mods4cars smartTOP STLFBW3 Installation Manual

Comfort roof control module for bmw 3 series convertible (e93) bmw z4 roadster (e89)

mods4cars product manual

http://www.mods4cars.com/sms/db/smarttop/ext/support/manuals/bmw/...

INSTALLATION BMW Z4

STLFBW3

Comfort Roof Control Module for

BMW 3 Series Convertible (E93)

BMW Z4 Roadster (E89)

Further information and manuals for all products can be found on our web site

w w w . m o d s 4 c a r s . c o m

We explicitly point out that all functions of this control unit should only be

used while exercising caution and responsibility. We can NOT be held liable

for any damage or injury caused by installing or using this product.

PLEASE READ THE COMPLETE MANUAL CAREFULLY BEFORE USING THIS

PRODUCT.

1 of 4

4/25/2012 10:04 PM

Table of Contents

Need help?

Do you have a question about the smartTOP STLFBW3 and is the answer not in the manual?

Page 1 INSTALLATION BMW Z4 STLFBW3 Comfort Roof Control Module for BMW 3 Series Convertible (E93) BMW Z4 Roadster (E89) Further information and manuals for all products can be found on our web site w w w . m o d s 4 c a r s . c o m We explicitly point out that all functions of this control unit should only be used while exercising caution and responsibility.
Page 2 Installation - Steps 1-3 1. Turn ignition on and open convertible top to the shown position (service position), then stop. Now turn ignition off and pull key before continuing! From the right side, reach into the trunk and lift the luggage divider (1) into the upper position.
Page 3 Installation - Steps 4-6 4. Remove additional plugs (1) and (2) that hold the plastic cover in place. One (see arrow) is hidden right behind the trunk lid hinge. Remove the whole plastic piece. 5. Underneath is another protective plastic cover. Lift it out to reveal a cluster of control units.
Page 4 Installation - Steps 7-8 7. Remove the black plug from the top controller and replace it with the one from the SmartTOP wiring harness. Make sure the lever locks into place. Since the introduction of the plug and play wiring...
