  • Page 1 OTDR OTDR OPTICAL TIME DOMAIN REFLECTOMETER ZS1000-A 2020/09 U S E R ' S M A N U A L...
  • Page 2: Table Of Contents

    CATALOGUE CATALOGUE Warning and note Introduction of the machine OTDR-Measurement Interface OTDR-Average Measurement OTDR-Real-time measurement OTDR-Event list OTDR-Cursor selection and waveform zoom in/out Menu Menu-Files Menu-Measurement Settings Menu-System Settings Menu-About OPM(optional) Upgrading and Charging Detail parameters...
  • Page 3: Warning And Note

    OTDR OTDR ZS1000-A ZS1000-A OPTICAL TIME DOMAIN REFLECTOMETER Introduction of the machine OPTICAL TIME DOMAIN REFLECTOMETER Warning and note WARNING Any undefined change or modification of this manual will deprive you of the right to operate the equipment. To reduce the risk of fire or electric shock, do not expose the equipment to rain or humidity. To prevent electric shock, please do not open the shell, and it must be repaired by qualified personnel.
  • Page 4: Otdr-Measurement Interface

    OTDR OTDR ZS1000-A ZS1000-A OTDR-Average Measurement OPTICAL TIME DOMAIN REFLECTOMETER OTDR-Measurement Interface OPTICAL TIME DOMAIN REFLECTOMETER Press "SCAN" button to start average measurement. When finished, press "File button to enter the storage interface. " Battery Date and time 2020-06-01 17:25 2020-06-01 17:25 50.00...
  • Page 5: Otdr-Real-Time Measurement

    OTDR OTDR ZS1000-A ZS1000-A OPTICAL TIME DOMAIN REFLECTOMETER OTDR-Real-time measurement OTDR-Event list OPTICAL TIME DOMAIN REFLECTOMETER During measuring, you can change range, change the cursor position, zoom in or out (see P7 for details). Press "ENTER" button to show the whole event list. Select an event, then press " ENTER" button to return and locate If you turn on RT analyse, it will analyse events when you press "REAL"...
  • Page 6: Otdr-Cursor Selection And Waveform Zoom In/Out

    OTDR OTDR OTDR-Cursor selection and ZS1000-A ZS1000-A Menu OPTICAL TIME DOMAIN REFLECTOMETER waveform zoom in/out OPTICAL TIME DOMAIN REFLECTOMETER Keep pressing " " button, then press Up/Down button to zoom in or out vertically, press Left/Right button to zoom 2020-06-01 17:25 System Set.
  • Page 7: Menu-Files

    OTDR OTDR ZS1000-A ZS1000-A Menu-Measurement Settings OPTICAL TIME DOMAIN REFLECTOMETER Menu-Files OPTICAL TIME DOMAIN REFLECTOMETER Press "MENU" button or "File" button to enter the files interface. Wavelength 2020-06-01 17:25 System Set. Files Files Measure Set. Module About About 1310nm 1550nm Wavelength 2020-06-01 17:25...
  • Page 8: Menu-System Settings

    OTDR OTDR ZS1000-A ZS1000-A Menu-System Settings OPTICAL TIME DOMAIN REFLECTOMETER OPTICAL TIME DOMAIN REFLECTOMETER Menu-About 2020-06-01 17:25 Files Measure Set. System Set. About Switch by right/left button 2020-06-01 17:25 Common Storage Administration Other Default storage device information System Set. Files Files Measure Set.
  • Page 9: Opm(Optional)

    OTDR OTDR ZS1000-A ZS1000-A OPM(optional) OPTICAL TIME DOMAIN REFLECTOMETER OPTICAL TIME DOMAIN REFLECTOMETER Press "OPM" button to turn on the OPM function, " " to open the function menu," "to hide the function menu. This device has VFL function, the output power is about 1mW. Press "VFL" button to control red laser on-flashing- off.
  • Page 10: Upgrading And Charging

    OTDR OTDR ZS1000-A ZS1000-A Upgrading and Charging Detail parameters OPTICAL TIME DOMAIN REFLECTOMETER OPTICAL TIME DOMAIN REFLECTOMETER Dynamic range 28/26dB 2020-06-01 17:25 Measure Set. System Set. System Set. Files Files Measure Set. About 3.5 inch colour LCD Insert the adapter to device, Min.
