Portable Heater Assembly Sheet
Tools Required
# 2 Phillips Screwdriver
# 2 Standard Screwdriver
3/8" Wrench
2001 Radiant Optics, Inc.
All Rights Reserved
Doc#: Port Manual
™
"Providing Heat in the Cold"
3) Hoop
1) Main Enclosure
8) Screw (4)
2) Corner Clips (4)
6) Wire Hoop (2)
4) Feet (2)
Radiant Optics
14522 NE Woodinville Way #107
Woodinville WA 98072
Portable Assembly
5) Trim
The information set forth on these pages is for your consideration and
do not, in part or total, constitute a warranty or legal representation.
TM
The IRLens
is patented in the US #4841947, 4896656 and abroad.
Manual
Figure 1
7) Rear Support
