Summary of Contents for Elm Plus EPL1020
- Page 1 E-mail: service@elmplus.com US Toll Free: 888 - 357 - 7263 Elm Plus LLC 2704 Handley Ederville Rd Richland Hills, TX76118...
- Page 2 48"W 30000-BTU Aluminum Propane Fire Pit with Cover Product has been CSA tested and certified. Read this manual before installing and operating this appliance. Failure to follow these instructions may result in electric shock, fire property, or personal injury. Do not store or use gasoline or other flammable liquids in vicinity of this appliance.
-
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION! IMPORTANT, FAILURE TO CAREFULLY READ, UNDERSTAND AND FOLLOW EVERY PART OF THIS DOCUMENT MAY RESULT IN PROPERTY DAMAGE, SERIOUS BODILY INJURY OR DEATH. DANGER FIRE OR EXPLOSION HAZARD If you smeII gas: • Shut off gas to the appliance. •... -
Page 5: Carbon Monoxide Hazard
DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. The minimum inlet gas supply pressure for the purpose of input adjustment: 25psi. - Page 6 WARNING lf the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. WARNING Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.
- Page 7 • Do not use this appliance if any part has been under water. • Remove the battery when not using the appliance for an extended length of time. • Do not store a spare or disconnected liquid propane cylinder under or near this appliance.
- Page 8 • Never lean over the open appliance or place hands or fingers on the upper portion of an operational unit. • Do not rest feet on the appliance. Do not enlarge valve orifices or burner ports when cleaning the valve or burner. •...
- Page 9 • This outdoor appliance is not to be installed or used in or on recreation vehicles and/or boats. • Always use in accordance with all applicable local, state and national codes. Contact your local fire department for details on outdoor burning. •...
- Page 10 Propane Characteristics: - Flammable, explosive under pressure, heavier than air and settles in pools in low areas. - In its natural state, propane has no odor. For your safety, an odorant has been added. - Contact with propane could burn the skin. •...
- Page 11 thoroughly cleaned and inspected on a regular basis. Clean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced prior to the appliance being put into operation. •...
- Page 12 • Keep gas appliance away from location where it can get excessively wet. Do not use gas appliance if any part has been underwater. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.
- Page 13 b) If the burner valve is open prior to the LP gas cylinder service valve being opened, the connection will interpret this free flow of gas to be a leak. c) The connection safety feature will reduce gas flow from the regulator to the appliance to a minimal level.
-
Page 14: Explosive View
CSA (Canadian Standards Association) certified to ANSI Z21.97-2017•CSA 2.41-2017 “Outdoor Decorative Gas Appliances”. Do not connect to a remote gas supply. Figure 1 SPECIFICATIONS INPUT 50,000 Btu/hr Propane Regulator 11 inches water Pressure column Clearances to Sides: 72in. / Top: 48 in. / combustible 182.9cm 121.9 cm... - Page 15 Item Description Table Top Control Knob (Preassmbled) Left Side Panel Back Side Panel Right Side Panel Door Frame Door Metal Stand M6X35mm Bolt M6X25mm Bolt M6 Flat Washer M6 Spring Washer Wrench Glass Beads Battery (AAA) (Not included) PVC Cover Door Knob M4X25mm Screw M4 Flat Washer...
- Page 16 ASSEMBLY INSTRUCTIONS * Please keep this owner's manual for future reference. * Please unpack and identify all parts using the parts list provided. * Note: DO NOT tighten any bolts until all bolts have been started. Philips screw driver NOT included STEP 1 Check that the Control Knob (C) for the gas supply system is...
- Page 17 STEP 4 Attach the steel base to the bottom part of the Table Top (B) by using 4pcs M6X35mm Bolts (J), 4pcs M6 Flat Washer (L) and 4pcs M6 Spring Washer (M). STEP 5 Insert the Door (H) to Right Front Panel (F) and attach Door Knob (R) to the door by using M4X25mm screw (S) and M4...
- Page 18 STEP 8 Pour the box of glass beads (O) into the fire pit around Table Top (B). DANGER WARNING: To ensure proper function, the guard on this burner should be free of glass beads at all times. STEP 9 Close the door, put the Burner Cover (A) on the fire pit Table Top (C), then cover the fire pit with PVC Cover (Q) when not in use to protect...
-
Page 19: Selecting A Location
LP (LIQUID PROPANE) GAS SUPPLY CONNECTION • Always confirm that the burner control knob is in the OFF position before connecting the gas supply. • Do not obstruct the flow of combustion air and ventilation air to the appliance. To Connect: 1. -
Page 20: Visual Check
VISUAL CHECK Prior to each use, check the hose and valve for excessive wear or abrasions. LEAK TEST 1. Perform a leak test in a well ventilated area outside. 2. Make sure any open flames or cigarettes are extinguished. 3. Remove the battery. 4. - Page 21 7. Once the appliance is lit, flame height can be changed by adjusting the burner control knob between the "High" and "Low" 8. Always check burner flames periodically to ensure proper operation. Flames should be mostly yellow with some blue for best performance. (See diagram) 9.
-
Page 22: Routine Care
TO EXTINGUISH 1. Push and turn burner control knob to the "OFF" position. 2. Close the LP tank valve. 3. Disconnect the regulator from the LP tank to close the gas supply when not in use. 4. Make sure that the unit is completely cooled before IGNITER-PUSH touching any of the components or putting on the cover. -
Page 23: Troubleshooting
Item Number:EPL1020 & EPL1021 Type of gas: Propane Normal Hourly Input: 30 ,000 BTU/hr (11.72 kw) Manifold Pressure: 11 inch w.c. (2.74 kpa) For Outdoor Use Only. If Stored Indoors, Detach and Leave Cylinder Outdoors. Cover must be removed when burn is in opeartion. - Page 24 PROBLEM CAUSE CORRECTIVE ACTION Make sure all the gas burner ports are free of any Appliance emits a Flame is obstructed at burner ports. glass beads or debris to allow the gas to flow freely. lot of black smoke when lit Regulator hose is pinched.
