Gazelle EDGE Manual

F I T N E S S
I :
NCLUDES Computer, Magnet Cluster, Battery & M6 Screw
NOTE: This computer is equipped with an auto on/auto off function. The
computer will come on automatically if the exercise machine is in motion. If
not exercising for over 4 minutes, the computer will turn itself off.
I :
NSTALLATION TOOLS REQUIRED
Step 1: Push in release tabs on both sides
to separate top and bottom
of computer.
Press in release tabs
on both sides to open
Step 2: Install two AAA batteries in the top of the computer
housing. Match + on battery with the + on battery housing.
Step 3: Push the Magnet Cluster over
the left section of tubing, then
work the boss into its mating
hole in the tubing. (Make sure
magnets face in as shown).
Step 4: Place the bottom case of the
computer underneath the bar.
Insert the M6 Screw into the
center hole on the bottom
housing and the hole on the
bottom side of the axle tube.
Tighten the screw.
Step 5: Align the top half of the case
with the bottom half and snap
them together.
Note: If your display screen cannot be easily
read when using the unit, you can adjust
it by loosening the bolts at both ends of
the axle tubes. Reposition the computer and
retighten the bolts.
FR8004
C O M P U T E R
-
Phillips Screwdriver
1
Magnet Cluster
3
Magnets facing in
Boss
4
M6 Screw
5
➢
O P
VER LEASE
