INSTALLATION GUIDE
RephiDuo P Pack TL1 with RO cleaning media
RephiLe Catalogue Number:
Comparable Millipore Part Number
Suitable Millipore Systems:
This product is a comparable to the corresponding Millipore cartridges. Please refer to
Millipore's User Manual for a detailed instruction on installation.
A brief description of the installation process is described below:
1. Place the system into Standby by pressing the STANDBY button for about 2 seconds
PRODUCTION
REJ
2. Press the MAINTENANCE button
STANDBY
3. Press the EXCH PROGARD PACK button for 2 seconds to get the system into
depressurize and purge mode. System will purge for 12 seconds during which time the
pump will operate.
MAINTENANCE
EXCH PROGARD PACK
RR500CPC1
:
PR0GTLCS1
RiOs 30 - 200
Elix 20 – 100. Elix Clinical
9 5%
9 8. 0%
DATA
STANDBY
SETUP
MAINTENANCE
PRODUCTION
DATA
STANDBY
MAINTENANCE
PRODUCTION
MAINTENANCE
EXCH PROGARD PACK
PURGE
PROGARD TL PACK
PLEASE WAIT...
SETUP
DATA
CANCEL
Page 1 of 3
Advertisement
Table of Contents
Related Manuals for RephiLe RephiDuo P Pack TL1
Summary of Contents for RephiLe RephiDuo P Pack TL1
- Page 1 INSTALLATION GUIDE RephiDuo P Pack TL1 with RO cleaning media RephiLe Catalogue Number: RR500CPC1 Comparable Millipore Part Number PR0GTLCS1 Suitable Millipore Systems: RiOs 30 - 200 Elix 20 – 100. Elix Clinical This product is a comparable to the corresponding Millipore cartridges. Please refer to Millipore’s User Manual for a detailed instruction on installation.
- Page 2 4. Wait till the purge completes. The system is now ready to have cartridge replaced. PURGE PLEASE REMOVE PROGARD TL PACK PROGARD TL PACK PLEASE WAIT… CANCEL CANCEL 4.1 Lift up the cartridge Locking Handle as shown in the picture. 4.2 Gently pull the used cartridge out of the system.
- Page 3 System goes into Cleaning for 20 minutes. Once the cleaning cycle completes, system will produce water automatically. RephiSolo, RephiDuo and RephiQuatro are trademarks of RephiLe Bioscience, Ltd. © 2010. RephiLe Bioscience, Ltd. All rights reserved. All other trademarks are trademarks of their respective manufacturers.
