Ware Pet Products Clean Living 4.0 Assembly Instructions

Clean Living 4.0
Assembly Instructions
Item #16018
Roof
Bottom Wire Set
#901616
ScatterShield
Front/Back x2
#901356
Step 1
Insert 4 Wheels into the
bottom of the Plastic
Base. Tip: Place the two
locking wheels towards
the front of the cage.
Step 3
Attach Clips to right and
left side of wire and snap
lock onto Base.
Step 5
Snap Ramp Bases onto
Ramps and twist-lock
assembled Ramps onto
the hooks on the bottom
of the Shelves.
Step 7
Unfold the Upper Wire
Set and rest on top of
the Lower Wire Set.
Lock Upper Wire Set
Latches onto Lower Wire
Set. Tip: Make sure the
door faces front.
Top Wire Set
#902274
#901617
Ramp Base
ScatterShield
x5 #901612
Sides x2
#901357
Shelf x3
#901537
Ramps x4
#901613
Clips x2 Wheels x4
#901353
#901540
Step 2
Unfold the
Lower Wire Set and place
inside notches in plastic
Base. Slide Pull-out Tray into
the bottom of the base. Door
should be above Pull-out
Tray. Tip: Lower Wire
Set does not have wire
latches on the sides.
Step 4
Snap together ScatterSh-
ield panels. Slide assem-
bled ScatterShield down
the outside of the Wire
Set and insert into
notches on the
Base.
Step 6
Using 5 Shelf Knobs,
attach Shelf to the 2nd
bar from the bottom on
the left side of the Lower
Wire Set.
Step 8
Using 5 Shelf Knobs, attach
Shelf to the 4th bar from the
bottom on the right side. Then
attach a Shelf on the 6th bar
from the bottom on the left side.
Pull-out Tray
#901536
Shelf Knobs x15
#901539
Base #901535
