ISkin CERULEAN F1 User Manual

Using the Controls on the CERULEAN F1 Page 6
Switches and Controls
Front Bottom Top Side
(Right Earpiece)
The RIGHT earpiece contains all
Mic
controls including the power switch.
Mini USB
The LEFT earpiece contains the
Port (Type A)
lithium battery. Multi-function
Status LED Button Volume Next/Previous Power
Light Controls Track ON/OFF
The CERULEAN F1 is both a stereo Bluetooth® earphone and a mono headset. As a stereo
earphone, you can connect to a stereo Bluetooth (A2DP) audio device or iPod® (equipped with
the *CERULEAN TX) and listen to your audio wirelessly. As a mono headset, you can connect to
a Bluetooth mobile phone, accept or reject calls and access other call features.
The CERULEAN F1 uses standard Bluetooth 2.0 defined profiles making it capable of
interacting with other Bluetooth devices. These profiles allow it to remotely control specific
features of a device, act as wireless stereo earphones and also act as a wireless mono headset
for a mobile phone.
Headset Controls
To: Do this: Headset Controls
Redial Last Number* Press and Hold the Multi-function button until beep Press / Hold / Release
Activate Voice Dial* Press the Multi-function button Press / Release
Answer Incoming Call Press the Multi-function button Press / Release
Reject Incoming Call* Press and Hold the Multi-function button until beep on incoming call Press / Hold / Release
Terminate Current Call Press the Multi-function button during call Press / Release
Mute Mic ON/OFF Press either the Next or Previous Track button Press / Release
Cancel outgoing call Press and Hold the Multi-function during outgoing call Press / Release
Transfer call to/from phone* Press Multi-function button during call until beep Press / Hold / Release
(Answer second
Call Waiting * Press and Hold the Next/Previous Track button during first call until beep Press / Hold / Release
incoming call)
Toggle between Calls* Press and Hold the Next/Previous Track button during call until beep Press / Hold / Release
Multi-function Button Next/Previous Track Button
The above functions require a device with HFP and HSP Bluetooth support (refer to your device's manual). *Dependent on mobile phone features.
Using the Controls on the CERULEAN F1 Continued Page 7
Remote Control Functions (AVRCP)
To: Do this: Remote Functions
Play/Pause Press the Multi-function button once for each command Press / Release
Stop playing Press and Hold Multi-function button until music stops Press / Hold / Release
Skip to next track Press the Next Track button Press / Release
Skip to previous track Press the Previous. Track button Press / Release
Control volume The F1's volume controls affect only the F1 and does not remotely control the volume of a connected device.
Control volume Up/Down Press either the "+" or "-" on the Volume Control button Press / Release
Multi-function Button Next/Previous Track Button Volume up/down
The above functions require an iPod equipped with the CERULEAN TX Bluetooth transmitter or a device with AVRCP Bluetooth support (See your
device's manual. Compatibility may vary).
Power and Pairing Controls
To: Do this: Headset Controls
Turn power on/off: Slide the ON/OFF switch to the desired position
Make discoverable PRESS and Hold the Multi-function button then slide ON/OFF
+
(enter pairing mode) switch to ON position
Make undiscoverable PRESS the Multi-function button once
(exit pairing mode)
Reconnect to paired device Set the ON/OFF switch to the ON position and Press and Release the
+
Multi-function button once. Must be initially paired with a device.
Multi-function Button ON/OFF Switch
Enables the CERULEAN F1 to receive stereo audio wirelessly from any (A2DP) Bluetooth device.
Enables the CERULEAN TX to transmit stereo audio wirelessly via Bluetooth.
Enables the CERULEAN F1 to remotely control specific features of any (A2DP) Bluetooth device.
Enables the CERULEAN TX to receive remote control commands via Bluetooth to control the iPod.
Supported Profiles.
Enables the CERULEAN F1 to act as a wireless mono headset for taking phone calls via a Bluetooth mobile phone.
Enables the CERULEAN F1 to remotely make, answer or terminate a call on a Bluetooth mobile phone.
CERULEAN F1 Specifications Page 8
General: Earphone Driver Unit:
Bluetooth version 2.0, Class II Diameter <15mm
Bluetooth Profile Support A2DP / AVRCP / HSP/ HFP Frequency Response 20Hz ~ 20KHz
RF Frequency 2.4GHz / 79 Channel / AFH Sound Pressure Level 93dB @ 1KHz
Operational Range Standard 33 feet (10 meters)* Impedance 16 @ 1V, 1KHz
Talk Time (Headset ) max.10 hours* Power Rating 5mW (Max)
Music Listening (Earphone) max. 8 hours* Other:
Standby Time up to 300 hours Microphone Typical : ECM unit (110dB)
Battery Charge Time 2.5 hours (Lithium-Polymer) S/N Ratio Up to 58dB
Power / Charging Method (USB) 5V, 300mA / DC Dimensions 47mm x 25mm x 23.5mm
(L) x (W) x (H)
Weight 35g (approx.)
*May vary depending on user habits.
Troubleshooting
If the Status LED on my CERULEAN F1 is not on or flashing.
Check that the CERULEAN F1 is powered on. If the power is on but the LED light is off, then try
charging the unit as described in this manual.
If crackling noises and/or interruptions occur when listening to the CERULEAN F1.
Bluetooth is a radio technology. It is sensitive to environmental conditions and objects that may
interrupt the signal. Cordless phones, wireless internet routers or any device that operates on
wireless frequency of 2.4GHz may cause some interference. To ensure clear sound, use the device
within the operational range and conditions specified in this manual.
If you experience difficulty pairing the CERULEAN F1 with a Bluetooth device.
Make certain that the device you are attempting to connect to is compatible with the Bluetooth
profiles supported by the CERULEAN F1. Check that the CERULEAN F1 is set to discovery mode as
explained in this manual. Make sure there are no other Bluetooth devices that may be attempting
to pair with the CERULEAN F1.
If no sound can be heard from the CERULEAN F1.
Verify that the CERULEAN F1 is properly paired with the CERULEAN TX and that the device is set to
and capable of outputting audio via Bluetooth. Check the volume levels on both the connected
device and the CERULEAN F1.
Other questions? Page 9
Learn more about Bluetooth and the CERULEAN TX+F1 at www.iSkin.com
Status LED Light Definitions (TX)
STATUS DEFINITION ON OFF
Light flashes quickly Initial Pairing, looking for new device to pair with.
repeatedly. Occurs when the CERULEAN TX is connected to iPod
(Discoverable) or computer.
Light flashes very quickly, Seeking previously paired device to reconnect to.
pauses and repeats. Occurs when the CERULEAN TX has previously
(Auto-reconnect) connected to a CERULEAN F1 or Bluetooth device
and has lost connection.
Light flashes Successfully paired.
slowly repeatedly. Occurs when the CERULEAN TX has been successfully
(Paired / Connected) paired with a CERULEAN F1 or Bluetooth device.
Warranty Service
Note: The Serial Number is located in fine print on the inside of the RIGHT (R) ear piece
and rear of the TX.
If the CERULEAN F1 or TX does not seem to function correctly, consult the Troubleshooting
section of this guide and/or visit iSkin.com for further online resources. If the unit
continues to malfunction, visit iSkin.com and check the warranty section for information.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by iSkin Inc. is under license. iSkin and CERULEAN are trademarks of
iSkin Inc., registered in Canada, the U.S. and other countries.
Printed in China
