Ware Pet Products living room Series Assembly Instructions

®
Front Panel #900475
Back Panel #900476
Step 1
Step 2
Step 3
rabbit and guinea pig home
Roof Panel #900477
Floor Grate #902556
Tracks
facing in
Attach the Roof Panel by sliding
the right rear lower wire extension
under the support tabs and into the
hole on the Side Panel.
Slide the rest of the lower wire
extension under the open tabs
and into the hole in the left
Side Panel.
Attach side panel with 4
more hex Bolts and
tighten all.
living room series
assembly instructions
Plastic Tray #900479
Wheels x4
#900492
Side Panel x2
#900456
Insert a non-locking Wheel into the Right Side Panel so
the holes line up, then insert Bolt. Align the hole in the
bottom of the Back Panel with the hole in the Side
Panel that you just placed the Bolt through. Using the
Hex Wrench, screw in the Bolt through the Side Panel
and into the Back Panel; repeat for the opposite Side
Panel making sure the tabs face towards the outside
and the tracks face towards the inside of the cage.
Attach the Front Panel in the same way, using the
locking Wheels and making sure the door opens out.
TIP: Do not tighten bolts fully until all panels are
in place.
item #01930
Ramp
#901347
Food Bowl
#900469 Bolts x8
and
Hex Wrench
#900457
4 Hex Bolts
Shelf
#900493
