U12S
USER
MANUAL
This helicopter can aerial photography and
transmitted in real time image.
▲This product is suitable for users over 14 years old.
▲Stay away from the rotating propeller
▲Read the<important statement and safety guidelines >carefully.
Ready before take off
Helicopter preparation
Tail Propeller
Navigation Lights
Battery Jack
Charging Instruction
Battery power is insufficient in the original plant.
It must be charged saturated before it can be used.
Connect the battery of the helicopter with the charging cable configured in
the original factory, and then connect it to other USB charging ports.
The indicator light of USB charger is red when charging.
And the light turns green when fully charged.
Balance Bar
Upper Propeller
Lower Propeller
Camera
Battery Slot
Power Switch
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U12S and is the answer not in the manual?

Questions and answers

Summary of Contents for udir/c U12S

  • Page 1 Ready before take off Helicopter preparation Balance Bar Tail Propeller U12S Upper Propeller USER Lower Propeller Navigation Lights Camera MANUAL Battery Jack Battery Slot Power Switch This helicopter can aerial photography and transmitted in real time image. Charging Instruction Battery power is insufficient in the original plant.
  • Page 2: Battery Installation

    Battery Installation ▲ Only use the original charging ② ① line; suggest select Adapters Open the battery cover of the Transmitter and place the same type of with output current of 5V 2A . USB adapter Original USB battery with saturated capacity according to the '+-' electrode indication in (Not Include) Charging Cable the battery cell (Not include).
  • Page 3: Flight Operations

    Flight Operations Control Stick Operation Left Stick Mobile phone connect with helicopter Go Up Go Down Download and install App: Flyingsee This software is suitable for mobile phones in the iOS and Android system. For detailed operation, Right Stick please check the system “HELP” of App. Transmitter connect with helicopter Forward Counterclockwise...
  • Page 4 Emergency Stop: During the flight, press "take off/land" for about 2 Flying Trimmer seconds, the transmitter will sound "di. di..." and the helicopter crashes directly. Left and right turning trimmer Press down During the flight, if the helicopter head rotates to Tip: Do not use the emergency stop function unless in emergency situation.
  • Page 5: Troubleshooting

    If there is damaged, please replace the new accessories or prone to Tips: the above data are the test data of UDIRC lab, for reference only. accident. Parameter Troubleshooting Helicopter Flight Battery Model: U12S Capacity: 350 mAh Problem Problem cause Solution Weight: 70.6g (Typical value) Voltage: 3.7 V Low battery.
  • Page 6: Fcc Note

    Wasted Lithium-Polymer batteries must not be placed with household trash. Please contact local environmental or Metal-Scout Model: U12S Manufacture time: waste agency or the supplier of your model or your nearest Manufacturer company: SHANTOU CITY CHENGHAI UDIRC TOYS CO., LTD Li-Po battery recycling center.
