Summary of Contents for Konica Minolta Q-M100
- Page 2 Names of main parts/Camera body ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ① Flash mode switch ⑨ ② Self-timer/Close-up mode switch ⑩ ③ Image quality mode switch ④ Data display panel (LCD) ⑤ Shutter release button ⑥ Viewfinder ⑪ ⑦...
- Page 3 ⑰ ⑱ ⑲ ⑳ 控 攻 ⑰ Viewfinder 昂 ⑱ MENU button 晃 ⑲ SET button ⑳ SELECT buttons 更 控 LCD monitor 攻 Battery cover 昂 Green lamp 杭 晃 Monitor power switch 更 Card access warning lamp 校 杭...
- Page 4 ① ② ③ ④ ⑨ ⑧ ⑦ In the following picture, all indicators of the data display panel ⑤ are on for explanation. ① Battery's remaining energy indicator Remaining energy of the battery is indicated in three steps of ] (full), [ ⑥...
- Page 5 ⑤ Flash mode indicator Each time the flash mode switch is pressed, indication of this indicator circularly changes from 1) automatic flash (AUTO), to 2) automatic flash with red-eye reduction, to 3) forced flash (ON), to 4) forced flash with red-eye reduction, to 5) non-flash (OFF), and to 1) again for selection of a desired flash mode.
- Page 6 Name of main parts/LCD monitor 1.Ⓐ Ⓒ Ⓑ Ⓓ ● The LCD monitor is used for many purposes such as to show playback pictures, to preview pictures and to show menus for selecting various functions. For details of each function or operation, read explanations on and after the next page.
- Page 7 2.ⓐ ⓓ ⓑ ⓔ ⓒ ⓕ 2. Functions that can be selected by pressing the MENU button in the playback mode are shown below. (Number appearing in the lower right part of each menu shows the menu number.) (Each time the SELECT button (“ ” or “ ”) is pressed, the following menus are circularly shown by turn.) ⓐ...
- Page 8 ⓘ ⓖ ⓗ (1) MENU button To access menus on the LCD monitor. (2) SET button To execute a selected function. (3) SELECT buttons To select a function from a menu. (4) Monitor power switch To turn on/off the LCD monitor.
- Page 9 Setting batteries in camera 1. First of all, close the lens barrier without fail. (Slide the lens barrier switch upwards.) 2. Make sure that the LCD monitor on the back of the camera is off.
- Page 10 3. Slide the battery cover on the bottom of the camera in the direction of the arrow to open it. Warning: Don’t touch the battery cover with wet hand, otherwise you may get an electric shock. 4. Set AA-size batteries (four) in the battery chamber paying careful attention to their respective orientations referring to + and - indications inside the battery chamber.
- Page 11 5. After confirming that all batteries are set right, firmly close the battery cover by sliding it in the direction of the arrow until it clicks. * When the battery's remaining energy indicator indicates the half level, the batteries need replacement. When replacing the battery, prepare four new batteries of the same type to replace all at the same time.
- Page 12 Use of AC adaptor (optional accessory) for Q-M100 * If you use an optional AC adaptor for Q-M100 to supply power to the camera, you can transfer picture data to a personal computer without worry about remaining energy of batteries.
- Page 13 2. Make sure that the LCD monitor on the back of the camera is off. 3. Open the I/O cover.
- Page 14 4. Plug the cord connector of the AC adaptor into the power input terminal of the camera. Next, plug the AC adaptor in to a mains outlet (Input 100V ∼ 240V, 50/60Hz AC). <figure> ① CLOSE ② OPEN ③ LCD monitor...
- Page 15 Setting CF card in camera ● First of all, make sure that the lens barrier is closed, the LCD monitor is off and all the power switches are off. If the camera is turned on in whole or in part, it may cause damage to the camera and a CF card set in the camera. 1.
- Page 16 (2A) (2B) 2. Paying heed to the orientation of a CF card, insert it straight into the deepest end. (2B) ○ Be sure to insert a CF card correctly referring to the figure 2A for orientation of the CF card. If a CF card is inserted in wrong orientation, the connector may be damaged.
- Page 17 4. Close the CF card cover. Caution: ○ If the CF card cover is opened during playback of picture, the camera is compulsorily turned off. Before inserting or setting a CF card, be sure to turn off the camera. Don’t open the CF card cover while the card access warning lamp is on in the shooting mode, otherwise operation of picture data writing on a CF card is interrupted.
- Page 18 Removing CF card from camera ● First of all, make sure that the lens barrier is closed, the LCD monitor is off and all the power switches are off. If the camera is turned on in whole or in part, it may cause damage to the camera and a CF card set in the camera.
- Page 19 2. Raise the CF card ejector button. 3. Press the CF card ejector button to stick out the CF card, then pick it out of the camera. * If the CF card cannot be stuck out by pressing the CF card ejector button, again push the CF card into the deepest end and press the CF card ejector button strongly once more.
- Page 20 4. Shut the CF card cover. Caution: ○ If the CF card cover is opened during playback of picture, the camera is compulsorily turned off. Before inserting or setting a CF card, be sure to turn off the camera. Don’t open the CF card cover while the card access warning lamp is on in the shooting mode, otherwise operation of picture data writing on a CF card is interrupted.
- Page 21 Use of strap (attachment) and soft case (attachment) <Fitting strap to camera> 1. Pass the shorter and thinner end of the strap (supplied with the camera) through the strap eyelet of the camera. ○ Since it is considerably hard to pass the strap end through the strap eyelet, use a toothpick or the like to do it.
- Page 22 <Putting camera into soft case> 1. When putting the camera into the soft case (supplied with the camera), insert the flashlight side first as shown in the figure on the left. 2. After putting the camera in the soft case, lid the soft case.
- Page 23 Setting calendar and clock ● Before starting calendar setting, make sure that batteries are properly set in the camera or a specified AC adaptor is connected to supply power to the camera and the lens barrier is closed (the lens barrier switch is set at “CLOSE”).
- Page 24 2. Press the MENU button once. The “Erase” icon reversely appears on the screen. * When no CF card is set in the camera or no picture is recorded on the inserted CF card, a message “No pictures in camera” appears on the LCD monitor.
- Page 25 4. Press the SET button. The camera enters into a calendar setting mode for “Year”. Set “Year” by pressing the SELECT button (“ ” or “ ”). * If the MENU button is pressed in this status, the previous setting is canceled and the camera (screen) status returns to the step 3.
- Page 26 6. Press the SET button. The camera enters into a calendar setting mode for “Day”. Set “Day” by pressing the SELECT button (“ ”or “ ”). * If the MENU button is pressed in this status, the previous setting is canceled and the camera (screen) status returns to the step 3.
- Page 27 8. Press the SET button. The camera enters into a clock setting mode for “Minute”. Set “Minute” by pressing the SELECT button (“ ”or “ ”). * If the MENU button is pressed in this status, the previous setting is can- celed and the camera (screen) status returns to the step 3.
-
Page 28: Taking Pictures
Taking pictures ● Firmly hold the camera by both hands and slightly compress your sides by elbows to stabilize the camera. ● For flash photography in vertical camera position, hold the camera with the flashlight up. ○ Carefully hold the camera not to cover the flashlight and lens with the strap or fingers. - Page 29 ① ② * If both the green and red lamps are blinking, it is impossible to take pictures. In this case, the following causes are thinkable. 1) The CF card has no room for writing data in the selected data compression mode. 2) There is no CF card set in the camera.
- Page 30 1. Slide the lens barrier switch downwards to set it at the “OPEN” position. The lens barrier is opened and the camera is turned on. * Open/close the lens barrier by operating the lens barrier switch only. 2. Compose a picture looking through the viewfinder, and lightly press the shutter release button.
- Page 31 3. Moreover press the shutter release button to actuate the shutter. With beep sound, the shooting is complete. After that, the camera starts writing picture data on the CF card. 4. The sandglass mark appears on the indicator panel, and the sand part of the sandglass starts blinking while the card access warning lamp goes While the card access warning lamp is on, the camera does not accept any operation because data writing is performed in this period.
- Page 32 ● Automatic power-off operation If the camera is left without operation for more 5 minutes as it is turned on, the automatic power-off function is activated to turn off the data display panel and LCD monitor, therefore, the batteries are prevented from getting consumed. To cancel the automatic power-off mode after it is activated, slide the lens barrier switch upwards to set it at the “CLOSE”...
- Page 33 Switching image quality (resolution) mode ● Each time the image quality mode switch is pressed, the “ ” mark moves on the data display panel to indicate an image quality mode one after an- other repeatedly. * An image quality mode set once is fixed for continuous shooting, but it is reset to the “FINE”...
- Page 34 2. When the image quality mode switch is pressed once, the image quality mode is switched to the “SUPER FINE”. * With switching of the image quality mode, number of frames available for future shooting changes. 3. When the image quality mode switch is pressed once more, the image quality mode is switched to the “ECONOMY”.
- Page 35 Use of each image quality mode 1) “SUPER FINE” mode: 1152 (horizontal) × 872 (vertical) pixels. Use this mode that records picture in the highest image quality (finest resolution) to shoot important objects worthy to preserve or to edit pictures on a personal computer, etc. 2) “FINE”...
- Page 36 Switching flash mode ● Each time the flash mode switch is pressed, one of five flash modes appears in turn on the data display panel. * The flash mode set once is fixed for continuous shooting, but it is reset to the “AUTO”...
- Page 37 2. If the flash mode switch is pressed once in the “AUTO” mode, the “ ” mark is selected and the flash mode is changed to the “red-eye re- duction automatic flash mode”. In this mode, the fiashlight emits light twice for a shot, namely preliminary emission and actual emission, to control red-eye phenomenon.
- Page 38 4. If the flash mode switch is moreover pressed, the and the flash mode is changed to the “red-eye reduction forced flash mode”. In this mode, the flashlight emits light twice for a shot, namely preliminary emission and actual emission, to control red-eye phenome- non.
- Page 39 Recommended object distance for flash photography: 0.5 m to 3.0 m approx. ※ If object distance is shorter than 0.5 m, the picture (camera subject) comes out too brightly. ※ If object distance is longer than 3.0 m, the picture (camera subject) comes out darkly because the flash has no effect on the distant object.
- Page 40 Self-timer photography/Close-up ● Each time the self-timer switch is pressed, one of three modes is selected one after another as indicated on the data display panel. 1. When the self-timer switch is pressed once, the close-up mode is se- lected with an indication on the data display panel. Use the close-up mode for shooting an object at a short distance of 0.2 m to 0.8 m.
- Page 41 2. When the self-timer switch is pressed twice, the camera enters the self-timer mode with an indication on the data display panel. In the self-timer photography mode, the shutter opens about 10 seconds after the shutter release button is pressed. Through the period from pressing the shutter release button and practical operation of the shutter, the self-timer lamp blinks.
- Page 42 Regarding self-timer photography ● On taking pictures with self-timer, carefully set up the camera on a tripod or a horizontal stable plane. ● The self-timer mode is canceled each time self-timer photog- raphy is complete. If you want to continue to take pictures with self-timer, set the self-timer switch for each photography.
- Page 43 Photographing with focus lock ※ Make sure that the mark is bright. 1. Aim at the camera subject with the auto-focus frame and then lightly press the shutter release button. The green lamp goes on to indicate that the focus is locked at the aimed point. * If the shutter release button is released from pressure of finger, fo- cus-lock is canceled and the camera is ready for next focus lock opera- tion.
- Page 44 Normal playback/Double magnified playback ● Close the lens barrier and confirm that a CF card which picture data is recorded on is set in the camera and the camera is turned on with power of batteries or an AC adaptor. 1.
- Page 45 2. The picture taken last with the CF card appears on the LCD monitor screen. Data on the picture such as the date* when the picture was taken, frame protection information (key mark), image quality mode and frame number of the picture are shown on the screen together with the picture.
- Page 46 When no CF card is set in the camera or a CF card on which no picture data is recorded is set in the camera, a message “No pictures in camera” appears on the monitor screen. In this case, no picture is shown on the screen.
- Page 47 Double magnified playback When the SET button is pressed in the condition that a picture is being played back on the LCD monitor, the picture is magnified double in its center part. If the SET button is pressed again, the magnified playback is canceled and the picture is played back normally.
- Page 48 Adjusting brightness of LCD monitor ● Before adjustment of brightness of LCD monitor, close the lens barrier and confirm that a CF card which picture data is recorded on is set in the camera and the camera is turned on with power supplied from batteries or an AC adaptor.
- Page 49 2. Press the MENU button once. The “Erase” icon is reversely shown on the screen. * If the MENU button is pressed again in this status, the last operation is canceled and the display of the previous step 1 appears again. 3.
- Page 50 4. Press the SET button. The camera enters the LCD monitor brightness adjustment mode. The cursor in the center indicates the standard level. 5. If the SELECT button is pressed, the cursor moves rightwards (to “+” side) and the screen becomes brighter. If the SELECT button is pressed, the cursor moves leftwards (to “-”...
- Page 51 6. If the SET button is pressed after brightness adjustment, the last setting of the brightness is saved and the display is changed for that of the pre- vious step 1. * The saved data on brightness adjustment will be maintained regardless of operation of the lens barrier and monitor power switch unless it is re- placed with new data.
- Page 52 Playback with TV set ● You can look at pictures on a TV screen. However, pictures that can be seen with a TV set are limited to playback pictures only and preview pic- tures cannot be seen on a TV screen. ●...
- Page 53 2. Connect the video output cord (supplied with the camera) to the camera's video port and the video input terminal of a TV set. After connection between the camera and a TV set is complete, turn on the TV set and set the input source selector of the TV set to “VIDEO”. 3.
- Page 54 * Read the instructions of the apparatus to be connected with this camera together. * When the Q-M100 is connected with a video apparatus by the through-connection video input terminal, make sure that nothing is con- nected to the same video input terminal except the Q-M100.
- Page 55 Getting icons to appear on TV screen ① ② ① Setting of frame protection ② Erase ③ Information on Frame protection ④ Image quality mode ⑤ Frame number ⑥ Index playback ⑦ Slide show ※Select a desired icon with the SELECT button. ●...
- Page 56 ● Picture can be double zoomed-in on a TV screen. ● If the video output cord is connected/disconnected to/from the video port during index playback, the picture that is selected at that time appears without the frame number on the display (LCD monitor or TV set) switched on by connection/disconnection of the video output cord, and the index playback is automatically canceled at the same time.
- Page 57 Applied operation/Use of preview function ● The preview function helps you to take well-composed pictures. ● Open the lens barrier and confirm that the camera is turned on with power supplied from batteries or an AC adaptor. 1. Press the monitor power switch to turn on the LCD monitor. The LCD monitor serves as a viewfinder and you can see the same im- age as the lens catches.
- Page 58 2. Press the shutter release button halfway, and the focus and exposure are locked. Press the shutter release button furthermore, and the shutter is opened to record the same image as shown on the LCD monitor. * The image to be recorded is shown through recording. With completion of recording, the monitor returns to the “through image display”...
-
Page 59: Compensation Of Exposure
Compensation of exposure ● Open the lens barrier and confirm that the camera is turned on with power supplied from batteries or an AC adaptor. ● Exposure can manually be compensated in the range of ±2 in EV (Expo- sure Value). 1. - Page 60 2. Press the MENU button once. The “Exposure” icon reversely appears on the screen and the “through image” appearing on the screen becomes a still picture. * If the MENU button is pressed in this status, previous setting is canceled and the display of the LCD monitor returns to the status of the step 1.
- Page 61 4. Each time the SELECT button ( moves step by step. When the SELECT button is continuously pressed, the indicator bar moves leftwards to decrease exposure time (under-exposure). When the SET button is pressed in this status, the “through image” is darkened. When the SELECT button is continuously pressed, the indicator bar moves rightwards to increase exposure time (over-exposure).
- Page 62 ● Setting of exposure compensation is maintained until the lens barrier is closed. When the lens barrier is opened again after it was once closed, the ex- posure is set at the initial status (indicator bar in the center position). ●...
- Page 63 4-frame continuous shooting function/Digital 2x Zoom ● The continuous shooting function snaps four consecutive scenes at a time and records them together in a frame. A frame of four pictures is composed of 576×436 pixels, and each of four pictures is composed of 288×218 pixels, namely a quarter of the frame.
- Page 64 2. Press the MENU button once. The “Exposure” icon reversely appears on the screen. * If the MENU button is pressed in this status, previous setting is canceled and the display of the LCD monitor returns to the status of the step 1. * Select the “Brightness adjustment”...
- Page 65 4. The “Normal shooting” icon is generally selected at this stage and the camera is accordingly set in the normal shooting mode. * If the MENU button is pressed, previous setting is canceled and the dis- play of the LCD monitor returns to the status of the step 1. * If the camera has been set in the “Continuous shooting”...
- Page 66 6. A blue frame ⓐ appears on the screen and a “through image” appears in the frame. Since the blue frame represents the continuous shooting mode, you can take continuous snapshot of four scenes each in this condition. * In the continuous shooting mode, the flashlight is inactivated. For shooting a dark object, it is recommended to use a tripod or lighting ap- paratus.
- Page 67 8. When recording of a series of four shots is complete, a “through image” in a blue frame appears on the screen. * In this status, the camera is still set in the continuous snapshot mode. If you want to discontinue the continuous snapshot mode and to take a picture in the normal shooting or zoom-in mode, repeat the above-mentioned steps 2 and 3 to select the “Normal shooting”...
- Page 68 10. A red frame ⓑ appears on the screen and the double magnified center part of a “through image” is shown in the frame. This red frame repre- sents the digital 2x zoom-in mode. If a picture is taken in this mode, the magnified center part is recorded on a CF card by a resolution of 1152×872 pixels.
- Page 69 ● To return to the normal shooting mode To reset the camera to the normal shooting mode, carry out one of the following means. 1) Repeat the above-mentioned steps 2 and 3 to select the “Normal shooting” icon. After selecting it, press the SET button. (See the figure on the left.) 2) Press the monitor power switch to turn off the “through image”...
- Page 70 Erasing recorded pictures in part or in whole ● First of all, confirm that the lens barrier is closed and the camera is turned on with power supplied from batteries or an AC adaptor. 1. Press the monitor power switch to turn on the LCD monitor. * When no CF card is set in the camera or a CF card on which no picture is recorded is set in the camera, a message “No pictures in camera”...
- Page 71 2. To erase recorded pictures one by one, select a desired picture with the SELECT button ( (To erase pictures recorded on the CF card in whole, proceed to the step 3. Press the MENU button once. The “Erase” icon reversely appears on the screen.
- Page 72 4. Press the SET button. Three erasing modes are shown on the screen. Press the SELECT button ( ) to select “This”, “NO” or “ALL”. * If the MENU button is pressed at this stage, the display returns to the status of the step 3.
- Page 73 6. If the SET button or the MENU button is pressed with selection of “NO”, the display returns to the status of the step 3. 7. To erase all pictures recorded on the CF card set in the camera, select “ALL”...
- Page 74 8. In case of the status shown by the left figure, “NO” is selected. Select “YES” and press the SET button to erase all the frames, or press the SET button as “NO” is selected if you don't want to erase all the frames.
- Page 75 9. If there is a protected frame on the CF card, a message “No pictures in camera” appears on the screen after the erasing operation is complete. At that time, a frame that was taken last among protected frames is shown on the screen.
- Page 76 To protect important pictures against erasing (Setting of frame protection) ● Important pictures can be protected from careless erasure by setting of the frame protection. ● Before starting setting, confirm that the lens barrier is closed and the camera is turned on with power supplied from batteries or an AC adaptor. 1.
- Page 77 2. Press the MENU button once, and the “Erase” icon reversely appears on the screen. * When no CF card is set in the camera or a CF card on which no picture is recorded is set in the camera, a message “No pictures in camera” appears on the screen.
- Page 78 When the selected frame has been protected, (3B) (3B) 4. To protect a selected frame: With the display of the figure 3A, press the SET button. The selected frame is protected against erasing and the display returns to the status of the step 1. If the MENU button is pressed for the SET button, the display returns to the status of the step 1 without setting of erasure protection for the se- lected frame.
- Page 79 To cancel erasure protection of a selected frame: With the display of the figure 3B, press the SET button. The selected picture is released from erasure protection and the display returns to the status of the step 1. If the MENU button is pressed for the SET button, the display returns to the status of the step 1 without canceling the erasure protection of the frame.
- Page 80 Looking at multiple pictures at a time (index playback) ● Before starting setting, confirm that the lens barrier is closed and the camera is turned on with power supplied from batteries or an AC adaptor. 1. Press the monitor power switch to turn on the LCD monitor. * When no CF card is set in the camera or a CF card on which no picture is recorded is set in the camera, a message “No pictures in camera”...
- Page 81 2. Press the MENU button once, and the “Erase” icon reversely appears on the screen. * When no CF card is set in the camera or a CF card on which no picture is recorded is set in the camera, a message “No pictures in camera” appears on the screen.
- Page 82 4. The display turns into the index playback menu. If the SELECT button ( ) is continuously pressed, the cursor (indi- cation box) moves on frames one after another. When the cursor passes the last frame, the nine frames appearing on the screen are replaced by the next nine frames, if there are.
-
Page 83: Slide Show Playback
Slide show playback ● In the slide show playback mode, recorded pictures can be seen one by one from the first frame. ● Before starting operation of the slide show playback, confirm that the lens barrier is closed and the camera is turned on with power supplied from batteries or an AC adaptor. - Page 84 2. Press the MENU button once, and the "Erase" icon reversely appears on the screen. * When no CF card is set in the camera or a CF card on which no picture is recorded is set in the camera, a message "No pictures in camera" appears on the screen.
- Page 85 4. After the last picture is shown on the screen, the display returns to the status of the step 3. * If the SET button is pressed at this stage, slide show playback starts again with the CF card set in the camera. * When pictures are shown on the camera's LCD monitor screen in the slide show playback mode, respective frame numbers of the pictures are also shown on the screen.
- Page 86 Formatting (initializing) CF card ● First of all, confirm that the lens barrier is closed and the camera is turned on with power supplied from batteries or an AC adaptor. ● When formatting (initializing) a used CF card, mind that all recorded pictures are erased by formatting if pictures are protected from erasing.
- Page 87 2. Press the MENU button once and the “Erase” icon reversely appears on the screen. * When no CF card is set in the camera or a CF card on which no picture is recorded is set in the camera, a message “No pictures in camera” appears on the screen.
- Page 88 4. To execute formatting of the CF card, select “YES” by pressing the SE- LECT button ( ).Then, press the SET button to start formatting the CF card. * If the SET button is pressed with selection of “NO”, formatting mode is canceled and the display returns to the status of the step 1.
- Page 89 Switching from NTSC TV system to PAL TV system ● For playback with a TV set, this camera is initially set for the NTSC TV system on shipment. For playing back pictures with a TV set in the area of the PAL TV system, the camera needs to switch the initial setting for the NTSC TV system to the PAL TV system.
- Page 90 2. Press the MENU button once. A scene which shows the “Erase” icon reversely appears on the screen. * When no CF card is set in the camera or nothing is recorded on a CF card set in the camera, a message “No pictures in camera” appears on the display.
- Page 91 ※ For switching the setting from the NTSC TV system to the PAL TV system, perform the same operation as the steps from 1 through 3. In this case, the “P” icon appearing in the step 3 is reversely shown because the camera is set for the PAL TV system.
- Page 92 TV systems in main countries ・ A TV set or video monitor having a video input connector of either NTSC or PAL TV system can be used for playing back pictures taken by the camera. ・ For connecting the camera with such a TV set or video monitor, a VIDEO OUTPUT cord supplied with the camera is necessary.
- Page 93 Setting buzzer inactive ● Confirm that the lens barrier is closed and the camera is turned on with power supplied from batteries or an AC adaptor. 1. Press the monitor power switch to turn on the LCD monitor. * When no CF card is set in the camera or a CF card on which no picture is recorded is set in the camera, a message “No pictures in camera”...
- Page 94 2. Press the MENU button once, and the “Erase” icon reversely appears on the screen. * When no CF card is set in the camera or a CF card on which no picture is recorded is set in the camera, a message “No pictures in camera” appears on the screen.
- Page 95 ※ When the buzzer icon appears as in the figure of the step 3, the buzzer has already been set inactive (OFF). In such the case, press the SET button to set the buzzer active (the “Buzzer ON” icon replaces the “Buzzer OFF”...
- Page 96 Explanation of “Auto white balance” What is white balance? Human eyes have such an adaptability as they recognize the color of a white object as white even when the color of lighting changes. This digital still camera senses color temperature of the light source and adjust the white balance according to the sort of the light source so that a white object can be reproduced as white as possible.
- Page 97 * Plug the 8-pin connector of the connecting cord into the camera's serial port jack. To disconnect the connecting cord from the camera’s serial port, refer to the instruction manual for Q-M100. ⓐ To serial port of personal computer. ⓑ Since the type of personal computer’s connector differs from personal computer to personal computer, carefully read the installation manual and use a proper connector or adaptor for connecting the cord.
- Page 98 2. Open the camera's lens barrier and turn on the personal computer. When the lens barrier is opened, “PC” appears on the camera's data dis- play panel. 3. When batteries are used as the power source, the battery mark continues blinking while the camera is being on.
-
Page 99: Personal Computer
Directly reading/writing data saved on CF card with personal computer ● If a CF card adaptor (available on the market) is used, data saved on a CF card can directly be read or rewritten with a personal computer, be- cause a CF card adaptor deals with a CF card as an ATA card conform- ing to the PCMCIA TYPEⅡ... - Page 100 2. Set a CF card adaptor in the slot of a personal computer which is capable of reading ATA card and has a slot designed to accept an ATA card con- forming to the PCMCIA TYPEⅡ standard. * For details of the setting, refer to the instructions of the personal com- puter to be used.
-
Page 101: Error Message
Error message ● When the remaining exposure counter reads “Err” and all indicators appearing on the indicator panel are blinking, there is an error in camera control. If the camera falls into such the status: 1) close the lens barrier, if it is open, and 2) press the MONITOR POWER switch to turn off the LCD monitor. - Page 102 Specifications in brief...
