Desktop Duster Box
ZVB
Series
Static neutralization, dust removal,
and dust collection processes
have been integrated
into one box.
Blow nozzle with improved
dust removal efficiency
A4 size [ZVB20]
210 x 297 mm (Dimensions)
202 x 212 mm (Static neutralization space)
Electronic
components
Static
neutralization
3 functions in 1 unit!
All in one
Dust
removal
A3 size [ZVB40]
400 x 384 mm (Dimensions)
392 x 298 mm (Static neutralization space)
Smartphone
Lens
Adopted a dedicated
ionizer with improved
static neutralization
efficiency.
Pneumatic dust collector
Dust
enables quick dust collection
collection
response.
Lamp cover
Cosmetic case
Parts for home
appliances
194
194
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMC Networks ZVC Series
Summary of Contents for SMC Networks ZVC Series
- Page 1 Desktop Duster Box Series Static neutralization, dust removal, Adopted a dedicated ionizer with improved Static and dust collection processes static neutralization neutralization efficiency. have been integrated 3 functions in 1 unit! into one box. All in one Pneumatic dust collector Dust Dust Blow nozzle with improved...
-
Page 2: Offset Voltage
Static Dust Dust 3 functions in 1 unit! All in one neutralization removal collection Static neutralization and dust removal efficiency have been improved by separation from the ion blow and air blow structure. Regulator for adjusting supply Regulator for adjusting supply pressure for additional air blow pressure to the dust collector Ionizer... -
Page 3: How To Order
Desktop Duster Box Series RoHS How to Order ZVB 20 w e r Size Additional air blow Photoelectric sensor AC adapter None ∗ ∗1 It is necessary to connect an external With additional air blow None (exclusive DC plug attached) With photoelectric sensor ∗... -
Page 4: Air Circuit Diagram
Series Air Circuit Diagram ZVB20 ZVB40 Regulator Regulator Solenoid valve Solenoid valve Ionizer Additional air blow adjustment Ionizer needle (Option) Additional air blow adjustment Compressed air needle (Option) supply port Compressed air supply port Exhaust port Exhaust port Exhaust port Dust collector (Vacuum flow) Work area Dust collector... -
Page 5: Operation Flow
Series Desktop Duster Box Operation Flow The following shows the operating sequence during continuous operation and timer operation with the photoelectric sensor. Stop of static neutralization and dust removal Main unit operation The photoelectric sensor detects a workpiece. The operation of the ionizer (static neutralization) and the additional air blow (dust removal) stops by the progression of the set time (2/5/10 s), or the OFF detection of the photoelectric sensor after the workpiece is removed. - Page 6 Series Dimensions [ZVB20] [ZVB40] D’ ∗ F’ ∗ Model ZVB20 ZVB40 ∗1 Dimension D’ is the overall height including the knob of the regulator. ∗2 Dimension F’ is the overall depth including the switch lever on the front and the exhaust port on the back. Refer to the operation manual for detailed dimensions.
- Page 7 Series Specific Product Precautions Be sure to read this before handling the products. Refer to page 227 for safety instructions. Installation / Mounting Operating Environment Warning Warning 1. Avoid using in a place where noise (electromagnetic 1. Operate in an environment in the specified ambient wave and surge) is generated.
