Summary of Contents for Beko DSN15420X
- Page 1 Dishwasher Manual Document Number: 15 9753 0300_AA_BEKO_A5_FR/ 16-01-18.(8:52)
- Page 2 Before you start, please read this user manual! Dear Customer, We hope you will get the best results from our product which is made using the advanced technologies and top quality materials. We therefore recommend that before using this product, you carefully read this manual and all the other documents supplied and keep them carefully for future reference.
- Page 3 Dishwasher Manual Document Number: 15 9753 0300_AA_BEKO_A5_FR/ 16-01-18.(8:52)
- Page 4 Before you start, please read this user manual! Dear Customer, We hope you will get the best results from our product which is made using the advanced technologies and top quality materials. We therefore recommend that before using this product, you carefully read this manual and all the other documents supplied and keep them carefully for future reference.
-
Page 5: Table Of Contents
TABLE OF CONTENTS 1 RELATED INSTRUCTIONS Special Lens Support ............ 23 Retractable Stemware Holder ........23 TO SAFETY AND THE Lower rack multi-function/adjustable height ENVIRONMENT support ................24 General safety ............4 Lower Rack Bottle Stem ........25 Intended use .......... -
Page 6: General Safety
Safety and environmental guidelines • This section contains safety Unplug the device when instructions that help guard not in use. • against the risk of personal Never wash the appliance by injury or property damage. spilling or pouring water on it! Failure to comply with these You will expose yourself to the instructions voids all... -
Page 7: Intended Use
Safety and environmental guidelines sensory or mental skills except when necessary. Pay are reduced or lack attention to the rush of hot sufficient experience or steam when you have to knowledge if a person in open the door. charge of safety Intended use supervises them or •... -
Page 8: Transporting The Device
Safety and environmental guidelines from recyclable materials. recycling. At the end of its life, Dispose of them properly and do not dispose of it with sort them according to the household waste. On the waste recycling instructions. contrary, have it disposed of at a Do not dispose of these collection point reserved for the materials with normal... -
Page 9: Dishwashers
Dishwasher Presentation 1. Upper basket 2. Upper helix 3. Lower propeller 4. Cutlery basket 5. Door 6. Rating label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir cover 12. Upper rack rail 13. Upper cutlery basket (varies by model) 14. -
Page 10: Fan Drying System
Dishwasher Technical specifications Compliance with standards and test data / EC Declaration of Conformity This product complies with the following EU directives: The stages of design, production and sale of this product are in compliance with the safety rules of all European Union regulations. 2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power circuit 220-240 V, 50 Hz (see rating... -
Page 11: Installation
Installation Suitable installation location Consult the nearest Authorized Service Agent for installation of your product. To make your machine ready for use, • Place the product on solid, level ground please check that the electricity, with sufficient load-bearing capacity!. drainage and water supply system are The appliance must be installed on a flat adequate before calling an authorized surface so that the door can be closed... -
Page 12: Adjusting The Feet
Installation Permissible water temperature: connection must be at least 50 cm and at up to 25°C most 100 cm from the ground. A drain It is not recommended to connect hose longer than 4 meters may cause the dishwasher to open water faulty washing. -
Page 13: Aquasafe
Installation Aquasafe+ • The power cable socket must be easily accessible after (depending on the model) installation. Protect the Aquasafe+ system against water leaks that may occur at the inlet of Unplug the appliance after the end the hose. Water contact with the system of the washing programme. -
Page 14: First Use
Installation First use Before you start using your device, make sure that all preparations have been made in accordance with the instructions given in the "Important safety instructions" and "Installation" sections. • To prepare the appliance for washing, first run it empty on the shortest program with detergent. -
Page 15: Preparation
Preperation Tips for saving energy System setting water softening The cleaning, rinsing and drying The following information will help you use the performance of your dishwasher product in an environmentally friendly and increases when the water softening energy efficient way. system is properly adjusted. - Page 16 Preperation Open the faucet remove the maintain the Wait a The strip test strip remove the strip of water and let test strip trial shows you in the water for minute. sound test sink about one about one of water and shake. the level of hardness.
-
Page 17: Adding Salt
Preperation use salts in your dishwasher. In this The salt reservoir fills with case, the “no salt indicator” (if fitted) water when you start the lights up continuously on the machine appliance. Therefore, add panel. salt before using the If the water hardness level is set to machine. -
Page 18: Detergent
Preperation Adding detergent You can pour about 2 kg of Carefully read the softening salt into the salt warnings on the detergent reservoir. package for best washing 5. Replace the lid and screw it tight and drying results. Contact when the tank is full. the detergent manufacturer for other questions. -
Page 19: Tablet Detergents
Tablet detergents In addition to conventional tablet detergents, there are also tablet detergents on the market which have the effect of a regenerating salt and/or a rinse aid. Some types of these detergents contain special components like stainless steel or glass protectors. These tablets show their effectiveness up to a certain 3. -
Page 20: Rinse Aid
Preperation Changing from powder detergent to tablet detergent: 1. Check that the salt and rinse aid reservoirs are full. 2. Set the water hardness to its maximum level and run the machine empty. 3. After the empty wash cycle, read the user manual and adjust the water 3. -
Page 21: Items Not To Be Washed In The Dishwasher
Preperation Items not to be washed in the • Place heavily soiled and large items in the lower rack and dishwasher smaller, delicate and light items in • Never wash dishes with cigarette the upper rack. ashes, remnants of candles, •... - Page 22 Preperation Dishwasher Loading Suggestions Incorrect loading of the dishwasher Lower basket Upper basket Incorrect loading of the dishwasher 20 /44 EN Dishwasher / Instructions for use...
-
Page 23: Cutlery Basket
Preperation Cutlery basket Cutlery basket (depending on the model) (depending on the model) The cutlery basket is designed to clean The cutlery basket is designed to clean your cutlery such as knives, forks, your cutlery such as knives, forks, spoons, etc. in a cleaner way. spoons, etc. -
Page 24: Lower Rack Retractable Rods
Preperation Lower basket retractable rods Putting the rods in a horizontal position by holding them by the ends can cause them to bend. (depending on the model) Therefore, it would be convenient The six retractable rods (A) located in the to arrange the middle rods in a lower basket of the machine are horizontal or vertical position by... -
Page 25: Drip Pan Support
Translated from French to English - www.onlinedoctranslator.com Special Glass Holder (depending on the model) The Special Glass Rack found in the lower basket of your machine guarantees safe washing of your fragile glasses. Putting the rods in a horizontal position by holding them by the ends can cause them to bend. -
Page 26: Support
Preperation Multi-function/height- Take care that the propeller does not adjustable lower basket touch the dishes placed on the racks. support (depending on the model) To close the supports: 1. This accessory located in the lower Fold the support (A). basket of the appliance allows you to 2. -
Page 27: Lower Rack Bottle Stem
Preperation Lower basket bottle rod (depending on the model) The bottle stem is designed for easier washing of long items with wide openings. You can remove the bottle rod from the basket when it is not in use by pulling it from the sides (H). You can lift the upper rack multi- purpose rack to remove it if you don't want to use it. -
Page 28: Adjusting The Height Of The Upper Basket
Preperation Upper basket height To lower the basket, while it is in the highest position; adjustment 1. Hold the upper basket rods with (depending on the model) with both hands, lift it slightly, The upper basket height adjustment simultaneously push and release mechanism has been designed so that the latches shown in the figure (B). -
Page 29: Upper Rack Retractable Rods
Preperation Retractable upper basket rods Release the latches attached to the right and left runners of the upper rack by pushing them outwards (depending on the model) Pull out the basket completely. Replace You can use retractable rods when the basket on the runners at the desired you want to create more space for height your dishes in the upper basket of... -
Page 30: Upper Cutlery Basket
Preperation Upper cutlery basket (depending on the model) The upper cutlery basket is designed to clean your cutlery such as forks, spoons, etc. by placing them between the bars of the basket. When the central tray is in the lower position, you can load long and tall objects such as coffee cups, ladles, etc. -
Page 31: Keys
Device Operation 2 3 4 10 9 On / Off / Program selection button Rinse aid indicator Salt indicator 4- On/Off control light 5- Time delay indicator 6- Time delay button 7- Handle 8- Program progress monitoring lights 9- Start / Pause / Cancel button 10- Half load function Keys 3. - Page 32 Device Operation 30 /44 EN Dishwasher / Instructions for use...
-
Page 33: Additional Functions
Device Operation Additional functions 3. Select the desired program and press the Half Load button. The The wash programs in your machine are Half Load indicator lights up on the designed to achieve the best possible wash, selected function indicator display. taking into account the type of soil, the degree of soiling and the characteristics of the dishes 4. -
Page 34: Starting The Program
Device Operation If you press the Time Your machine launches Delay button when the 9 water softening according to hour time delay light is the hardness level of the water flashing, the time delay supply. Due to the water lights will turn off. If you softening process, program press the Start/Pause/ duration may vary. -
Page 35: Program Progress Tracking
Device Operation Program progress When the program selection tracking knob is in the "Stop" position, the washing You can check the current phase of the program stops and the selected program from the program machine is ready for a new phase indicators on the control panel. -
Page 36: End Of The Program
Device Operation End of program clockwise. After this time, the machine switches to rinse aid The end of program indicator lights setting mode. up when the washing program is 2. After the machine enters the Rinse finished. 1. Press the On / Off / Aid Setting Mode, the rinse aid Program selection button to stop level will be displayed on the... -
Page 37: Care And Cleaning
Maintenance and cleaning Filter cleaning The life of the product is extended and frequently encountered problems are Clean the filters at least once a week reduced if it is cleaned regularly. for the device to work properly. Check Unplug the product and turn for food residue on the filters. -
Page 38: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the pipe filter Damage to the appliance caused by impurities from mains water or your own water installation (e.g. sand, dust, rust, etc.) can be avoided by to the filter attached to the water inlet valve. Regularly check the filter and the hose and clean them if necessary. -
Page 39: Cleaning The Propellers
Maintenance and cleaning Propeller cleaning upper propeller Clean the propellers at least once a Check whether the holes in the upper week to keep the device working propeller (1) are blocked. If they are, properly. remove the dirt and clean the propeller. Turn its nut to the left to remove the upper Lower propeller propeller. - Page 40 Repair The device does not start. • The electric cable is disconnected. >>> Check if the power cable is connected. • The fuse has blown. >>> Check the fuses in your house. • The water is off. >>> Check that the water inlet tap is open. •...
- Page 41 Repair The dishes are not dry at the end of the cycle • The dishes are not sorted in order in the machine. >>> Place the dishes in such a way that water does not accumulate between the plates. • There is not enough rinse aid.
- Page 42 Repair Limescale remains on dishes and glass looks dull • There is not enough rinse aid. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough rinse aid in the machine. •...
- Page 43 Repair • Heavy duty detergents like bleach are used. >>> The protective coating of metal surfaces is damaged and loses its effectiveness over time when it comes into contact with detergents such as bleach. Do not wash your dishes with bleach. •...
- Page 44 Repair The dishes are scratched. Cookware that contains aluminum or is made of aluminum should not be washed in the dishwasher. • There are salt leaks. >>> Be careful not to spill salt around the salt filling hole when adding salt. Scattered salt can cause scratches. Always make sure the lid of the salt container is properly closed after filling.
- Page 45 Repair Kitchen utensils are broken. • The dishes are not sorted in order in the machine. >>> Load the dishes as described in the user manual. • The baskets are overloaded. >>> Do not overload the baskets beyond their capacity. Water remains in the dishwasher at the end of the programme.
