- Page 1 DIVERSE MF300Fe+ FERRITE METER USER MANUAL DIVERSE CAMBRIDGE ENGLAND CB22 5EW www.diverse-technologies.net 03/2018 Page 1...
-
Page 2: Table Of Contents
Contents PREFACE INTRODUCTION FIRST TIME QUICK START OPERATION FERRITE PERCENTAGE SOFTWARE SPECIFICATION LOW BATTERY LIABILITY CALIBRATION & REPAIR DISPOSAL & RECYCLING 03/2018 Page 2... -
Page 3: Preface
Diverse, our contact details are at the end of this manual. The MF300Fe+ is the latest version of the Diverse Ferrite Meter. It has a large number of features including: ● Robust slimline probe ●... -
Page 4: Introduction
FN but the relationship depends upon the type and origin of the stainless steel used and the measurement technique (see section on Ferrite %) The Diverse Ferrite meter MF300Fe+ measures the Ferrite number (FN) of austenitic and duplex stainless steel weld material. -
Page 5: First Time
● Load the USB driver onto your computer using the CD supplied ● Download the serial software from: http://www.diverse- technologies.net/software/magmeterserial.zip ● Unpack the files into a directory. To run the software click on MagmeterSerial.exe (for convenience we recommend you... -
Page 6: Quick Start
Quick start 1. Plug in the ferrite probe. 2. Load four AA batteries in to the battery compartment ensuring that the polarity is correct. 3. If you have the gas cooled option and are using hot samples connect a gas/air-line, regulated to 2 bar, to the probe using the fitting provided. -
Page 7: Operation
Operation The Ferrite meter has 4 keys: ℹ power �tick �up �down The ℹ power, �tick, �up and �down keys have a second meanings if held down for more than 2 seconds. The step by step instructions that follow provide all the key information about operation of the instrument. - Page 8 Operation - Display Options Step 4 Display Options 4.1 Top line 4.1.1 Record number On the top line the number of the next available record in the database is displayed on the left. There are 1000 available records (0-999) and the current measurement value can be saved by pressing the ℹ...
- Page 9 Operation - Display Options continued This value will be displayed as FN or F%, to toggle between these units press and hold the �up key. Note that the instrument is calibrated using FN standards and that the reported F% is calculated using a conversion graph (see section on Ferrite percentage) 4.3 Third line...
- Page 10 If the transfer standards do not read accurately after a user calibration then the instrument should be returned to Diverse for factory calibration. Press �tick key to select user calibration.
- Page 11 Operation - Menu continued 5.4 View data log (Viewlog) This displays the log of saved ferrite records, 4 records per screen. To cycle through the records use the �up or �down keys, long press �up or �down keys to move 100 records, any other key to leave.
-
Page 12: Ferrite Percentage
Ferrite percentage Ferrite Percentage Calibration standards exist for ferrite number (FN) and the MF300Fe+ is calibrated using secondary ferrite number standards supplied by NIST. The volume percentage of ferrite can be estimated roughly as about 70% of the FN particularly at higher FN (ref 1). However, the relationship depends upon the type and origin of the stainless steel used and the measurement technique. -
Page 13: Software
Software Software The serial version of the MF300Fe+ is supplied with software to run on a windows (7/Vista/XP/2000) PC, see First Time for information about installation. The program name is: MagmeterSerial.exe. Its operation is as follows: Download files from: http://www.diversetechnologies.net/software/magmeterserial.zip. Unpack and copy all the files to the directory in which you want to work (there is no separate installation file). - Page 14 Hyperterminal supplied free with Windows XP. Free updates to the logging software are placed on our web site: http://www.diverse-technologies.net 03/2018 Page 14...
- Page 15 Software - MF300Fe+ Software - MF300Fe+ The instrument provides for storage of up to 1000 sample records. Each record is accompanied by a 4 character ID which is used to identify the place where the measurement is taken. If you do not want to use the ID then on sampling the sample number is used.
- Page 16 Software - MF300Fe+ Recording a new reading into the database Make a short press of the ℹ power key. A new line will be displayed at the bottom of the screen. This will display the current record number on the left, the Ferrite measurement value to be stored and the record ID.
- Page 17 Software - MF300Fe+ Database control in Windows software The actions are controlled by the menus and the ribbon of buttons. Button ID Function Start Opens the communication port and establishes connection provided hardware set-up and correct port selected Closes current connection Sample Request sample from meter Clear...
- Page 18 Software - MF300Fe+ record number. - Upload site IDs, the user is able to upload a database of IDs to the instrument which can be used to prompt the user for specific sites. - Upload site IDs and ferrite numbers allows the instrument database to be restored.
-
Page 19: Specification
Oil filtered supply desirable Air temperature: ambient (10°C - 30°C) Humidity Non-condensing Weight in case 1.25 kg Case dimensions 210 x 100 x 45 mm Support Call/email Diverse for support for use of the instrument or assistance with unusual application. 03/2018 Page 19... -
Page 20: Low Battery
Low battery If the MF300Fe+ displays the legend "Low Battery" on the bottom row of the display when the batteries are low. When the batteries are low the bar graph facility is not available. Do not use the instrument when the batteries are low as the accuracy may be compromised. -
Page 21: Liability
Liability Diverse Technologies accepts no responsibility for the consequential losses arising from the ability or inability to use the equipment supplied. The limit of warranty is the repair or replacement of any faulty components, directly attributable to manufacturing defects, arising during the period of 12 months following purchase. - Page 22 Instruments returned to Diverse for calibration or repair, from outside the EU, must be imported into the UK using simplified IPR customs procedure. If this is not carried out then duties will be incurred that Diverse will have to pass on. If in doubt contact Diverse. 03/2018...
- Page 23 Disposal and Recycling This instrument should be deposed of in a responsible manner to allow the components within it to be recycled. The wheelie bin symbol shown here and on the product means that the product is classed as Electrical and Electronic Equipment and should not be disposed with other household or commercial waste at the end of its working life.
