- Page 1 MANUAL MANUALE HEAT PUMPS C.P.A. CLIMEXEL SERIES Ver.02–2017-08-04...
-
Page 2: Table Of Contents
CLIMEXEL HEAT PUMPS MANUAL pag. 2 di 18 SOUMMARY INSTALLATION CHOICE OF THE POSITIONING AND INSTALLATION AREA HYDRAULIC CONNECTION CIRCUIT (BY-PASS) COLLEGAMENTO ELETTRICO ELECTRICAL CONNECTION CONDENCE DRAIN START-UP CONTROLLER IC 121 CX CONTROL KEYPAD FUNCTIONS DISPLAY OPERTIVE GUIDE START-UP DISPLAY – CORRECT WORKING DISPLAY- SIGNAL OF ANOMALY STOP SET POINT DISPLAY AND PROGRAMMING... -
Page 3: Installation
CLIMEXEL HEAT PUMPS MANUAL pag. 3 di 18 INSTALLATION WARNING!!! The heat pump must only be installed by qualified personnel! WARNING: ▪ Never lift the machine by the hydraulic fittings, there is the risk of damaging the connection with the titanium exchanger located inside the machine. ▪... - Page 4 CLIMEXEL HEAT PUMPS MANUAL pag. 4 di 18 ▪ La distanza che separa la pompa di calore dalla piscina non deve essere eccessiva (preferibilmente inferiore ai 10 m) al fine di limitare le dispersioni termiche nelle tubazioni di collegamento al circuito di filtrazione della piscina. ▪...
-
Page 5: Hydraulic Connection Circuit (By-Pass)
CLIMEXEL HEAT PUMPS MANUAL pag. 5 di 18 HYDRAULIC CONNECTION CIRCUIT (BY-PASS) Uscita Acqua Ingresso Acqua La circolazione dell’acqua della piscina attraverso la pompa di calore è generalmente ottenuta using a pump already placed at the level of the pool's filtration circuit (in order to avoid the attachment of an additional pump). -
Page 6: Collegamento Elettrico
CLIMEXEL HEAT PUMPS MANUAL pag. 6 di 18 These characteristics must be checked at the beginning of the season, before circulating the water in the heat pump, and then regularly during the operating period.. WARNING: Shock treatment of swimming pool water If "shock"... - Page 7 CLIMEXEL HEAT PUMPS MANUAL pag. 7 di 18 ELECTRICAL FEATURES Model M.P.I. 80M M.P.I. 100M M.P.I. 160M M.P.I. 190M M.P.I. 190T M.P.I. 240M M.P.I. 240T M.P.I. 320T M.P.I. 380T Power supply [V] 230 - mono 230 - mono 230 - mono 230 - mono 400 - tri 230 - mono...
-
Page 8: Condence Drain
CLIMEXEL HEAT PUMPS MANUAL pag. 8 di 18 CONDENSATE DRAIN The machine's support base must have a very slight slope (approx. 1-2%) towards the corner of the collection basin chosen for draining the condensate. Use one of the corner holes in the lower collection basin to drain the condensation. -
Page 9: Control Keypad Functions
CLIMEXEL HEAT PUMPS MANUAL pag. 9 di 18 CONTROL KEYPAD FUNCTIONS Button Function Push and release: The Set point value is shown in cooling (SetC code) and in heating (SetH code) Press and hold for 3 seconds: The Set point value is shown Press and release in programming mode: Allows you to access the modification of the parameters Allows the acceptance of the new parameters... -
Page 10: Display
CLIMEXEL HEAT PUMPS MANUAL pag. 10 di 18 DISPLAY Icon Function °C -°F Appears when temperature is displayed Appears when an alarm is detected Appears when the Menu button is pressed Appears when the defrost function is active Appears when there is no or insufficient water flow Appears when the compressor is running Appears when the filtration is in series with the heat pump (optional) Appears when the defrost function is active while the ambient temperature is... -
Page 11: Display - Correct Working
CLIMEXEL HEAT PUMPS MANUAL pag. 11 di 18 DISPLAY – CORRECT FUNCTIONING DISPLAY-SIGNAL OF ANOMALY STOP Press to stop the pump when it is in cooling mode Press to stop the pump when in heating mode Display con macchina in spegnimento www.cpa-piscine.it Ver.02–2017-08-04... -
Page 12: Set Point Display And Programming
CLIMEXEL HEAT PUMPS MANUAL pag. 12 di 18 SET POINT DISPLAY AND PROGRAMMING Press and release the "SET": − In the lower part of the screen the cooling set point "SetC" or the heating set point "SetH" is displayed. − The set point is displayed at the top of the screen. Set point selection: 1) Press and hold the SET SET key for 3 seconds 2) The current set point is displayed on the screen, flashing... -
Page 13: Settings And Controls
CLIMEXEL HEAT PUMPS MANUAL pag. 13 di 18 In "COMFORT" mode the machine will operate at maximum power until the set point temperature is reached. In "ECO" mode the machine will adjust the power according to the water and air temperature in order to optimize electricity consumption. -
Page 14: Defrost Cycle
CLIMEXEL HEAT PUMPS MANUAL pag. 14 di 18 DEFROST CYCLE As the air passes over the evaporator fins, the water contained condenses into small drops. If the ambient air is cold, these droplets could freeze and therefore would no longer be able to drain by gravity from the bottom of the machine. - Page 15 CLIMEXEL HEAT PUMPS MANUAL pag. 15 di 18 Never stop the heat pump during a thermodynamic defrosting phase or only after one, this could cause problems when the heat pump is restarted at the beginning of a subsequent season (subsequent triggering of the "HP"...
- Page 16 CLIMEXEL HEAT PUMPS MANUAL pag. 16 di 18 The heat pump does not carry out the defrost cycle correctly o Does the thermodynamic defrosting phase start? Acoustic sound + change in compressor pitch and (partial) ice melting. o Ice remains on the bottom of the evaporator: condensate does not drain: o The heat pump is not tilted slightly towards the condensate drain hole o The condensate drain hole is blocked.
-
Page 17: Troubles List
CLIMEXEL HEAT PUMPS MANUAL pag. 17 di 18 ALARM CODE LIST Code Description Cause Remedy/Reset Automatic reset when sensor is Sensor alarm Pb1 heat Faulty sensor or false contact replaced or contact is verified exchanger input Automatic reset when sensor is Sensor alarm Pb2 heat Faulty sensor or false contact replaced or contact is verified... -
Page 18: Electrical Dyagram
CLIMEXEL HEAT PUMPS MANUAL pag. 18 di 18 ELECTRICAL SCHEME ▪ Le informazioni contenute nel presente documento possono variare a discrezione del redigente, senza preavviso, contestualmente alle modifiche del prodotto in oggetto al presente documento: sarà responsibility of the customer when placing the order to verify the persistent correspondence of the product to the informati on sheet. ▪...
