Rocstor Y10C195-B2 User Manual

USB Type-C® to DisplayPort™1.2 Cable 4K 60Hz
Y10C195-B2, Y10C196-B2
Y10C197-B2, Y10C196-W2
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.

Introduction

This is a premium Rocstor Mini DisplayPort1.2 to HDMI Adapter with HDR which allows
to connect Mini DisplayPort based PC(eg: Macbook air) to HDMI Display with max
4K/60Hz resolution. With this adapter, you can watch videos or slideshows together on
the big screen

Package Contents

Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
User Manual
®

Features

Mini Display Port - Male
• Support DP1.2 Alt mode with 21.6Gbps all lanes, per
lane 5.4 Gbps (HBR2), 2.7 Gbps (HBR) and 1.62 Gbps
(RBR)
HDMI - Male
• Support HDMI max 4K/60Hz 8bit with max 18Gbps
• Support RGB, YCbCr 4:4:4 ,4:2:2 ,4:2:0,
• Support 8bit/10bit deep color
• Support HDR
• Support HDCP2.2&1.4
• Support CEC
• Support DP1.2 Alt mode with max 21.6Gbps
• Support HDMI max 4K/60Hz
• Support HDR
• Support HDCP2.2&1.4
• Support CEC
• Cable length:max 6ft
• Powered from DisplayPort source
Note:
The output resolution, refresh rate, video pixel format depends on the
performance of the computer and the monitor.
Speci cation

Connector

First End
Second End

Warranty

Limited Warranty

Environmental

Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity

Regulatory Approvals

Certi cations
Size & Weight
Size

Accessory

User Manual
Mini DisplaPort Male x1
HDMI x1
2 Year
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
FCC, CE
MDP Side: 28x19.8x9.8mm - 1.1"x0.7"x0.3"
HDMI Side: 43.2x20.8x11mm -1.7"x0.8"x0.4"
