Sea-King Fully Stabilized Marine Satellite System

9815-RJ

9818-RJ

Installation and Operating Instructions

MEMBER

Satellite Solutions for Mobile Markets

11200 Hampshire Avenue South, Bloomington, MN 55438-2453

Phone: (800) 982-9920

Fax: (952) 922-8424

www.kingcontrols.com

1315 REV A

Table of Contents

Need help?

Do you have a question about the 9815-RJ and is the answer not in the manual?

Questions and answers

Summary of Contents for King Controls 9815-RJ

Page 1 ® Sea-King Fully Stabilized Marine Satellite System 9815-RJ 9818-RJ Installation and Operating Instructions MEMBER ® Satellite Solutions for Mobile Markets 11200 Hampshire Avenue South, Bloomington, MN 55438-2453 Phone: (800) 982-9920 Fax: (952) 922-8424 www.kingcontrols.com 1315 REV A...
Page 3: Table Of Contents
The satellite TV market is expanding and changing. The information in this manual was accurate at the time of printing. If your Sea-King System does not operate as outlined in this manual please call King Controls at (800) 982-9920 or visit our website at www.kingcontrols.com.
Page 4: Introduction
SECTION 1 The Sea-King Fully Stabilized Marine Satellite System includes 4 main components (Fig. 1). Dome (Antenna) Unit Controller Tuner Power Supply Note: A TV, satellite receiver, and program subscription are also required for satellite TV viewing. (Not supplied by King Controls.) Fig.
Page 5: Definition Of Terms
SECTION 2 AZIMUTH: Angle in degrees measured clockwise from Magnetic North (0°) (Fig. 2). Fig. 2 ELEVATION: Angle in degrees measured from the ground plane (Fig. 3). Fig. 3 SIGNAL STRENGTH: Intensity of electronic signal received from the satellite transmission. DEFINITION OF TERMS Page 3...
Page 6: Installation
SECTION 3 TOOLS AND MATERIALS REQUIRED: - drill and drill bit set - tape measure - 7/16” open end wrench (coax connections) - 5/32” allen wrench, channel lock or pliers (to remove shipping bolt) - 1/8” allen wrench or phillips screw driver (to remove dome cover) - appropriate fasteners and tools to install all components and wiring - adhesive sealant, compatible with vessel material KIT CONTENTS:...
Page 7 The shortest distance between the dome unit and the main satellite receiver is most desirable. b) The dome unit requires either a 16.5 inch (9815-RJ) or 20 inch (9818-RJ) diameter mounting area on the vessel surface, or an industry standard mount (call King Controls for more information).
Page 8 1. Remove and save the dome cover screws. (Figs. 6A and 6B). 2. Carefully remove the dome cover, tilting it side to side as necessary to prevent damaging internal components. 3. Remove and discard the shipping bolt. Page 6 9815-RJ = Fig. 6A 9818-RJ = Fig. 6B...
Page 9 Fig. 6A 9815-RJ IMPORTANT! CAREFULLY remove the dome cover, tilting it side to side as necessary to prevent damaging internal components. Fig. 6B 9818-RJ IMPORTANT! CAREFULLY remove the dome cover, tilting it side to side as necessary to prevent damaging internal components.
Page 10 NEVER lift the unit by the LNB assembly, Wave Guide assembly, or the dish. 4. Place the dome unit on its mounting pedestal and temporarily secure the unit from falling. DO NOT PERMANENTLY MOUNT THE DOME UNIT UNTIL YOU HAVE COMPLETED THE SYSTEM LOCATION CHECK ON THIS PAGE.
Page 11 DOME INSTALLATION AND EXTERNAL WIRING IMPORTANT! USE ONLY THE COAXIAL CABLES SUPPLIED WITH THE SEA-KING. DO NOT CUT COAX. COIL AND STORE EXCESS CABLE IN THE CABINET WITH THE COMPONENTS. If coaxial cable other than that supplied with the Sea-King is used, the following guide lines must be followed: 1) Ends must be terminated with SNAP-N-SEAL F-compression style connectors as shown in Fig.
Page 12 IMPORTANT! The installer is responsible for weatherproofing all holes in the vessel. Note: The installer is responsible for determining the most appropriate fastener to secure the dome unit to the pedestal or vessel surface. Depending on the surface material, fasteners such as lag screws, well nuts, sheet metal screws, toggle bolts and T anchors may be used.
Page 13 2. Connect 50’ coax cable to the coax port labeled MAIN on the bottom of the dome unit and tighten connection. If using a second receiver, connect second 50’ coax cable to the unlabeled port and tighten connection. DO NOT OVER TIGHTEN CONNECTIONS (Fig.
Page 14 The coaxial cable that connects the dome unit to the tuner carries a 24 volt electrical current. Exercise extreme caution when handling this cable. Do not cut, break, or splice this line. Do not insert or connect any devices such as splitters or any other device for any reason.
Page 15: Wiring Diagram
Fig. 10 9815-RJ 9818-RJ WIRING DIAGRAM IMPORTANT! AVOID SHARP BENDS WHEN ROUTING COAX. Page 13...
Page 16 MULTIPLE SATELLITE RECEIVER CONFIGURATIONS With the use of an active multi-switch (not supplied by King Controls), more than two TV’s and receivers can be hooked up (see Fig. 11 for typical 4 receiver hookup). Other options: 3-4 satellite receivers: use one 2x4 or 3x4 active multi-switch 8 satellite receivers: use one 2x8 or 3x8 active multi-switch 16 satellite receivers: use one 3x16 active multi-switch King Controls recommends the use of an active multi-switch.
Page 17 TYPICAL 4 RECEIVER HOOKUP Fig. 11 IMPORTANT! AVOID SHARP BENDS WHEN ROUTING COAX. Page 15...
Page 18 OPTIONAL WALL MOUNT FACEPLATE (INCLUDED) Note: If not using the faceplate, see faceplate removal instructions below. IMPORTANT! Depending on the thickness of the vessel wall, a relief notch may need to be cut for the cable. THE CABLE MUST NOT BE PINCHED OR BENT WHEN MOUNTING THE DISPLAY.
Page 19 OPTIONAL TUNER MOUNTING BRACKETS (INCLUDED) 1. Remove 4 screws from the tuner. 2. Fasten mounting brackets to tuner with same screws (Fig. 14). Fig. 14 Note: The installer is responsible for determining the most appropriate fasteners to secure the mounting brackets to the chosen surface. 3.
Page 20: Operation
SECTION 4 IMPORTANT! There must be a clear “line of sight” to the satellite (See Fig. 2, Page 3). Terrain, other boats, buildings, trees, masts, telephone poles, etc. can all block the satellite signal from reaching the dish. Note: This example is for the DTV 101 satellite in Region 2-North Central. The information on your controller will vary depending on the satellite and region you have chosen.
Page 21 Note: To reduce satellite acquisition time, you can set your current region. SET REGION (OPTIONAL) REGION OPTIONS: NORTH WEST NORTH CENTRAL NORTH EAST CENTRAL WEST MIDDLE CENTRAL CENTRAL EAST SOUTH WEST SOUTH CENTRAL SOUTH EAST ALL REGIONS RECALIBRATE Page 19...
Page 22 SET SATELLITE SERVICE DISH 61 EXPVU 91 DISH 129 DISH 148 EXPVU 82 DTV 101 Sat 110 Sat 119 DTV 101/ 110 hd DTV 101/ 119 Note: The King Controls HD TV Converter Box (#9747 or #9747-AM) is required to receive HD programming from the DIRECTV satellite at 110. Page 20 SATELLITE OPTIONS Dish Network at 61...
Page 23 Note: For DIRECTV Subscribers: The satellite setting allows the user to select the satellite and service provider of choice. For DIRECTV subscribers, the Sea-King can also track a secondary or alternate satellite. Example: If you are a subscriber to the DIRECTV service most of the programming that you will be watching will be transmitted from the satellite located at 101 degrees.
Page 24: Troubleshooting
SECTION 5 SYMPTOM Controller does not power up. Controller remains in one of the following conditions: POWER TRIP ANT COM ERROR? TUNER COM ERROR? Controller displays AZ FAULT. Dish cannot rotate. Display reads EL FAULT. Page 22 TROUBLESHOOTING POSSIBLE SOLUTION Check: tuner is connected to power supply.
Page 25 SYMPTOM Only getting signal on 1/2 of transponders. Unit never locks on or locks on and drifts off of satellite. POSSIBLE SOLUTION Kinked or sharply bent coax cable. Verify coax cables are tightly crimped with F-compression style crimps only. Verify receiver is operating properly. Verify LNB type is set correctly.
Page 26 OPTION 21 RE-INITIALIZE and 0-RECALIBRATE Page 24...
Page 27 Page 25...
Page 28 IMPORTANT! You must call King Controls before performing this procedure. IMPORTANT! The Sea-King must remain perfectly still during the mechanical calibration. The Sea-King must be running (NOT IN IDLE/HOLD). Page 26 MECHANICAL CALIBRATION...
Page 29: Maintenance
MAINTENANCE SECTION 6 The Sea-King Satellite System has been designed to be maintenance and trouble free. For optimum signal strength, keep the dome clean from dirt, bugs, and other debris. Periodic washing of the dome with mild soap and water is recommended. If you plan on storing your vessel for long periods of time, it is recommended that the system be put through a search procedure on a quarterly basis to keep all moving parts in good working order.
Page 30: Limited Warranty
SECTION 7 Every King Controls Satellite System is thoroughly inspected and tested before leaving the factory. It is covered by a two year parts and one year labor limited warranty from the date of original purchase. This warranty does not cover installation and external wiring or refurbished units.
Page 32 ® 11200 Hampshire Avenue South, Bloomington, MN 55438-2453 Phone: (800) 982-9920 Fax: (952) 922-8424 www.kingcontrols.com...
