compruebe que el TV está ajustado a la entrada correcta A/V. INVISIBLE SCART 300™ 26-09-2006 11:02 Pagina 31 adaptador S-VIDEO a video compuesto Adaptador S-VIDEO a video compuesto de Marmitek (artnr. 09388) Ilustración 7...
  • Page 31 ¿Causa el Invisible Scart 300™ algún conflicto con mi red inalámbrica (WLAN) ? Los dos sistemas funcionan dentro de la misma banda de frecuencia (2,4GHz). Es posible que se produzcan interferencias. El Invisible Scart 300™ dispone de varios canales dentro de la banda de frecuencia (A,B,C,D). Seleccione el canal con menores interferencias.
  • Page 32: Características Técnicas

    Marmitek Flat TV Link 4 Con el Flat TV Link 4 puede conectar todos sus apa- ratos A/V con el transmisor del Invisible Scart 300™ o con la pantalla del TV, sin perder calidad. Para información más detallada, vea www.marmitek.com.
  • Page 33 Si desea obtener información más detallada sobre la eliminación segura de su aparato usado, consulte a las autoridades locales, al servicio de recogida y eliminación de residuos de su zona o pregunte en la tienda donde adquirió el producto. 26-09-2006 11:02 Pagina 34 MARMITEK...
  • Page 34: Introduzione

    Data la forma compatta, Invisible Scart 300™ può essere ben combinato con uno schermo piatto (televisore a cristalli liquidi, al plasma), ma è naturalmente adatto a qualsiasi televisore con collegamento scart.
  • Page 35: Contenuto Della Confezione

    RCA. Per maggiori dettagli si veda l’immagine 1. Impostare su A il selettore di canale [A] (A-B-C-D). Mettere il selettore on/off [B] su ‘OFF’. 26-09-2006 11:02 Pagina 36 GIGAVIDEO TRASMETTITORE ADATTATORE SCART/SCART RCA CAVO SCART ORIGINALE Immagine 1 ALL’APPARECCHIO TELEVISORE MARMITEK...
  • Page 36: Installazione Del Ricevitore

    Aprire verso l’alto l’antenna ad asta [J] situata sul lato. Collegamento del trasmettitore Invisible Scart 300™ a diversi apparecchi: Se si dispone di diversi apparecchi audio/video, questi potranno probabilmente essere collegati in serie al televisore. Per esempio, per poter trasmettere il segnale del videoregistratore e del rice- vitore satellitare, si collega il trasmettitore fra l’ultimo apparecchio audio/video e il televisore.
  • Page 37: Installazione Del Cavo Di Prolunga A Ir

    LED a IR. Anche se non si utilizzano questi LED a IR, non toglierli mai! 7. INSTALLAZIONE DI INVISIBLE SCART 300™ SUL PC. Invisible Scart 300™ deve essere collegato alle uscite ‘TV-out’ o ‘Video-out’ del PC. Normalmente questo collegamento si trova sulla scheda grafica.
  • Page 38: Uso

    20129_20060817_UG_scart300 fornito in dotazione al momento dell’acquisto di una scheda grafica (o di un PC) con uscita ‘TV- out’ e può anche essere acquistato tramite il concessionario Marmitek di fiducia (codice articolo 09388). Su alcuni tipi di PC non si può usare il cavetto standard. In tal caso si consiglia di contattare il for- nitore della scheda grafica.
  • Page 39 Entrambi i sistemi funzionano con la stessa banda di frequenza (2,4GHz). E’ quindi possibile che vi sia un’interferenza. Invisible Scart 300™ ha però a disposizione diversi canali all’interno della banda di frequenza (A, B, C, D). Scegliere il canale con l’interferenza minore.
  • Page 40: Caratteristiche Tecniche

    Marmitek Flat TV Link 4 Con Flat TV Link 4 potete collegare tutti i vostri apparecchi audio/video al trasmettitore Invisible Scart 300™ o allo schermo del televisore, mante- nendo inalterata la qualità. Per ulteriori informazio- ni vi invitiamo a visitare www.marmitek.com.
  • Page 41 Per ricevere informazioni più dettagliate circa lo smaltimento delle vecchie apparecchiature in Vostro possesso, Vi invitiamo a contattare gli enti pubblici di competenza, il servizio di smaltimento rifi uti o il negozio nel quale avete acquistato il prodotto. 26-09-2006 11:02 Pagina 42 MARMITEK...
  • Page 42: Introductie

    11. Optioneel verkrijgbaar. __________________________________________________________________________________49 1. INTRODUCTIE. Gefeliciteerd met de aankoop van de Marmitek Invisible Scart 300™. Hiermee kunt u uw TV scherm draadloos aansluiten op uw A/V apparaat (zoals Videorecorder, DVD speler, DVD recorder, satellietontvanger, Set Top Box, PC enz.). Dit is ideaal wanneer u uw A/V apparaat niet dicht bij uw TV wilt of kunt plaatsen.
  • Page 43: Inhoud Van De Verpakking

    Sluit nu de tulp/tulp kabel aan op de gele, rode en witte aansluitbus van de scart/scart tulp adapter. Zie afbeelding 1 voor meer details. Zet de kanaalschakelaar [A] (A-B-C-D) op A. 26-09-2006 11:02 Pagina 44 GIGAVIDEO TRANSMITTER SCART ADAPTER “TRANSMITTER” ORIGINAL SCART CABLE Afbeelding 1 TO SCART VIDEO TO TV MARMITEK...
  • Page 44: Installatie Van De Ontvanger (Receiver)

    [K] met de vlakke zijde in de richting van de ontvanger. Klap de staafantenne [J] aan de zijkant ophoog. Aansluiten van de Invisible Scart 300™ Zender op meerdere apparaten: Als u meerdere A/V apparaten heeft, dan zullen deze waarschijnlijk al in serie met uw TV zijn aan- gesloten.
  • Page 45: Installatie Van De Ir Verlengerkabel

    A/V apparaat. Gebruikt u deze IR LED?s niet, verwijder deze dan nooit! 7. INSTALLATIE VAN DE INVISIBLE SCART 300™ OP DE PC. De Invisible Scart 300™ moet worden aangesloten op de ‘TV-out’ of ‘Video- out’ van uw PC. Meestal zit deze aanslui- ting op de grafische kaart.
  • Page 46: Gebruik

    Schakel de TV waarop u de ontvanger heeft aangesloten over naar de juiste scart ingang. Dit doet u bij de meeste toestellen door het intoetsen van de 0 of A/V toets. U krijgt nu direct beeld. De TV hoeft voor het aansluiten van de Invisible Scart 300™ nooit kanalen te zoeken.
  • Page 47 4 verschillende kanalen instelbaar (A, B, C, D). Het IR retourkanaal is echter niet verschil- lend instelbaar en blijft door het gehele systeem werken. De Invisible Scart 300™ zenders en ontvangers werken ook samen met de zenders en ontvangers van de GigaVideo45 en de Invisible Scart 200™.
  • Page 48: Technische Gegevens

    11. OPTIONEEL VERKRIJGBAAR. Marmitek Flat TV Link 4 Met de Flat TV Link 4 kunt u al uw A/V apparaten aansluiten op uw Invisible Scart 300™ zender of uw TV scherm, met behoud van kwaliteit. Zie voor meer informatie www.marmitek.com.
  • Page 49 Voor meer informatie over het vernietigen van uw oude apparatuur neemt u contact op met de plaatselijke autoriteiten of afvalverwerkingsdienst, of met de winkel waar u het product hebt aangeschaft. 26-09-2006 11:02 Pagina 50 MARMITEK...
  • Page 50: Declaration Of Conformity

    Bij deze verklaart Marmitek BV, dat deze Invisible Scart 300™ voldoet aan de essentiële eisen en aan de Richtlijn 1999/5/EG van het Europees Parlement en de Raad van 9 maart 1999 betreffende radioapparatuur en telecommunicatie-...
  • Page 51 20129_20060817_UG_scart300 26-09-2006 11:02 Pagina 52 www.marmitek.com...
