Summary of Contents for Cardo Systems PACKTALK EDGE

  • Page 2: Table Of Contents

    CONTENTS 1. Introduction 2. Getting Started 2.1 Getting to Know Your PACKTALK EDGE 2.2 Charging Your PACKTALK EDGE 2.3 Switching Your Unit On/Off 2.4 Using Your PACKTALK EDGE 2.5 Pairing Your Unit to Bluetooth Devices 3. Cardo Connect App 3.1 Registering your unit 3.2 Updating your unit 4.

  • Page 3: Introduction

    1. INTRODUCTION Thank you for choosing the Cardo PACKTALK EDGE communication and entertainment system for motorcycle helmets. We wish you a great PACKTALK EDGE experience and encourage you to visit www.cardosystems.com/support/packtalk-edge regarding any questions, suggestions or comments you may have. If you have not yet installed the PACKTALK EDGE unit on your helmet, please install it as described in the Installation Guide provided in the package.

  • Page 4: Getting Started

    2. GETTING STARTED 2.1 GETTING TO KNOW YOUR PACKTALK EDGE 2.2 CHARGING YOUR PACKTALK EDGE Make sure that your PACKTALK EDGE battery is charged for at least 4 hours before initial use. To charge the unit: 1. Using the supplied USB cable, connect your computer or wall charger to the USB port on your PACKTALK EDGE.

  • Page 5: Switching Your Unit On/Off

    While charging, the LED indicates the charging status as follows: Red LED on — charging ● Red LED off — charging complete ● TIP: You can check the battery charge at any time in the Cardo Connect App, or by saying "Hey Cardo, battery status".

  • Page 6: Pairing Your Unit To Bluetooth Devices

    2.5 PAIRING YOUR UNIT TO BLUETOOTH DEVICES Your PACKTALK EDGE has two Bluetooth channels for connection to Bluetooth devices such as mobile phones, GPS devices, and TFT Bike Infotainment. To connect your unit to a Bluetooth device, you must first pair them. Once paired, they automatically recognize each other whenever they are within range.
  • Page 7 c. For a second phone, roll the wheel forward. The led flashes red and blue. 4. On the device you are pairing, search for Bluetooth devices. 5. When your PACKTALK EDGE appears in the list of available devices, select it. If prompted for a PIN or Passkey, enter 0000 (four zeros). If prompted to allow pairing on your phone, allow it.

  • Page 8: Cardo Connect App

    3. CARDO CONNECT APP The Cardo Connect App enables you to configure the settings of your PACKTALK EDGE. In addition, the App offers you remote controlled operation from the screen of your smart.phone. 3.1 REGISTERING YOUR UNIT 1. Download the Cardo Connect App. 2.

  • Page 9: Updating Your Unit

    3.2 UPDATING YOUR UNIT Before using your unit for the first time, and whenever a new software update is available, make sure to have the latest software update. Updating with the latest software keeps your unit free of bugs and provides you with additional new functionalities.

  • Page 10: On The Road

    4. ON THE ROAD PACKTALK EDGE makes it easy for you to receive phone calls and listen to music in a convenient and safe manner. 4.1 BASIC AUDIO FUNCTIONS The basic audio functions are the same whether you are listening to music, speaking on the intercom, or having a phone conversation.

  • Page 11: Making And Receiving Phone Calls

    4.2 MAKING AND RECEIVING PHONE CALLS You can use your mobile phone to make and receive phone calls while paired to your PACKTALK EDGE. You can make a hands-free call using your mobile phone's voice dial option or using the Cardo speed dial or redial last call options.

  • Page 12: Switching Between Two Calls On Two Mobile Phones

    If you connected two mobile phones to your unit, you cannot make an additional phone call from the ● other phone while a phone call is already active. During Bluetooth intercom 3 or 4-way calls, riders that are connected on both channels A and B cannot ●...

  • Page 13: Streaming Music

    To toggle between two calls on two mobile phones (without disconnecting either call): and the intercom button simultaneously. ● To disconnect the current call and switch to the other call: and the intercom button simultaneously. ● 4.3 STREAMING MUSIC You can stream music from your paired device to your PACKTALK EDGE. To start music streaming from your paired device: Tap the Media Button or say "Hey Cardo, music on".

  • Page 14: Listening To Fm Radio

    To skip back to the previous track (while streaming): Tap the media button twice or say "Hey Cardo, previous track". ● To share music with another rider: Press the Intercom button for 2 seconds or say "Hey Cardo, share music". ●...
  • Page 15 To turn on the FM radio: twice or say "Hey Cardo, radio on". ● When you switch on your FM radio, the station that was playing when you last switched off resumes playing. To turn the FM radio off: Tap the Control Wheel or say "Hey Cardo, radio off". ●...
  • Page 16 To scan for and select a station: 1. Tap 3 times. The FM radio plays each station that it finds for several seconds. 2. When you hear a station you want to select, tap To store a scanned station in the active preset: Use the Cardo Connect App on your mobile device.

  • Page 17: Voice Commands

    To toggle between FM and ATDP music: Press for 2 seconds. ● 4.5 VOICE COMMANDS You can use voice commands for hands-free operation of certain PACKTALK EDGE features. Voice commands use natural voice operation. You loudly say a command and PACKTALK EDGE performs the action.

  • Page 18: Riding With Others

    5. RIDING WITH OTHERS Your PACKTALK EDGE features three distinct intercom communication modes: the traditional Bluetooth protocol, Live Intercom,and the Cardo's Dynamic Mesh Communications (DMC) technology. DMC is the best way to communicate in a group. In DMC mode, you can instantly create or join a dynamically- fluid network of up to 15 riders to communicate in full conference mode.

  • Page 19: Using Dmc Intercom

    If your DMC group splits with some group members remaining in range of each other but not in range of all group members, you can continue speaking with the members still in range. Once in range of any other group member, you automatically reconnect.
  • Page 20 To bridge a non-DMC passenger/rider: To add a Bluetooth passenger, use the Cardo Connect App: To start/stop a non-DMC passenger intercom: 3 times. ● 5.1.2.2 CHATTING PRIVATELY You can chat privately with a specific member of your DMC group. This option is also available using the Cardo mobile app. To chat privately: 1.
  • Page 21 2. To start /stop a private chat, tap twice. 5.1.2.3 MUTING/UNMUTING DMC INTERCOM GROUPS Muting the DMC intercom mutes your microphone and speaker for the intercom group communication. Your microphone and speakers are still active for phone calls and music. Unmuting brings you back to the group conversation.

  • Page 22: Bluetooth Intercom

    5.1.2.5 MULTIPLE AUDIO SOURCES AND VOLUME MANAGEMENT The PACKTALK EDGE can use parallel audio streaming to stream audio from two connected sources simultaneously, so that you can listen to your music or the FM radio while holding a DMC intercom conversation. PACKTALK EDGE automatically manages your music and FM radio volume while using DMC intercom.
  • Page 23 Select Intercom Switch to Bluetooth mode Select the Bluetooth rider Bluetooth intercom pairing needs to be initiated on the other device. 3. To add a 3rd rider: Bluetooth intercom pairing needs to be initiated on the other device. 4. To add a 4th rider, Rider 1 or Rider 2 connects to the additional rider.

  • Page 24: Using The Bluetooth Intercom

    5.2.2 USING THE BLUETOOTH INTERCOM 5.2.2.1 STARTING/ENDING BLUETOOTH INTERCOM CALLS To start or end communication with a rider: once or say "Hey Cardo, call intercom" or "Hey Cardo end intercom". ● To start or end communication with Rider 2: twice or say "Hey Cardo, call intercom" or "Hey Cardo end intercom". ●...

  • Page 25: Sharing Music

    5.3 SHARING MUSIC You can share music with a passenger or other rider. Music can be shared with only one passenger/rider. ● Bluetooth intercom calls are disabled when sharing music. ● If you paired your unit to two mobile phones, music will be shared from the mobile phone through which ●...

  • Page 26: Switching Between Intercom Modes

    5.4 SWITCHING BETWEEN INTERCOM MODES Your PACKTALK EDGE unit can work in only one intercom mode at a time. The current intercom mode is indicated by the color of the LED: When in DMC intercom mode, the LED flashes green at approximately 4-second intervals. ●...

  • Page 27: Troubleshooting

    6. TROUBLESHOOTING 6.1 SOFT RESET If your PACKTALK EDGE stops responding, reset it in one of these ways: Turning it off and then on again (see Switching Your Unit On/Off). ● Rebooting the unit, by simultaneously pressing for 10 seconds. ● 6.2 RESET TO FACTORY SETTINGS This option deletes all paired units, devices and all configuration settings.

  • Page 28: Personalizing Your Device

    7. PERSONALIZING YOUR DEVICE Get the most out of your PACKTALK EDGE by changing the settings and customizing your unit according to your own personal preferences, using the Cardo Connect App on iOS or Android devices. Cardo recommends you customize your settings before going out on the road. You can adjust any of ●...

  • Page 29: Audio Source Priorities

    You can configure parallel audio streaming via the Cardo app. 7.2 AUDIO SOURCE PRIORITIES PACKTALK EDGE manages the audio sources you hear through the speakers according to the following audio source priorities. Priority Audio Source Higher Priority GPS device instructions ↑ Phone calls Lower Priority Music or Intercom...

  • Page 30: Support

    All rights reserved. Cardo, the Cardo logo and other Cardo marks are owned by Cardo and may be registered. All other trademarks are the property of their respective owners. Cardo Systems assumes no responsibility for any errors that may appear in this document. Information contained herein is subject to change without notice.
