  • Page 1 All manuals and user guides at all-guides.com BDL5588XH V1.00 www.philips.com/welcome User Manual (English)
  • Page 2 All manuals and user guides at all-guides.com BDL5588XH Safety Instructions Safety precautions and maintenance :$51,1* 8VH RI FRQWUROV DGMXVWPHQWV RU SURFHGXUHV RWKHU WKDQ WKRVH VSHFLÀHG LQ WKLV GRFXPHQWDWLRQ PD\ UHVXOW LQ H[SRVXUH WR shock, electrical hazards and/or mechanical hazards. Read and follow these instructions when connecting and using your display: Operation: Maintenance: IMPORTANT...
  • Page 3 All manuals and user guides at all-guides.com BDL5588XH Read and follow these instructions when connecting and using your display: ‡ IMPORTANT CE Declaration of Conformity Federal Communications Commission (FCC) Notice (U.S. Only)
  • Page 4 All manuals and user guides at all-guides.com BDL5588XH 3ROLVK &HQWHU IRU 7HVWLQJ DQG &HUWLÀFDWLRQ 1RWLFH...
  • Page 5 All manuals and user guides at all-guides.com BDL5588XH Electric, Magnetic and Electromagnetic Fields (“EMF”) Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. Important: How to connect a plug...
  • Page 6 All manuals and user guides at all-guides.com BDL5588XH China RoHS...
  • Page 7 All manuals and user guides at all-guides.com BDL5588XH North Europe (Nordic Countries) Information VARNING: ADVARSEL: VAROITUS: ADVARSEL: End-of-Life Disposal (For customers in Canada and U.S.A.) Waste Electrical and Electronic Equipment-WEEE Attention users in European Union private households Attention users in United States: End of Life Directives-Recycling...
  • Page 8 All manuals and user guides at all-guides.com BDL5588XH Restriction on Hazardous Substances statement (India) E-Waste Declaration for India viii...

  • Page 9: Table Of Contents

    All manuals and user guides at all-guides.com BDL5588XH Operation ................. 18 Table Of Contents Unpacking and Installation ............1 Parts and Functions ..............8 &KDQJH \RXU VHWWLQJV ............. 23 86% GHYLFH FRPSDWLELOLW\ ............29 &RQQHFWLQJ ([WHUQDO (TXLSPHQW.......... 12 Input Mode ................31 3L[HO 'HIHFW 3ROLF\ ..............

  • Page 10: Unpacking And Installation

    All manuals and user guides at all-guides.com BDL5588XH Unpacking and Installation 1.1. Unpacking 1.2. Package Contents CD ROM Quick start guide * The supplied power cord varies depending on destination. Edge Alignment Kit-1 Remote Control and AAA Batteries Power Cord Daisy chain cable Edge Alignment Kit-2 Video Signal Cable...
  • Page 11 All manuals and user guides at all-guides.com BDL5588XH 1.4. Installing and Removing Table Stands (optional) To install table stands: Carrying handle Thumbscrews Guide block Longer portions face the front Table stand To remove table stands:...
  • Page 12 All manuals and user guides at all-guides.com BDL5588XH 1.5. Mounting on a Wall Protective Sheet VESA Grid Table Tabletop stand 1.5.1. VESA Grid BDL5588XH Caution: Ventilation Requirements for enclosure locating 100 mm 100 mm 100 mm 100 mm...
  • Page 13 All manuals and user guides at all-guides.com BDL5588XH 1.6. Mounting in Portrait Position...
  • Page 14 All manuals and user guides at all-guides.com BDL5588XH 1.7. Operating Instructions of Edge Alignment Kit 1.7.1. Installing Edge Alignment Kit...
  • Page 15 All manuals and user guides at all-guides.com BDL5588XH...
  • Page 16 All manuals and user guides at all-guides.com BDL5588XH 1.8. Using of Edge Finishing Kit (Optional) 1.8.1. Installing Edge Finishing Kit Edge Finishiing Kit-Top (*1PCS) Corner(*4PCS) Edge Finishiing Edge Finishiing Kit-Right(*1PCS) Kit-Left(*1PCS) Screw Edge Finishiing Kit-Bottom (QTY is different depending (*1PCS) on models) Edge Finishiing Kit-Top (*2PCS)

  • Page 17: Parts And Functions

    All manuals and user guides at all-guides.com BDL5588XH Parts and Functions 2.1. Control Panel MUTE INPUT MENU [ ] button Remote control sensor and power status indicator [MUTE] button [INPUT] button 6&+('8/( [ ] button [ ] button [ ] button [ ] button [MENU] button...
  • Page 18 All manuals and user guides at all-guides.com BDL5588XH 2.2. Input/Output Terminals 9 10 11 14 15 17 AC IN VGA IN (D-Sub) MAIN POWER SWITCH COMPONENT IN (BNC) IR IN / IR OUT Y/CVBS PC LINE IN NOTES IR IN SPEAKER SWITCH IR Pass Through AUDIO IN...
  • Page 19 All manuals and user guides at all-guides.com BDL5588XH 2.3. Remote Control [ ] POWER button 2.3.1. General functions [PLAY] buttons ] SOURCE button USB Network HDMI 1 HDMI 2 DisplayPort Card OPS DVI-D YPbPr AV ] HOME button ] LIST button [ ] [ ] [ ] [ ] NAVIGATION buttons ] button [ ] ADJUST button...
  • Page 20 All manuals and user guides at all-guides.com BDL5588XH 2.3.2. Inserting the batteries in the remote control Caution: 2.3.3. Handling the remote control 2.3.4. Operating range of the remote control Operation Angle RC operational distance θ...

  • Page 21: Rqqhfwlqj

    All manuals and user guides at all-guides.com BDL5588XH Connecting External Equipment 3.1. Connecting External Equipment (DVD/VCR/VCD) 3.1.1. Using COMPONENT video input Audio Out COMPONENT Out (YPbPr) DVD / VCR / VCD [AUDIO IN] [COMPONENT IN] (YPbPr) 3.1.2. Using Video Source input Y/CVBS Out DVD / VCR / VCD [AUDIO IN]...
  • Page 22 All manuals and user guides at all-guides.com BDL5588XH 3.1.3. Using HDMI video input DVD / VCR / VCD HDMI Out [HDMI IN] 3.2. Connecting a PC 3.2.1. Using VGA input VGA Out D-Sub 15 pin Audio Out [VGA IN] [VGA AUDIO IN] 3.2.2.
  • Page 23 All manuals and user guides at all-guides.com BDL5588XH 3.2.3. Using HDMI input HDMI Out [HDMI IN] 3.2.4. Using DisplayPort input DisplayPort Out [DisplayPort IN] 3.3. Connecting Audio Equipment 3.3.1. Connecting external speakers External speakers...
  • Page 24 All manuals and user guides at all-guides.com BDL5588XH 3.3.2. Connecting an external audio device Audio In Stereo Amplifier [AUDIO OUT] 3.4. Connecting Multiple Displays in a Daisy-chain Configuration 3.4.1. Display control connection DISPLAY 1 DISPLAY 2 [RS-232C] [RS-232C IN] [RS-232C OUT] [RS-232C IN] 3.4.2.
  • Page 25 All manuals and user guides at all-guides.com BDL5588XH DISPLAY 1 DISPLAY 2 [DP] [DP IN] [DP OUT] [DP IN] DVD / VCR / VCD DISPLAY 1 DISPLAY 2 [HDMI] [DVI IN] [DVI OUT] [DVI IN] 3.4.3. Analog video connection DISPLAY 1 DISPLAY 2 [VGA] [VGA IN]...
  • Page 26 All manuals and user guides at all-guides.com BDL5588XH 3.5. IR connection External IR Receiver [IR IN] IR IN 3.6. IR Pass-through Connection [IR OUT] DVD / VCR / VCD [IR IN] (DVD / VCR / VCD) Remote Control 3.7. Wire-connecting to Network 3OD\ PXOWLPHGLD ÀOHV YLD /RFDO $UHD 1HWZRUN INTERNET ROUTER...

  • Page 27: Operation

    All manuals and user guides at all-guides.com BDL5588XH To setup the network: Operation NOTE ] HOME Setup 4.1. Watch the Connected Video Source Connect to network ] SOURCE (QG 8VHU /LFHQFH $JUHHPHQW 4.2. Change Picture Format ] FORMAT Auto zoom 0RYLH H[SDQG  Wide screen Unscaled...
  • Page 28 All manuals and user guides at all-guides.com BDL5588XH Movie ] HOME Setup Music Game News Internet Source 4.5. Play multimedia files via Local Area Setup Network Connect to network Connect to network Quick picture and sound 4.5.1. Set up the network Settings Network settings Connect...
  • Page 29 All manuals and user guides at all-guides.com BDL5588XH You can play photos, music and movies stored on a computer in your home network. View network settings To do so, you need to install recent media server software on the computer. A list of Network settings suitable media server software is available in the Help.
  • Page 30 All manuals and user guides at all-guides.com BDL5588XH ] OPTIONS Music options &OHDU RIÁLQH VHUYHUV ] OPTIONS 6KXIÁH 4.6. Play multimedia files from USB device Repeat Repeat 3OD\ RQFH ] INFO ] INFO 4.7.2. Playing movie files Movie Movie ] SOURCE Play All Network HDMI 1...
  • Page 31 All manuals and user guides at all-guides.com BDL5588XH Slideshow options ] OPTIONS 6KXIÁH Repeat Repeat 3OD\ RQFH Slideshow Time Slideshow Transitions 4.8. How to use Opera browser (HTML5) ] HOME Internet Setup Source Internet Done Internet Web Address： http:// History www.google.com Bookmark .

  • Page 32: Kdqjh \Rxu Vhwwlqjv

    All manuals and user guides at all-guides.com BDL5588XH 5.1. Quick picture and sound Change your settings Using the remote control: ] HOME Setup Quick picture and sound Continue 5.2. Settings ] HOME Setup Settings ] HOME 5.2.1. Picture Setup Picture [ ] [ ] [ ] Quick picture and Sound...
  • Page 33 All manuals and user guides at all-guides.com BDL5588XH Advanced Advanced Gamma Auto volume leveling Tint Speaker settings Custom tint Clear sound Tint Æ Custom Audio out format Video contrast Brightness $XGLR RXW GHOD\ Audio out offset Game or computer $XGLR RXW GHOD\ Game 5.2.3.
  • Page 34 All manuals and user guides at all-guides.com BDL5588XH ([DPSOH  [  VFUHHQ PDWUL[  GLVSOD\V 5.2.4. General settings Picture H monitors Sound Tiling Position General settings Frame comp. Menu language Monitor group Monitor ID Eco mode Auto search Clock Scheduling Clock Clock...
  • Page 35 All manuals and user guides at all-guides.com BDL5588XH On time Picture Sound Tiling General settings On time Scheduling On time 00 : 00 Cancel Done Status Off time Off time Off time 14 : 00 Cancel Done Source Æ USB Source Source Æ...
  • Page 36 All manuals and user guides at all-guides.com BDL5588XH Source Æ USB Playlist setting /RFN DOO H[SHFW YROXPH DQG SRZHU RC lock Unlock /RFN DOO /RFN EXW YROXPH /RFN EXW SRZHU [ ] POWER /RFN DOO H[SHFW YROXPH DQG SRZHU [ ] POWER Local KB lock Options Exit...
  • Page 37 All manuals and user guides at all-guides.com BDL5588XH DisplayPort Ver. Clear Internet memory Cooling Fan Factory settings 5.3. Network Settings Setup ] HOME Network Settings View network settings Network settings Static IP configuration Digital Media Renderer - D... Network name Clear Internet memory View network settings Network settings...

  • Page 38: 86% Ghylfh Frpsdwlelolw

    All manuals and user guides at all-guides.com BDL5588XH USB device compatibility USB Video Subtitle Formats (for language subtitles, etc.) USB Multimedia Formats...
  • Page 39 All manuals and user guides at all-guides.com BDL5588XH...

  • Page 40: Input Mode

    All manuals and user guides at all-guides.com BDL5588XH Input Mode VGA Resolution: SDTV Resolution: HDTV Resolution: INPUT...
  • Page 41 All manuals and user guides at all-guides.com BDL5588XH Pixel Defect Policy 8.1. Pixels and Sub-Pixels subpixel pixel 8.2. Types of Pixel Defects + Dot Definition 'RW GHÀQLWLRQ :KDW LV D GHIHFWLYH ´'RWµ"  R R G B 8.3. Bright Dot Defects...
  • Page 42 All manuals and user guides at all-guides.com BDL5588XH 8.4. Dark Dot Defects 8.5. Proximity of Pixel Defects 8.6. Pixel Defect Tolerances 8.7. MURA HOW TO SPOT MURA HOW TO AVOID MURA...

  • Page 43: Cleaning And Troubleshooting

    All manuals and user guides at all-guides.com BDL5588XH Cleaning and Troubleshooting 9.1. Cleaning Caution When Using the Display Front Panel Cleaning Instructions Cabinet Cleaning Instructions...
  • Page 44 All manuals and user guides at all-guides.com BDL5588XH 9.2. Troubleshooting 6\PSWRP Possible Cause 5HPHG\ 1R SLFWXUH LV GLVSOD\HG ,QWHUIHUHQFH GLVSOD\HG RQ WKH GLVSOD\ RU DXGLEOH noise is heard Color is abnormal Picture is distorted with abnormal patterns 'LVSOD\ LPDJH GRHVQ·W ÀOO XS WKH IXOO VL]H RI WKH screen Can hear sound, but no picture Can see picture but no sound is heard...
  • Page 45 All manuals and user guides at all-guides.com BDL5588XH Technical Specifications Display: Item 6SHFLÀFDWLRQV In/Out Terminals: Item 6SHFLÀFDWLRQV...
  • Page 46 All manuals and user guides at all-guides.com BDL5588XH General: Item 6SHFLÀFDWLRQV Environmental Condition: Item 6SHFLÀFDWLRQV Internal Speaker: Item 6SHFLÀFDWLRQV...
  • Page 47 All manuals and user guides at all-guides.com 2014 © Koninklijke Philips N.V. All rights reserved. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. 6SHFLÀFDWLRQV DUH VXEMHFW WR FKDQJH ZLWKRXW QRWLFH...
