  • Page 1 PLC-2760NV INSTRUCTION MANUAL...

  • Page 2: Table Of Contents

    4-2. Setting the optional input for the the center guide ..........7 4-3. Setting the optional output for the center guide ..........8 CAUTION This Instruction Manual for the PLC-2760NV only describes their differences from the stan- dard models (PLC-2760V). For safety-related information, carefully read and fully understand "Safety precautions"...

  • Page 3: Specifications

    Electronic control Alternate vertical feed control Electronic control Lubricating oil JUKI New Defrix Oil No. 1 (equivalent to ISO standard VG7) or JUKI MACHINE OIL No. 7 Number of patterns Sewing pattern ......99 patterns (For the polygonal shape sewing, as many as 10 patterns can be registered.)

  • Page 4: Threading The Machine Head

    2. Threading the machine head WARNING : To protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. Thread the machine head following the order as illustrated in the figure.

  • Page 5: Pneumatic Components (When The Pneumatic Center Guide Is Used)

    3. Pneumatic components (when the pneumatic center guide is used) WARNING : To protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. (1) Installing the regulator ❽...
  • Page 6 (3) Attaching the solenoid valve ❺ Attach solenoid valve asm. ❷ to the under- surface of the table with accessory screw ❶ ❶ (SK3452001SE). Connect the 6 tube described in step 4) in "(1) ø Installing the regulator" to joint ❸ . Cut the 6 tube to an appropriate length before ø...

  • Page 7: Setting The Incidental Device (Pneumatic Center Guide)

    4. Setting the incidental device 4-1. Setting the ON/OFF status of the center guide ❶ ❶ held pressed for three second. The "mode screen" is displayed. Select "14. Incidental device setting". The "Incidental device setting screen" is dis- played. When the device setting of which is to be changed is selected, the setting screen for the selected device is displayed.
  • Page 8 Select ON/OFF status of the function. ❷ to confirm the setting. Press ❷ <Center guide ON/OFF setting screen> ❸ to display the sewing data Press edit screen. ❸ ❹ to display the "S056 center Press guide". ❹ ❻ 10) Then, set the ON/OFF status of the center guide.

  • Page 9: Setting The Optional Input For The The Center Guide

    4-2. Setting the optional input for the the center guide Assign the switching function of the center guide to the 6-gang switch. ❶ ❶ held pressed for three second. The "mode screen" is displayed. Select "19. Optional I/O setting". Select "1. Optional input setting". Select "INPUT6.

  • Page 10: Setting The Optional Output For The Center Guide

    Select "i62. Center guide input". ❷ to confirm the selection. Press ❷ 4-3. Setting the optional output for the center guide Select "2. Optional output setting". Select "OUTPUT11. Function is not provided". Select "o25. Center guide". ❶ to confirm the selection. Press ❶...
