MYK2011_100 Low Power Wi-Fi Module User Manual
Low Power Wi-Fi Module User Manual
Overview of Characteristic
Support IEEE802.11b/g/n Wireless Standards
Based on Self-developed High Cost Effective MCU
Ultra-Low-Power for Battery Applications with Excellent Power Save Scheme
Support UART/SPI/PWM/GPIO Data Communication Interface
Support Work As STA/AP/AP+STA Mode
Support Smart Link Function (APP program provide)
Support Wireless and Remote Firmware Upgrade Function
Support WPS Function
Support Multi-TCP Link (5 Channel) Apllication
Support External(I-PEX) Antenna Option
Single +3.3V Power Supply
Smallest Size: 23.1mm x 32.8mm x (3.45±0.3)mm
FCC/CE/TELEC Certificated
Shanghai High-Flying Electronics Technology Co., Ltd(www.hi-flying.com)
MYK2011_100
V 1.9
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MYK2011_100 and is the answer not in the manual?

Questions and answers

Related Manuals for High-Flying MYK2011_100

Summary of Contents for High-Flying MYK2011_100

  • Page 1 MYK2011_100 Low Power Wi-Fi Module User Manual MYK2011_100 Low Power Wi-Fi Module User Manual V 1.9 Overview of Characteristic  Support IEEE802.11b/g/n Wireless Standards  Based on Self-developed High Cost Effective MCU  Ultra-Low-Power for Battery Applications with Excellent Power Save Scheme ...

  • Page 2: Table Of Contents

    MYK2011_100 Low Power Wi-Fi Module User Manual TABLE OF CONTENTS LIST OF FIGURES ........................... 3 LIST OF TABLES ............................ 4 PRODUCT OVERVIEW ........................ 5 1.1. General Description ......................... 5 1.1.1 Device Features ........................5 1.1.2 Device Paremeters ......................6 1.1.3 Key Application ........................

  • Page 3: List Of Figures

    Figure 1. MYK2011_100 View ....................... 7 Figure 2. MYK2011_100 Pins Map ......................7 Figure 3. MYK2011_100 Mechanical Dimension ................11 Figure 4. MYK2011_100 PCB Symbol Size ..................11 Figure 5. Reflow Soldering Profile ....................... 13 Figure 6. Shipping Information ......................14 Shanghai High-Flying Electronics Technology Co., Ltd(www.hi-flying.com)

  • Page 4: List Of Tables

    MYK2011_100 Low Power Wi-Fi Module User Manual LIST OF TABLES Table 1 MYK2011_100 Module Technical Specifications ..............6 Table 2 MYK2011_100 Pins Definition ....................7 Table 3 MYK2011_100 External Antenna Parameters ............... 12 Table 11 Reflow Soldering Parameter ....................13 Shanghai High-Flying Electronics Technology Co., Ltd(www.hi-flying.com)

  • Page 5: Product Overview

    TheMYK2011_100 is a fully self-contained small form-factor, single stream, 802.11b/g/n Wi-Fi module, which provide a wireless interface to any equipment with a Serial/SPI interface for data transfer.MYK2011_100 integrate MAC, baseband processor, RF transceiver with power amplifier in hardware and all Wi-Fi protocol and configuration functionality and networking stack, in embedded firmware to make a fully self-contained 802.11b/g/n Wi-Fi solution for a variety of applications.

  • Page 6: Device Paremeters

    MYK2011_100 Low Power Wi-Fi Module User Manual 1.1.2 Device Paremeters Table 1 MYK2011_100 Module Technical Specifications Class Item Parameters Certification Wireless standard 802.11 b/g/n Frequency range 2.412GHz-2.462GHz 802.11b: +16 +/-2dBm (@11Mbps) 802.11g: +14 +/-2dBm (@54Mbps) Transmit Power 802.11n: +13 +/-2dBm (@HT20 , MCS7) Wireless 802.11n: +13 +/-2dBm (@HT40 , MCS7)

  • Page 7: Hardware Introduction

    MYK2011_100 Low Power Wi-Fi Module User Manual 1.2. Hardware Introduction Figure 1. MYK2011_100 View 1.2.1. Pins Definition Figure 2. MYK2011_100 Pins Map Table 2 MYK2011_100 Pins Definition Describtion Net Name Signal Comments Type 1,17,32,48 Ground Power Debug Pin SWCLK I, PD Debug functional pin, Shanghai High-Flying Electronics Technology Co., Ltd(www.hi-flying.com)
  • Page 8 MYK2011_100 Low Power Wi-Fi Module User Manual Describtion Net Name Signal Comments Type No connect if not use. Debug Pin I/O,PU No connect GPIO/AD Sleep_RQ I.PU GPIO7, No connect if not use. GPIO/AD Sleep_ON GPIO8, No connect if not use.

  • Page 9: Electrical Characteristics

    After module is powered up, long press this button ( “Low” >= 4s ) to make the module recover to factory setting. High-Flying strongly suggest customer fan out this pin to connector or button for “Manufacture” and “ Smart Link” application.
  • Page 10 MYK2011_100 Low Power Wi-Fi Module User Manual Supply current, IEEE PS DTIM=100ms Output high voltage Sourcing 6mA Output low voltage Sinking 6mA Input high voltage Input low voltage kΩ GPIO Input pull-up resistor kΩ GPIO Input pull-down resistor Shanghai High-Flying Electronics Technology Co., Ltd(www.hi-flying.com)

  • Page 11: Mechanical Size

    MYK2011_100 Mechanical Dimension MYK2011_100 Module PCB symbol size (mm) as follows: Figure 4. MYK2011_100 PCB Symbol Size 1.2.4. External Antenna MYK2011_100 module supports external antenna(I-PEX or SMA) option for user dedicated application. Shanghai High-Flying Electronics Technology Co., Ltd(www.hi-flying.com) - 11 -...

  • Page 12: Table 3 Myk2011_100 External Antenna Parameters

    MYK2011_100 Low Power Wi-Fi Module User Manual If user select external antenna,MYK2011_100 modules must be connected to the 2.4G antenna according to IEEE 802.11b/g/n standards. The antenna parameters required as follows: Table 3 MYK2011_100 External Antenna Parameters Item Parameters Frequency range 2.4~2.5GHz...

  • Page 13: Package Information

    MYK2011_100 Low Power Wi-Fi Module User Manual 2. PACKAGE INFORMATION 2.1. Recommended Reflow Profile Figure 5. Reflow Soldering Profile Table 11 Reflow Soldering Parameter Item Temperature (Degree) Time(Sec) Reflow Time Time of above 220 35~55 sec Peak-Temp 260 max Note: 1. Recommend to supply N2 for reflow oven.

  • Page 14: Figure 6. Shipping Information

    MYK2011_100 Low Power Wi-Fi Module User Manual TAPE Size: 340*340*70 mm Size: 340*340*350 mm (inside) Figure 6. Shipping Information Note: 1 tape = 500pcs 1 box = 5 tapes = 5 * 500 pcs = 2500pcs Shanghai High-Flying Electronics Technology Co., Ltd(www.hi-flying.com)

  • Page 15: Oem/Integrators Installation Manual

    MYK2011_100 Low Power Wi-Fi Module User Manual 3. OEM/INTEGRATORS INSTALLATION MANUAL Important Notice to OEM integrators 1.This module is limited to OEM installation ONLY. 2. This module is limited to installation in mobile or fixed applications, according to Part 2.1091(b).
  • Page 16 MYK2011_100 Low Power Wi-Fi Module User Manual energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can...
  • Page 17 © Copyright High-Flying, May, 2011 The information disclosed herein is proprietary to High-Flying and is not to be used by or disclosed to unauthorized persons without the written consent of High-Flying. The recipient of this document shall respect the security status of the information.
