- Page 1 DIVERSE MAGMETER MF300H+ MAGNETIC FIELD STRENGTH METER USER MANUAL Version 1.5 2/22 CAMBRIDGE ENGLAND CB22 5EW www.diverse-technologies.net Page 1...
-
Page 2: Table Of Contents
Contents PREFACE INTRODUCTION FIRST TIME Zeroing QUICK START OPERATION Plug in the Field Probe Power On/Off Zero Select Reading Options Display Options Set up Menu Select units Average Samples Logger Serial Autoranging Serial Output Logging mode Review Clear Serial Period Start About MAGNETIC PARTICLE INSPECTION... -
Page 3: Preface
Thank you for purchasing MagMeter. Before using the unit, please read these instructions carefully. If you are uncertain about any aspect of its operation, please contact Diverse our contact details are at the end of this manual. The serial interface version of this product is provided with software to run on a PC. -
Page 4: Introduction
Introduction The MF300H+ Magnetic Field Meter is used to measure the intensity and the direction of magnetic fields. The meter can be used to show the actual value of the intensity of the magnetic field as an average, peak or RMS value. The measured values can be presented in a range of units and the chosen options can be selected from a menu displayed on the... -
Page 5: First Time
Windows PC. To do this download the zip file from our web site. To install on Windows, navigate to the download folder then: Use Program Manager: run file Double click on INSTALL.BAT. The software will be copied to your hard disc C:\diverse. Page 5... -
Page 6: Zeroing
Quick start 1. Plug in the field probe. 2. Load the AA batteries in to the battery compartment ensuring that the polarity is correct 3. Press the power button, the unit will switch on. 4. Press the down button and select the mode displayed at the top right hand side of the display. -
Page 7: Operation
Operation The Magmeter has 4 keys: power tick down The keys second meanings if held down for more than 2 seconds. The step by step instructions that follow provide all the key information about operation of the instrument. Note that unless otherwise specified, any readings referred to are in Gauss. -
Page 8: Select Reading Options
Operation - Options Step 4 Select Reading Options The MF300H+ can display the Average, Absolute peak, Peak or RMS value of the magnetic field. To go from one to the another, press the down key each time. The nature of the current display is shown on the top right hand corner of the screen. -
Page 9: Set Up Menu
Operation - Sep up Step 5 Set up Menu At the main display long press the tick key to see the Set up menu. This has 6 options: 5.1 Select units To Select the Units of measurement, long press the tick key to get to the setup menu, then press the tick key... -
Page 10: Samples
Operation - Logger 5.3 Samples This allows the number of samples to be selected for RMS mode. In this mode, samples are taken, squared and summed. Finally they are averaged and the square root taken. The normal setting is 64, but options are 4,16, 64 and 256 available. The number of samples controls time response of the instrument in RMS mode. -
Page 11: Serial Output
Operation - Autorange Step 6 Autoranging The letters in the top left hand corner of the display indicate if the instrument is set to autoranging or manual range selection. The possible letters and their meanings are as follows: AL = Autoranging with range on the lowest most sensitive setting. -
Page 12: Logging Mode
Operation - Logging Step 8 Logging mode From the set up menu select Logger. 8.1 Review This presents the logged data in groups of 4 to the extent of the logger database. You can scroll through the data with the up/down keys. Any other key exits. Data is stored as a x10 integer i.e. -
Page 13: Magnetic Particle Inspection
Operation - MPI Magnetic Particle Inspection A wide range of magnetising systems are used for Magnetic Particle Inspection. The value of the magnetic flux density required is specified in BS4069 as 0.72 Tesla. This is produced when the magnetising coils generate a magnetic field of 2.4kA/m which is applied to a component made from material with a relative permeability of 240. - Page 14 Page 14...
-
Page 15: Software
Operation - Software Software The serial version of the MF300H+ is supplied with software to run on a windows (10/7/Vista/XP) PC, see First Time for information about installation. The program name is: MAGW.EXE. Its operation is as follows: Download the zip file from our website. Unpack all the files to the directory in which you want to work (there is no separate installation file). - Page 16 If you do not want to use the logging software provided, then you can use any serial terminal software such as Hyperterminal supplied free with Windows. Free updates to the logging software are placed on our web site: http://www.diverse-technologies.net Page 16...
-
Page 17: Specification
MF300H+ Specification Accuracy: Transverse probe +/- 1% of full scale Axial Probe +/- 2% of full scale Operating Temperature: 0C to +40C. The instrument has temperature compensation for the Hall probe. Units: mT, T, G, kA/m, Oe, kA at distance Range: 0 - 1.99T, autoranging. -
Page 18: Units
Units Symbol ______________________________________________ Magnetic Flux Maxwell Weber Flux Density Gauss Tesla Magnetising force Oersted A-T/m Permeability 4*pi() E-7 of free space ______________________________________________ A-T/m is Ampere-Turns/m Conversion Factors Multiply by To Obtain _____________________________________ Gauss 1E-4 Tesla Oersted 79.577 A-T/m _____________________________________ In a vacuum or air then B= H, then mu0=1 so: Flux density B in Gauss = Magnetising Field H in Oersteds. -
Page 19: Low Battery
Low battery If the MF300H+ displays the legend "Low Battery" on the bottom row of the display when the batteries are low. When the batteries are low the bar graph facility is not available. If you are using rechargable cells then recharge them using a suitable charger. -
Page 20: Calibration And Repair
Diverse Technologies. The cost for this is the same or less than that charged by institutions such as BSI or NPL. If the MF300H+ requires repair, the unit should be returned to Diverse, there are no user serviceable parts. - Page 21 Business users should ensure that this product is not mixed with other commercial waste for disposal. Diverse Technologies accepts no responsibility for the consequential losses arising from the ability or inability to use the equipment supplied. The limit of...
