E INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zoom I60c and is the answer not in the manual?

Questions and answers

Related Manuals for Konica Minolta Zoom I60c

Summary of Contents for Konica Minolta Zoom I60c

  • Page 1 E INSTRUCTION MANUAL...

  • Page 2: Table Of Contents

    CONTENTS For Proper and Safe Use ... 4 Thank you for your purchasing this camera. Before using your new GETTING STARTED camera, please take the time to read Names of Parts... 10 through this instruction manual for it Attaching the Camera Strap ... 14 contains important information on the Inserting the Battery ...

  • Page 3: For Proper And Safe Use

    FOR PROPER AND SAFE USE Read and understand all warnings and cautions before using this product. WARNING Using batteries improperly can cause them to leak harmful solutions, overheat, or explode which may damage property or cause personal injury. Do not ignore the following warnings: •...
  • Page 4 • If the product emits a strange odor, heat, or smoke, discontinue use. Immediately remove the batteries taking care not to burn yourself. The continued use of a damaged product or part may cause injuries. • Take the product to a Konica Minolta Service Facility when repairs are required. CAUTION •...
  • Page 5 FOR PROPER AND SAFE USE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 6: Getting Started

    NAMES OF PARTS BODY The quartz-date model is illustrated. AF window* Meter window* Remote-control receiver* (p. 50) (Quartz-date model only) Self-timer/Remote-control lamp* (p. 41, 52) * This camera is a sophisticated optical instrument. Care should be taken to keep these surfaces clean.
  • Page 7 NAMES OF PARTS DATA PANEL All indicators are displayed for clarity. Date/Time display (p. 44 ) (Quartz-Date model only) Flash-mode indicators (p. 32 ) Autoflash Autoflash with red-eye reduction Fill-flash Continuous-advance indicator (p. 42 ) Flash cancel Self-timer indicator (p. 40 ) Night Portrait (with red-eye reduction) VIEWFINDER...

  • Page 8: Attaching The Camera Strap

    ATTACHING THE CAMERA STRAP 1. Pass the small loop of the 2. Pass the the other end of • Button keys are attached to the strap. Use the larger key to open the battery-chamber door, and the smaller key to push the manual-rewind button. Button keys INSERTING THE BATTERY strap through the strap...

  • Page 9: Battery-Condition Indicator

    BATTERY-CONDITION INDICATOR Each time the camera is turned on, an indicator will appear on the data panel to indicate the power status of the battery. The indicator briefly appears. Power is sufficient for all camera operations. The indicator blinks. Power is sufficient for camera operation, but the battery must be replaced soon.
  • Page 10 LOADING THE FILM 2. Place the film cartridge into the film chamber. 3. Extend the film leader to the film-tip mark. The film must lay flat. • If the film tip extends beyond the index mark, push the excess film back into the cartridge. GETTING STARTED 4.

  • Page 11: Basic Operation

    FULLY AUTOMATIC OPERATION 1. Press the main switch to turn the camera on. • To conserve battery power, the auto-power- off function will turn the camera off eight minutes after the last operation. • Do not obstruct or hold the lens barrel. 2.
  • Page 12 FULLY AUTOMATIC OPERATION 4. Place the subject within the focus frame and press the shutter-release button partway down. • The status of the AF system and flash are indicated by the lamps next to the viewfinder. Focus frames Focus lamp (green) Glows : focus confirmed Blinks rapidly : subject is too close...

  • Page 13: Focus Lock

    FOCUS LOCK The focus-lock function allows the camera to be focused on a certain subject and then the picture can be recomposed to arrange the subject at a different position within the image area. 1. With subject in the focus frame, press and hold the shutter-release button partway down.

  • Page 14: Special Focusing Situations

    SPECIAL FOCUSING SITUATIONS The camera may not be able to focus in certain situations. At this time, the focus-lock function (p. 24) can be used to focus on an object at the same distance as your subject, and then the image can be recomposed to take the picture.

  • Page 15: For Closer Subjects

    FOR CLOSER SUBJECTS Close-framing guides Because of parallax, the image seen in the viewfinder and the image recorded with the camera are not exactly the same. Parallax becomes significant with close subjects. Use close-framing guides to eliminate the effect of parallax.

  • Page 16: Rewinding The Film

    REWINDING THE FILM The camera automatically rewinds the film after the last exposure is taken. When the cartridge mark blinks on the data panel, the film has been rewound. Open the back cover and remove the film. • The film-chamber lock is release during rewind.

  • Page 17: Selecting The Flash Mode

    SELECTING FLASH MODE Press the flash-mode button until the desired flash-mode indicator appears on the data panel. The following flash modes can be selected: Autoflash (p. 35) Autoflash with red-eye reduction (p. 36) Fill-flash (p. 37) Flash cancel (p. 38) Night portrait (p.

  • Page 18: Flash Range

    FLASH RANGE The flash range depends on the film speed and focal length in use. Because of the optical system, the flash range is not the same at the lens’ wide-angle position as it is at the telephoto position. To ensure proper exposure, the subject must be within the flash range.

  • Page 19: Autoflash With Red-Eye Reduction

    AUTOFLASH WITH RED-EYE REDUCTION The flash will fire a few short bursts before the main flash burst to reduce red-eye; an effect caused by light reflected from the retina. Used in low-light condition when taking photographs of people or animals, the pre-flashes contract the pupils of the subject’s eyes.

  • Page 20: Flash Cancel

    FLASH CANCEL The flash will not fire in this mode. Use flash cancel when flash photography is prohibited, natural light is desired to illuminate the subject, or the subject is beyond the flash range. The camera-shake warning may appear in this mode. Press the flash-mode button until the flash- cancel indicator appears on the data panel to set the flash mode.

  • Page 21: Self-Timer

    SELF-TIMER The self-timer is used for taking self-portraits. The self-timer delays release of the shutter for approximately 10 seconds after the shutter-release button is pressed. 1. With the camera on a tripod, press the drive- mode button until the self-timer indicator appears on the data panel.

  • Page 22: Continuous Advance

    CONTINUOUS ADVANCE In this mode, the camera continuously takes pictures as long as the shutter-release button is held down. The camera will take one picture every 2.2 seconds. When the flash is used, the rate may be slower because the flash must recharge between frames.

  • Page 23: For Owners Of The Quartz-Date Model

    FOR OWNERS OF THE QUARTZ-DATE MODEL The quartz-date model has date and time imprinting and remote-control operation. DATE AND TIME IMPRINTING The imprinting feature enables the date or time to be printed onto the lower-right portion of the picture. The date is recorded as the film is advanced to the next frame.
  • Page 24 FOR OWNERS OF THE QUARTZ-DATE MODEL SETTING THE DATE OR TIME Note: the date and time must be reset each time the battery is replaced. 1. Turn the camera on. Press the date button until “SEt ” appears on the data panel. 2.
  • Page 25 FOR OWNERS OF THE QUARTZ-DATE MODEL • Pressing the select (SEL) button until the date/time display stops blinking can also set the calendar and clock. CHANGING THE DATE FORMAT 1. Press the date button until “SEt” appears on the data panel. 2.

  • Page 26: Remote Control Operation

    FOR OWNERS OF THE QUARTZ-DATE MODEL REMOTE CONTROL OPERATION The quartz-date model can be controlled by the IR remote control RC-3 (sold separately). The remote control allows remote camera operation up to 5 meters (16.5 feet) away. • Focus lock cannot be used with the IR remote control. NAMES OF PARTS Emitter window Delay button...
  • Page 27 FOR OWNERS OF THE QUARTZ-DATE MODEL 3. Point the remote control toward the front of the camera and press either the release button (•) or the delay button (2s) to take the picture. • If the release button (•) is pressed, the self- timer/remote-control lamp on the front of the camera will blink once before the picture is taken.

  • Page 28: Appendix

    CARE AND STORAGE OPERATING TEMPERATURE AND CONDITIONS • This camera is designed for use from -10 to 40°C (14 to 104°F). • Never leave the camera where it may be subjected to extreme temperatures such as in the glove compartment of a car. •...
  • Page 29 CARE AND STORAGE • When photographing in cold weather, it is recommend that you keep the camera and spare batteries inside your coat to keep them warm when you are not shooting. Cold batteries will regain some of their charge when they warm •...
  • Page 30 BEFORE IMPORTANT EVENTS • Check camera operation carefully and take test photographs. Purchase a spare battery. • Konica Minolta is not responsible for any loss which may occur due to an equipment malfunction. CAMERA ERROR If all the indicators on the data panel blink, or the data panel is blank and the camera will not function with a recently installed battery, remove and reinsert the battery.

  • Page 31: Technical Specifications

    Tele: 0.95 - 2.0 m (3.1 - 6.6 ft.) Battery: One 3-volt CR123A lithium battery Battery-condition indication: 3-stage indication Battery performance: approx. 14 rolls based on Konica Minolta's standard test method using 24-exposure rolls with flash for 50% of the exposures. Viewfinder: Magnification: 0.37X - 1.46X...
  • Page 32 MEMO MEMO...
  • Page 33 © 2003 Konica Minolta Camera Inc. under the Berne Convention and the Universal Copyright Convention 0-43325-53159-0 9222-2479-11 NI-B401 Printed in China...
