- Page 1 E-mail: service@elmplus.com US Toll Free: 888 - 357 - 7263 Elm Plus LLC 2704 Handley Ederville Rd Richland Hills, TX76118...
- Page 2 32"D 30000-BTU Slates Top Aluminum Propane Fire Pit with Cover Product has been CSA tested and certified. Read this manual before installing and operating this appliance. Failure to follow these instructions may result in electric shock, fire property, or personal injury. Do not store or use gasoline or other flammable liquids in vicinity of this appliance.
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION! IMPORTANT, FAILURE TO CAREFULLY READ, UNDERSTAND AND FOLLOW EVERY PART OF THIS DOCUMENT MAY RESULT IN PROPERTY DAMAGE, SERIOUS BODILY INJURY OR DEATH. DANGER FIRE OR EXPLOSION HAZARD If you smeII gas: • Shut off gas to the appliance. •... -
Page 4: Carbon Monoxide Hazard
DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. If you are assembling this unit for someone else, give this Owner’s Manual to them to read. - Page 5 DANGER CARBON MONOXIDE HAZARD This fire pit is a combustion appliance. All combustion appliances produce carbon monoxide (CO) during the combustion process. This product is designed to produce extremely minute, non-hazardous amounts of CO if usedand maintained in accordance with all warnings and instructions. DO not block air flow into or out of the fire pit.
- Page 6 Store the propane cylinder outdoors in a well- ventilated space out of reach of children. Never store the propane cylinder in an enclosed area (house, garage, etc.). If fire pit is to be stored indoors, disconnect the propane cylinder for outdoor storage and allow the fire pit to fully cool down prior to move indoors.
- Page 7 DANGER Failure to comply with the precautions and instructions provided with this fire pit can result in death, serious bodily injury and property loss or damage from hazards of fire, explosion, burn, asphyxiation, and/or carbon monoxide poisoning. Only persons who can understand and follow the instructions should use or service this fire pit.
- Page 8 WARNING Children and adults should be alerted to the hazards of high surface temperatures and kept at a safe distance to avoid burns or clothing ignition. WARNING All children should be kept away from the appliance and should not be allowed near the product unless carefully supervised by an adult.
- Page 9 Do NOT burn solid fuels in this gas fireplace. Do NOT ignite the burner before pouring all of the burner media (lava rock or fire ice) into the burner pan. The media must be evenly distributed over the burner. If during initial firing of fire pit, please stay away from the fire pit for 20 minutes as fire media (lava rock or fire ice) may pop and hit someone on the face or eyes.
- Page 10 IMPORTANT SAFETY INFORMATION A self-contained LP-gas cylinder for use with this appliance must have a capacity of 20 lbs. and must be equipped with a Type 1 connector and an OP D (overfill protection device). See Figure 1. The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP- gas cylinders of the U.S.
-
Page 11: Explosive View
EXPLOSIVE VIEW Item Description Burner Cover Table Top Back Post Front Right Post Front Left Post Ignition Side Side Door Cylinder Holder Lava Rock 1 Box Adjustable Leveler PVC Cover Slate Knob Flat Washer Spring Washer 1/4 in x 15 mm Bolt 1/4 in x 20 mm Bolt #4 x 20 mm Screw Allen Wrench... - Page 12 ASSEMBLY INSTRUCTIONS * Please keep this owner's manual for future reference. * Please unpack and identify all parts using the parts list provided. * Note: DO NOT tighten any bolts until all bolts have been started. STEP 1 Connect the Front Right Post (D), Side (G), Back Post (C), Side (G) with 6 pieces ¼...
- Page 13 STEP 4 Place the Door (H) in the body, and install the Knob (N) with #4 x 20mm Screw (T) attaching from back of door. STEP 5 Assemble the base frame to the top with 8 pieces ¼ in x 15 mm Bolts (R), 8 Spring Washers (Q) and 8 Flat Washers (P).
-
Page 14: Danger Warning
STEP 8 Pour the box of Lava Rocks (J) into the fire table body around Table Top (B). Note: (A) Cover must be removed when burner is in operation. DANGER WARNING: To ensure proper function, the guard on this burner should be free of lava rocks at all times. -
Page 15: Natural Gas Conversion
NATURAL GAS CONVERSION BATTERIES Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignition module located on the control panel to access the battery compartment. The ignition module requires one AAA size battery. Battery is not included. WARNING Prior to turning gas on and attempting to light the appliance, make sure the appliance is outside, in a well ventilated area... -
Page 16: Maintenance
MAINTENANCE • Before performing any maintenance always disconnect propane gas tank. • Keep the heating item free and clear from combustible materials. • Visually inspect burner for obstructions and keep tank enclosure free and clear from debris. • Use a soft brush to get rid of the mild stains, loose dirt and soil after the burner is completely cooled down.
