OPERATION
▲ This product is suitable for users over 14 years old.
▲ Stay away from the rotating propeller
▲ Read the "important statement and safety guidelines" carefully.
https://udirc.com/disclaimer-and-safety-instructions
Wasted Lithium-Polymer batteries must not be placed with household
trash. Please contact local environmentalor waste agency or the
supplier of your model or your nearest Li-Po battery recycling center.
Our company's products are improving all the time, design and specifications are
subject to change without notice. All the information in this manual has been
Important
carefully checked to ensure accuracy, if any printing errors, our company reserve
Notice
the final interpretation right.
UDI008/UDI020
GUIDE
Suitable for sailing in ponds
Li-Po Battery Disposal & Recycling
Note
01
Advertisement
Table of Contents
Related Manuals for udir/c UDI008
Summary of Contents for udir/c UDI008
- Page 1 UDI008/UDI020 OPERATION GUIDE Suitable for sailing in ponds Note ▲ This product is suitable for users over 14 years old. ▲ Stay away from the rotating propeller ▲ Read the “important statement and safety guidelines” carefully. https://udirc.com/disclaimer-and-safety-instructions Li-Po Battery Disposal & Recycling Wasted Lithium-Polymer batteries must not be placed with household trash.
- Page 2 Ready before sailing Preparation the boat Cabin outer cover Deck Outer cover lock Tail rudder Hull bottom Spindle tube Outlet Propeller Right navigation Tail rudder Bracket Rods Support bracket Left navigation Battery Charge Battery power is insufficient in the original plant. It must be charged saturated before it can be used. Connect the charging case to the charging input port of the boat battery and then connect the USB output ports.
- Page 3 Boat battery installation method 1) Twist to left or right to open the outer cover lock. 2) Open up the cabin cover. Cabin Inner Cover 3) According to the mark on the surface of the inner cover, unlock the lock and take out the inner cover upward.
- Page 4 Transmitter Preparation Forward Trim Backward Trim Power Indicator Steering Wheel Left Rudder Trim Right Rudder Trim Throttle Trigger Power Switch Backward Trim Forward trim If the boat still moves If the boat still moves forward when the throttle backwards when the throttle trigger is in the middle trigger is in the middle position, press backward...
- Page 5 Sailing Operation Frequency Pairing Please make sure the transmitter throttle trigger and Steering wheel to normal. 1) Power on the transmitter, will sound “di”, and the indicator light flashes, then to enter frequency pairing. 2) After the boat battery is installed and powered on, tighten the hatch cover. 3) Put the boat into the water, the transmitter will sound “didi”, and the indicator will keep long bright it means frequency pairing successful.
- Page 6 Self-Righting Hull If the boat capsizes, Push forward and backward the throttle trigger of the transmitter and then pull back at once. The boat will then return to normal, the capsize reset function will turn off automatically when the boat in low battery. Low Battery Alarm Boat: When the boat in low battery, the transmitter will beep “di.di.di.
- Page 7 Replac the steering gear Disassembly： The steering gear is Turn off the power of boat ④ separated from the steering gear arm. ③ Unscrew the Steering gear steering gear arm screws. Tie rod arm of steering gear ② ② Unscrew steering Steering gear gear and fixing screws and then take out fixing...
- Page 8 FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
