- Page 1 CAN Switch Box™ Installation and Operation Guide 016-0171-467 Rev. B 4/2015 E21066 Copyright 2015...
- Page 2 Raven Industries shall not be held responsible for any modifications or repairs made outside our facilities, nor damages resulting from inadequate maintenance of this system.
-
Page 3: Care And Maintenance
Overview The Raven CAN Switch Box is designed to interface with Raven CAN control consoles and field computers such as the Viper Pro, Envizio Pro, or SCS 5000 and offer product and section control features at the operator’s finger tips. -
Page 4: Installation
-016-0171-467 Rev. B -Any comments or feedback (include chapter or page numbers if applicable). -Let us know how long have you been using this or other Raven products. We will not share your email or any information you provide with anyone else. - Page 5 Envizio Pro XL Bracket (P/N 107-0172-197) Note: The supplied mounting bracket must be attached to the Envizio Pro XL so that the CAN Switch Box is mounted below the field computer. 1. Set the mounting bracket over the mounting posts on the back of the field computer.
-
Page 6: Cable Connections
Note: If the CAN Switch Box is connected as instructed above, the switch box will be powered on or off using the Raven console or field computer switched power. Refer to the console or field computer manual for instructions to... - Page 7 The Logic Power LED will begin flashing if low logic power is supplied to the CAN Switch Box. Troubleshoot the logic power system before proceeding with operations. If this LED is not lit when the Raven console or field computer is powered up, troubleshoot the CANbus system before starting any system operations. Increase/Decrease Flow Switch...
- Page 8 AccuBoom system on. 3-Way Selectable Section Switches The section switches may be used to toggle up to ten individual sections. Raven field computers are also capable of controlling additional sections using the section mapping feature to group sections to the same switch. Refer to the field computer Installation and Operation Manual for additional information.
- Page 9 OmniSeed CANbus control system. Note: Contact a local Raven dealer for more information about drill control nodes and other OmniSeed control hardware options and features. Openers Switch...
-
Page 10: Troubleshooting
Troubleshooting General Issues Possible Issue Solution Cause Check chassis cable battery Console or field connections. No power to computer does console not power up Check chassis cable fuses. Check CAN Switch Box switched power connection. Ensure console or field computer is powered on. -
Page 11: Setup Issues
Setup Issues Possible Issue Solution Cause Previous Poor CAN Refer to the “CAN Troubleshooting” calibration data connections section on page 11. lost Job Issues Possible Issue Solution Cause CAN Switch Box Toggle the section and master switches switches in the to the on position. - Page 12 Possible Issue Solution Cause Adjust hydraulic valve and valve calibration settings to stop bed creep. Bed creep Refer to the control console or field computer operation manual. A fast close or PWM close valve must be selected to shut off product Wrong valve application in zero rate zones.
-
Page 13: Can Troubleshooting
CAN Troubleshooting Although the control algorithm is located within the CAN node(s), the same troubleshooting techniques that apply to traditional hard wired control systems still apply to a CANbus control network. CAN allows for modularization of the control system, but the behavior of the system remains the same. Flow and speed sensors, the control valve and any boom valves, are used in the same manner. -
Page 15: Limited Warranty
HOW CAN I GET SERVICE? Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility. -
Page 16: What Is Not Covered By This Warranty
WHAT IS NOT COVERED BY THIS WARRANTY? Raven Industries will not assume any expense or liability for repairs made outside our facilities without written consent. Raven Industries is not responsible for damage to any associated equipment or products and will not be liable for loss of profit, labor, or other damages. The... -
Page 17: Extended Warranty
24 months from the date of retail sale. In no case will the Extended Warranty period exceed 36 months from the date the product was issued by Raven Industries Applied Technology division. This Extended Warranty coverage applies only to the original owner and is non-transferable. - Page 18 HOW CAN I GET SERVICE? Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
