3. Construction of the device

1
RF IN
7
1. USB connector
Display
2.
3. IR sensor
4. Previous channel
5. Next channel
https://mptech.eu/qr/techbite
Or by scanning the QR code below:
Front panel:
Rear of the device:
COAXIAL
8 9
2 3
TV SCART
10
6. Power button
7. RF IN
8. HDMI connector
9.
Audio output
10. SCART connector
