Summary of Contents for Slee MCS II
- Page 1 O P E R A T I N G M A N U A L C O V E R S L I P P E R M C S I I HIGHLY RELIABLE SYSTEMS FOR A SMOOTH WORKFLOW IN THE LABORATORY HIGHEST QUALITY STANDARDS D ES I GN &...
-
Page 2: Table Of Contents
1.10. 2. Information about MCS II .................. 8 Technical Data ......................8 2.1. Shipment ......................... 8 2.2. 3. Overview components of the MCS II ..............9 Operating Panel Buttons ..................11 3.1. Type plate .......................11 3.2. 4. Operation ......................12 Power-on the MCS II ....................12 4.1. - Page 3 5. Troubleshooting ....................25 The message window ....................25 5.1. The alarm codes ......................27 5.2. Definitions of alarm codes ................27 5.2.1. List of error codes ....................27 5.3. Motion errors ....................27 5.3.1. Details of driver errors ..................28 5.3.2. Task errors........................29 5.3.3. System errors....................29 Network errors ....................29 5.3.4.
-
Page 4: Safety Instructions
This way, an adequate use of the device, is ensured. If you have problems, feel free to contact the competent SLEE medical GmbH contact person. The device present is offered with two different power supply variations. Please check the tool identification plate to make sure that the device’s power supply matches your local power supply. -
Page 5: Emission
1.5. Personal protective equipment When working with the MCS II, it is necessary, according to your security policies applicable in any case, to wear protective clothings to avoid direct contact with the biologic samples. The same applies, for example, when cleaning the unit. -
Page 6: Transport And Stocking
Mains voltage fluctuation is within + / - 10 % of rated voltage. 1.8. Safety measures on installation location The MCS II must be installed on a stable, level and horizontally oriented base to ensure the safe and reliable operation. -
Page 7: Intended Use
Only persons who have been thoroughly trained by the operator and commissioned can handle the MCS II. The operator is responsible for other people in the work area. The operating company make the instruction manual accessible to the operator and make sure, that the operator have read and understand the instruction manual. -
Page 8: Information About Mcs Ii
2. Information about MCS II 2.1. Technical Data Model MCS II Coverslipping speed: 10 to 20 sec per slide, changeable 7-shift speed Dispensing volume: 0.04 to 0.2 cm³, adjustable Mountant container Commercially avaible container or our standard container Coverglass: Size – Standard: 24 x 40, 50, 55, 60 mm Size –... -
Page 9: Overview Components Of The Mcs Ii
3. Overview components of the MCS II Protection hood Operating panel Pull-out magazine for basket loading Type plate Power switch Mains socket Manual_MCS_II_2021-10-003.00_EN.docx... - Page 10 Connection for external exhaust- system Unloading station for basket Holder for Motion-head to put covermedium and the coverglass on xylol container the slides Xylol container to Dispenser for prevent the dispense the dispenser-nozzle for mounting media on drying-out the coverglass Coverglass container Loading station for Holder for...
-
Page 11: Operating Panel Buttons
3.1. Operating Panel Buttons Power: Switch on the MCS II Start / Restart: Starting the program Light: Covermedium remaining quantity Stop: Stop the running program Finger: Opening and closing the OT holders Emergency: Immediately stop the running programn 3.2. Type plate... -
Page 12: Operation
4.1. Power-on the MCS II Plug in the power cable into the power-socket (backside of the device). Switch the power-switch in the “I”-position. Press the Power button to turn on the MCS II. When the system starts, the standby screen appears. -
Page 13: Setting 2
4.3. Setting 2 Change the Change the length mounting speed of of the conintuous the covering discharge between between 60-120 rpm 10-40 mm Change the position Change the of the intermittent discharge amount discharge between between 1 - 10 0-30 mm to change the values of the different parameter. -
Page 14: Program Setting
4.5.1. Program setting Program 0 can not be edit. You can only edit program 1-4. 4.5.1.1. Program setting 1 Change the number of the program between 1-4 which you want to edit. Change the cycle Change the amount time for the of discharge complete covering- between 0-250... -
Page 15: Installation
4.5.1.3. Program setting 3 Change the length Change the number of the conintuous of the program discharge between between 1-4 which 10-40 mm you want to edit. Change the position Change the of the intermittent mounting speed of discharge between the covering 0-30 mm between 60-120 rpm... - Page 16 4.5.3.1. CG Head Reset button Solenoid valve Individual operation on/off button button You can use the CG head menu to control a single deck process by pressing and holding the keys. The suction of the coverslips is activated with the [Suction ON] button. Press the [Suction ON] button again to turn off the suction of the covers.
- Page 17 4.5.3.3. Elevator operation Limit lamp Individual operation button Reset button Single move button Press “Elevator” to enter the elevator control menu. You can use the elevator menu to control the lift by pressing and holding the “Up” / “Down” button. The elevator is controlled until you release the buttons.
-
Page 18: Installation Of External Exhaust System
4.5.3.5. Finger operation Individual operation Limit lamp button Finger open / close button Reset button Press “Finger” to enter the finger control (gripper) menu. Use the Finger menu to control the finger by pressing and holding “Up” / “Down”. The finger is controlled until you release the buttons. -
Page 19: Loading Xylol
4.7. Loading Xylol Fill the xylol in the xylol container between the min and max marks. The level of the container should always be between the two markings Please refill the xylol bottle frequently to prevent the covering prcoess against bubbles in the mounting media. -
Page 20: Loading Mounting Media
10. Press “Return” to go to the operation menu. To abort the process, press the button “finish” for about 2-5 seconds. Should you put the MCS II back into operation after a longer service life, then rinse the roofing system with xylene before filling in the roofing material. -
Page 21: Adjusting The Cg Head
4.9. Adjusting the CG head If you use different coverglass, you can adjust the position of the adjustment board. Coverglass size scala with setted coverglass mark Scale locking screw 1. Loosen the cover glass size scale locking screw. 2. The two arrows (red/blue) must be on top of each other for the selected size. The correct position for the corresponding size is shown in the table below. -
Page 22: Start The Process
• Mains supply is connected. If the MCS II has finished the covering for one basket, you can open the side-flap to remove the covered basket. If you want to remove the covered basket through the side-flap be careful of the rotation parts! Manual_MCS_II_2021-10-003.00_EN.docx... -
Page 23: Power-Off The Device
4.11. Power-off the device Ensure that the current program has been terminated. 4.11.1. Replace the xylol in the dispenser reservoir At the end of the working day remove the dispenser reservoir and refill the bottle with new xylol. Remove the Refill the container to the dispenser reservoir orange line with xylol... -
Page 24: Seaking The Dispenser Needle Overnight
Press the Power button to turn off the MCS II and press the power switch in the “0”-position. If you do not use the device for a long time, unplug the power plug from your sockets to prevent the MCS II against damage caused by lightning strike. -
Page 25: Troubleshooting
5. Troubleshooting 5.1. The message window After the completion of operations, in the case of faults or when an alarm is triggered, this window displays messages while the unit is in operation, while a beep sounds at the same time. In the following, the displayed contents of the individual messages are explained and how to delete them. - Page 26 Displayed if the slides have not been removed correctly during the cover-up process. Please check whether the slides are correctly inserted in the basket. * If this message is displayed even though you have checked the above, it is conceivable that there is a defect inside the unit. Please contact the manufacturer in this case.
-
Page 27: The Alarm Codes
5.2. The alarm codes If a malfunction occurs or a malfunction occurs, an alarm code is displayed as a warning message. To turn off the alarm, press the "CLR" key, which is displayed in the alarm message after you have eliminated the cause of the fault. 5.2.1. -
Page 28: Details Of Driver Errors
5.3.2. Details of driver errors Task- Driver Error description Reason Action alarm- code Fault due to Fault of a Please check the device for overcurrent of the mechanical part device-related influences driver Bad druver The replacement of the driver or motor is necessary Error due to driver Fault of a... -
Page 29: Task Errors
Task errors Alarm-codes Error description Reason Action 02xxxxxx Controller error when The emergency stop Please check the running a program button has been condition of the pressed. emergency stop The upper or lower flap button, as well as the has been opened. condition of the lower Abnormal data setting and upper flap. -
Page 30: Cleaning, Maintenance And Recycling
6. Cleaning, Maintenance and Recycling 6.1. Cleaning Instructions The MCS II is a precision instrument. Of course, it is necessary to keep it clean to guarantee a long timespan between maintenance checks. The surface of the MCS II may be cleaned with standardized, not scratching cleaning agents, if needed. -
Page 31: Cleaning And Maintenance Plan
6.3. Abandonment / Recycling After expiration of instrument’s life span please transfer unit into professionally disposal or send it back to SLEE medical GmbH. As a manufacturer / distributor we take back the used equipment, requiring a payment for disposal. - Page 32 SLEE medical GmbH • Am Neuberg 14 55268 Nieder-Olm • Germany www.slee.de T: +49 (0) 6136 76997-0 E: mail@slee.de www.slee.de YouTube LinkedIn Instagram INS9500GB ∙ Manual_MCS_II_2021-10-003.00_EN...
