- Page 1 T GP 58 Se r ie s Printer Installation Guide Th ank y ou fo r choo s i ng TOP VME .
-
Page 3: Table Of Contents
C o n t e n t s 1. Introduction ……………………………………………………………………………………………………… 1 1-1. Overview ………………………………………………………………………………………………………… 1 1-2. Features ………………………………………………………………………………………………………… 1 2. Specification …………………………………………………………………………………………………… 2 2-1. General …………………………………………………………………………………………………… 2 2-2. Cutter …………………………………………………………………………………………………………… 2 2-3. Thermal Print head ……………………………………………………………………………………… 2 3. Dimension ……………………………………………………………………………………………………… 3 3-1. - Page 4 C o n t e n t s 7-4. Typeset print function ………………………………………………………………………………… 9 7-5. NO / NC choose …………………………………………………………………………………………… 11 7-6. Upload text …………………………………………………………………………………………………… 11 7-7. Clear diary …………………………………………………………………………………………………… 11 7-8. Cut the paper ……………………………………………………………………………………………… 11 7-9. Direct Print format graphics ………………………………………………………………………… 11 7-10.
-
Page 5: Introduction
Printer 1. Introduction 1-1. Overview TGP58 system with built-in clock, local time can be set before shipment, mark the time on the printed document. Provide users with one-day and summary reports, free to choose to delete, the document has a typesetting function, users can easily download or design document formats, trademarks, etc.The document format is stored via TGP58 for future use. -
Page 6: Specification
TGP58 Series 2. Specification 2-1. General Power Source 12V DC (10.8~13.2V DC) Input/Output level HI : 12V LO : 0V DC Roll Width 56 ± 0.5 mm Installation Indoor TGP58 Standby：0.12A / 1.44W Operation：2.1A / 25.2W Maximum：2.5A / 30W Power Consumption TGP58-L Standby：0.23A / 2.76W... -
Page 7: Dimension
Printer 3. Dimension 3-1. TGP58 Dimension Unit : mm [ inch ]... -
Page 8: Tgp58-L Dimension
TGP58 Series 3-2. TGP58-L Dimension 84.10 3.311 75.20 2.961 19.30 0.760 6.30 0.248 82.00 3.228 12.00 0.472 70.20 2.764 120.20 4.732 151.30 5.957 Unit : mm [ inch ]... -
Page 9: The Hardware Setup
Printer 4. The hardware setup 4-1. Connection Setting Please read the table below for information on connectors : CN1 Serial Interface PIN 1- GND PIN 5- RESET PIN 2- X PIN 6- VCC (+5V DC) PIN 3- PGD PIN 7- RX PIN 4- PGC PIN 8- TX PULSE MODE... -
Page 10: Led And Dip Switch Setting
TGP58 Series 4-2. LED and DIP Switch Setting A.Bezel LED：Normal - LED light，Error - LED is off TGP58-L TGP58 B. Status light：Normal : LED is green ; Error : LED is red . -
Page 11: Setting Step
Printer C. DIP Switch Features Paper cutting part Completely cut paper Pulse Width 30ms Pulse Width 50ms Pulse Width 100ms Pulse Width 200ms Normal High (NC) Normal Low (NO) D. KEY1 and KEY2 • Press KEY1 once，Print daily report • Hold for KEY1 more than two sec ，The last record before printing •... -
Page 12: Battery Setup
TGP58 Series 5. Battery setup 1、2 PIN shorted : Enable 2、3 PIN Short : Disable Enable is default setting, the battery will charge after connecting power, that will supply the internal clock when turn off power. 6. Roll Installation Guide 1. The new paper roll into the clockwise direction... -
Page 13: Rs232 Command Format
Printer 7. RS232 Command Format 7-1. Reading the date and time Byte1 Byte2 7-2. Setting the date and time Command Command : Byte1 Byte2 Byte3~12 Byte13 Data Format Return code: Byte1 Byte2 Style : Format Command yy/mm/dd 0x00 mm/dd/yy 0x01 dd/mm/yy 0x02 yy/dd/mm... - Page 14 TGP58 Series Blank lines Character2 Trademark Character3 Two-dimensional code Character4 Fraction Character5 date Character6 Barcode Character7 character1 Character8 *Parameters1：Byte4,Byte6,Byte8~~~~~~~,Byte32 Information Content If the parameter 1 is a trademark of a two-dimensional code, date or barcode, please set parameter 2 to B0h No parameters If the parameter 1 is to choose a score, a text 1, text 2,text 3, or text 4.
-
Page 15: Nc Choose
Printer 7-5. NO / NC choose Byte1 Byte2 Byte3 Data Byte3= 00h (pulse normal High) Byte3= 01h (pulse normal Low) 7-6. Upload text Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 Byte9 Data1 Data2 Data3 Data4 Data5 Data6 Data7 Byte Byte Byte Byte... -
Page 16: Print Format Text Directly
TGP58 Series 7-10. Print format text directly Byte1 Byte2 Byte3 Byte4~9 End character ASCII Mode Character Printer will respond to 06h, indicating reception success Printer will respond 0Ah, representing the failure to receive Location Print size (width x height) Mode = 00h... -
Page 17: Print Diary
7-12. Print diary Byte1 Byte2 Printer will respond to 06h, indicating reception success 7-13. Back to the software version Byte1 Byte2 Printer will respond to 12 Bytes of data 7-14. Read machine status Byte1 Byte2 Printer will be a normal response to 00h, 01h represent run-out to paper 02h represent that cutter is malfunction. - Page 19 Taiwan Top Vending Machine Electronics Co., Ltd. NO.11, Anzhong St., Luzhu Dist., Taoyuan City338, Taiwan, (R.O.C.) Phone : +886-3-3115969．Fax : +886-3-3115970 E-mail : sales@topvme.com.tw Website : www.topvme.com...
- Page 20 Top Vending Machine Electronics Co., Ltd. w w w .topv me .co m...
