Summary of Contents for King Controls Jack AU8200
- Page 3 EXTERIOR BASE MOUNT INSTALLATION (FIG. 2) IMPORTANT! The installer is responsible for determining the most appropriate fastener to secure the base mount to the roof and weatherproofing all holes with sealant. The installer is responsible for sealing all existing holes when replacing an existing antenna mount.
- Page 4 INTERIOR ENCLOSURE INSTALLATION (FIG. 3) IMPORTANT! The rotation knob only fits on the end of the adjustable connector in one direction. SEE INSET BELOW. 1. Press knob button and remove knob from enclosure base. 2. Make sure the coax exits the roof thru the enlarged portion of the roof hole and route the coax thru the coax hole in the enclosure base.
