Quikserv QSB-12 Service Manual

Bullet resistant drawer
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
Service Manual
QSB-12 & QSB-12S
Rough Opening - QSB-12S (W/O FLANGE): 28 1/4" x 15 3/4"
Rough Opening - QSB-12S (W/ FLANGE): 28 3/4" x 16"
Quikserv Corp.
©
Service Manual
Service Opening - 13 1/4" x 9" x 23"
Rough Opening - QSB-12: 18 1/4" x 15 3/4"
Click the Procedure to View
quikserv.com
• -800-388-8307 • Fax (73) 849-5708

QSB-12 & QSB-12S
2
3
4
5
6
7
8
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QSB-12 and is the answer not in the manual?

Questions and answers

Related Manuals for Quikserv QSB-12

Summary of Contents for Quikserv QSB-12

  • Page 1: Table Of Contents

    Service Manual Service Opening – 13 1/4” x 9” x 23” Rough Opening – QSB-12: 18 1/4” x 15 3/4” Rough Opening – QSB-12S (W/O FLANGE): 28 1/4” x 15 3/4” Rough Opening – QSB-12S (W/ FLANGE): 28 3/4” x 16”...

  • Page 2: Operation And Maintenance Procedures

    QSB-12 & QSB-12S Service Manual QSB-12 & QSB-12S Operation and Maintenance Procedures Bullet Resistant Drawer Operation and Maintenance Procedures Operation Procedures • Unlock all locking mechanisms and ensure that the drawer is free of obstructions. • Operate the drawer and return to the closed position.

  • Page 3: Rear Carriage Lock Assembly Replacement

    QSB-12 & QSB-12S Service Manual Rear Carriage Lock Assembly Replacement - Part No. 8006 . Remove 0 screws holding back panel to drawer. . Remove back panel. 3. Slide the  back sections apart to access the lock assembly. 4. Remove the 4 screws holding the lock assem- bly to the back panel.

  • Page 4: Rail Replacement

    QSB-12 & QSB-12S Service Manual Rail Replacement - Part No. 8008 . Push open drawer; remove 4 screws on the Figure 2 bottom interior drawer that holds rails to the bottom of drawer. Rail . Remove 4 screws on the bottom part of han- dle (part # 8807) from interior drawer.

  • Page 5: Coil Spring Removal

    QSB-12 & QSB-12S Service Manual Coil Spring Removal - Part No. 8021 . Remove  bolts holing spring bracket assem- Figure 3 bly (part # 8808). . Remove spring from bracket. Coil Spring 3. Replace with new spring. 4. After replacing the spring, reverse the above procedures using removable Loc-Tite on screws.

  • Page 6: Rear Loading Door Lock Assembly

    QSB-12 & QSB-12S Service Manual Rear Loading Door Lock Assembly - Part No. 8805 . Remove the  screws holding the lock as- Figure 4 semble to back panel. . Replace with new lock assemble (part #8806). 3. Replace  screws using removable Loc-Tite.

  • Page 7: Removal Of Handle Assembly

    QSB-12 & QSB-12S Service Manual Removal of Handle Assembly - Part No. 8807 . Remove 6 screws on cover panel and remove Figure 5 cover. . Move handle unit 7/6” bolt show in hole slot. a. Remove nut from inside drawer handle.

  • Page 8: Roller Wheel Replacement

    QSB-12 & QSB-12S Service Manual Roller Wheel Replacement - Part No. 1032 . Push open drawer and remove 4 screws on Figure 6 the bottom interior drawer that holds the rails to the bottom of drawer. Rail . Remove 4 screws on the bottom part of han- dle (part #8807).

  • Page 9: Warranty Service Policy

    Warranty Service Policy 1. Quikserv Corp. MUST be notified of a war- 7. Quikserv Corp. needs to be notified of any ex- ranty situation before any work is performed. tra parts - either to be sent back or to be kept Otherwise, Quikserv Corp.
