Alera ALE-WD4220SR Assembly Instructions

Model# ALE-WD4220SR
Product support and parts:
Ayuda del producto y partes: 1-800-733-4000
Support technique et pieces:
No tools required for assembly.
Helpful - Rubber Mallet
Part Description
A Shelf
B Reversible Solid Surface
C Cantilever Shelf
D Cantilever Shelf Liner
E
3-Sided Support Bracket
F Side Support Rail
G Back Ledge
H Top Pole With Pole Cap & Connector
I Front Bottom Pole With Pole Cap & Leveler
J
Back Bottom Pole With Feet Leveler
K Tapered Locks, 2pcs/set
Pole Cap - Optional if do not attach cantilever shelf
L
Put the 2 caps on the top of the 2 back bottom poles
Note: White plastic discs between each shelf collar are for packing only. Please throw away after sorting out parts.

Special Warnings

Assemble the item on a soft, non-abrasive surface, such as carpeting, to avoid scratching the finish.
Use care when handling. May require two adults for safe assembly.

Care and Maintenance

Periodically check and ensure that all components are in their proper position, are free from damage and that all connectors
are tight.
Assembly Instructions
Manufactured for / Hecho para / Fabriqué pour Alera ® USSCo
1 Parkway North Blvd, Suite 100, Deerfield, IL 60015 © 2013 USSCo
Made in / Hecho en / Fabriqué en China
Quantity
14 sets
+2 sets extra
Illustration
1
1
1
1
1
2
1
2
2
2
2
